1.7cu.ft. oven-the-range microwave

Advertisement

1.7Cu.Ft. Oven-the-Range Microwave
Please read these instructions carefully before installing and operating the oven.
技术要求:欧盟 ROHS2.0 指令要求规定的十种有害物质的含量符合 ROHS2.0 指令要求。
标 记 处数 更改单号 签 字
设 计
周亚娥
标准化
校 对
审 定
审 核
杨瑞其
工 艺
日 期 2018-05-02
USER GUIDE
RED500JAH-SACH0A
说明书
RED500JAH-SACH0A
(D100D50ASLRIIIH-JA)
日期
关业红
图 样 标 记
李丰
S
A
共 27 页
JS1M0609-22260-004-(0)
数量 重量 比例
1:1
第 /
广东格兰仕微波生活
电器制造有限公司

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RED500JAH-SACH0A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Galanz RED500JAH-SACH0A

  • Page 1 USER GUIDE 1.7Cu.Ft. Oven-the-Range Microwave RED500JAH-SACH0A Please read these instructions carefully before installing and operating the oven. 技术要求:欧盟 ROHS2.0 指令要求规定的十种有害物质的含量符合 ROHS2.0 指令要求。 说明书 JS1M0609-22260-004-(0) RED500JAH-SACH0A (D100D50ASLRIIIH-JA) 标 记 处数 更改单号 签 字 日期 设 计 周亚娥 标准化 关业红 图 样 标 记...
  • Page 2: Table Of Contents

    CONTENTS  IMPORTANT SAFETY INSTRUCTIONS ..................2  PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ..4  UNPACKING INSTRUCTIONS ....................4  GROUNDING INSTRUCTIONS ....................5  INFORMATION YOU NEED TO KNOW ..................6  SPECIFICATIONS ........................10  FEATURES DIAGRAM ......................10  CONTROL PANEL FEATURES ....................11  BASIC CONTROLS ........................13  Function description: ......................13  Setting the Clock ......................13  Setting Microwave cooking program ................13  Multi stage cooking......................14  Grill cooking ........................14  Microwave + Grill Cooking ....................
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS  When using electrical appliances, basic safety precautions should be followed, including the following:  WARNING  ‐ To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to  excessive microwave energy:   Read all instructions before using the appliance.   Read  and  follow  the  specific  "PRECAUTIONS  TO  AVOID  POSSIBLE  EXPOSURE  TO  EXCESSIVE  MICROWAVE ENERGY" on page 4.     This appliance must be grounded. Connect only to properly grounded outlet. See "GROUNDING  INSTRUCTIONS” on page 5.   Install or locate this appliance only in accordance with the provided installation instructions.     Some products such as whole eggs and sealed containers ‐for example, closed glass jars‐ are able  to explode and should not be heated in this oven.   Use  this  appliance  only  for  its  intended  use  as  described  in  this  manual.  Do  not  use  corrosive  chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or ...
  • Page 4  Do not cover or block any openings on the appliance.   Do  not  store  or  use  this  appliance  outdoors.  Do  not  use  this  product  near  water,  for  example,  near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.   Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if it  has been damaged or dropped.   Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord hang  over edge of table or counter.   Use only thermometers, which are specifically designed for use in microwave ovens.   Do not operate any heating or cooking appliance beneath this appliance.   Be certain the glass tray and roller rings are in place when you operate the oven   This appliance should be serviced only by qualified service personnel, contact nearest authorized  service facility for examination, repair, or adjustment.   When cleaning surfaces of door and oven that comes together on closing the door, use only mild,  nonabrasive soaps, or detergents applied with a sponge or soft cloth.   VENTILATING HOODS ...
  • Page 5: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE  TO EXCESSIVE MICROWAVE ENERGY  (a) Do not attempt to operate this oven with the door open since open‐door operation can result in  harmful exposure to microwave energy. It is important not to defeat or tamper with the safety  interlocks.  (b) Do  not  place  any  object  between  the  oven  front  face  and  the  door  or  allow  soil  or  cleaner  residue to accumulate on sealing surfaces.  (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close  properly and that there is no damage to the:  ① Door (bent),    ② Hinges and latches (broken or loosened),  ③ Door seals and sealing surfaces.  (d) The  oven  should  not  be  adjusted  or  repaired  by  anyone  except  properly  qualified  service  personnel.
  • Page 6: Grounding Instructions

    The  extension  cord  must  be  a  grounding‐type  3‐wire  cord,  and  The  longer  cord  should  be  arranged so that it will not drape over the counter top or table top where it can be pulled on  by children or tripped over unintentionally.  NOTES:    If  you  have  any  questions  about  the  grounding  or  electrical  instructions,  consult  a  qualified  electrician or service person.    Neither Galanz nor the dealer can accept any liability for damage to the oven or personal injury  resulting from failure to observe the electrical connection procedures.   Radio or TV Interference  Should there be any interference caused by the microwave oven to your radio or TV, check that the  microwave oven is on a different circuit, relocate the radio or TV as far away from the oven as feasible  or check position and signal of receiving antenna. ...
  • Page 7: Information You Need To Know

    NOTE: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
  • Page 8  Stir foods from outside to center of dish once or twice during cooking, if possible.   Turn  foods  over  once  during  microwaving  to  speed  cooking  of  such  foods  as  chicken  and  hamburgers. Large items like roasts must be turned over at least once.   Rearrange foods such as meatballs halfway through cooking both from top to bottom and from  the center of the dish to the outside.   Add  standing  time.  Remove  food  from  oven  and  stir,  if  possible.  Cover  for  standing  time  that  allows the food to finish cooking without overcooking.  ...
  • Page 9  The proper containers and covers are essential for best sensor cooking.   Always use microwave‐safe containers and cover them with lids or vented plastic wrap. Never use  tight  sealing  plastic  containers  —  they  can  prevent  steam  from  escaping  and  cause  food  to  overcook.   Be  sure  the  outside  of  the  cooking  containers  and  the  inside  of  the  microwave  oven  are  dry  before placing food in the oven. Beads of moisture turning into steam can mislead the sensor.   Do not use this feature twice in succession on the same food portion — it may result in severely ...
  • Page 10 Small flat pieces of aluminum foil placed smoothly on the food can be used to shield areas that  are either defrosting or cooking too quickly.   Foil should not come closer than one inch to any surface of the oven.  ACCESSORIES   There  are  many  microwave  accessories  available  for  purchase.  Evaluate  carefully  before you purchase so that they meet your needs. A microwave‐safe thermometer will assist you in  determining  correct  doneness  and  assure  you  that  foods  have  been  cooked  to  safe  temperatures.  Galanz is not responsible for any damage to the oven when accessories are used  ABOUT CHILDREN AND THE MICROWAVE   Children below the age of 7 should use the microwave oven with a supervising person very near  to them. Between the ages of 7 and 12, the supervising person should be in the same room.   The children must be able to reach the oven comfortably; if not, he/she should stand on a sturdy  stool.  ...
  • Page 11: Specifications

     Children need to learn that the microwave oven is not a toy.  SPECIFICATIONS  Power Supply  120V 20AC 60Hz Single phase  Power Consumption  1650W(Microwave), 1350W(Grill), 1600W(Convection)  Output Power  1000W  Microwave Frequency    2450MHz  Outside Dimensions  16  ”(H)×29  ”(W)×17  ”(D)  Cavity Dimensions    10  ”(H)×21  ”(W)×14  ”(D)  Oven Capacity    1.7 Cu.Ft.  Cooking Uniformity    Turntable /Stirrer Fan System  Weight    Approx. (net) 67.0lb / (gross) 76.3lb    FEATURES DIAGRAM  1. Door Safety Lock System  2. Oven Window  3. Roller Ring  4.
  • Page 12: Control Panel Features

    CONTROL PANEL FEATURES  Your microwave oven control panel lets you select the desires cooking function quickly and easily. All  you have to do is touch the necessary Command pad. The following is a list of all the Command and  Number pads located on the control panel. For more information on these features, see the operation  section. ...
  • Page 13 1. Display. The display includes a clock and indicators to tell you time of day, cooking time settings  and cooking functions selected.  2. Sensor Cook Menu. Touch to set sensor cooking program (such as Veggies, Potato, Meat, Reheat).  3. Auto cook menu. Instant settings to cook popular foods (such as Popcorn, Melt/Soften, Beverage,  Cakes, Keep Warm and Chicken).  4. 1 LB Defrost. Touch this button to defrost frozen food quickly.  5. Number. Touch number pads to enter cooking time, power level, cooking temperature or weight  and you can set express cooking program by touching 1~6 pad.  6. Clock/Timer. Press to set current time of day or set the oven timer.  7. Grill. Press to set grill cooking program.  8. Power Level. Touch this pad to set cooking power level  9. Combi. Use to set microwave and grill or microwave and convection combination cooking.    10. Vent Delay Off. Use to set vent delay off program.  11. Time Defrost. Use to defrost food based on time enter.  12. Weight Defrost. Use to defrost food based on weight enter.  13. Stop/Cancel. Touch this pad to stop the oven or press this pad for 3 seconds to set child lock.  14. Start/Add 30 Sec. Touch to start the oven; also use to start the oven quickly at full power or use to  add cooking time.  15. Time Cook. Use to set microwave cooking or multi‐stage cooking.  16. Convection. Use to set convection cooking.  17. Turntable. Touch this pad to turn on/off the turntable.  18. My Settings.    Touch this pad to adjust the default settings for sound, weight unit and daylight  save time. ...
  • Page 14: Basic Controls

    BASIC CONTROLS  Learn about your microwave oven.  CAUTION    To  avoid  risk  of  personal  injury  or  property  damage,  do  not  operation  the  microwave  oven  empty.   To  avoid  risk  of  personal  injury  or  property  damage,  do  not  use  stoneware,  aluminum  foil,  metal utensils, or mental trimmed utensils in the microwave oven. Function description:   When the oven first plugged in, the display will fully displayed for 3s and then show “AM ...
  • Page 15: Multi Stage Cooking

    99 minutes, 99 seconds.                   Power Level Press  pad once and then press number pads to choose cooking power level.  Use number pad choose cooking power level  Press Number pad  Power level (Display)  Press Number pad  Power level (Display) 1、0  100% (PL: Hi)  4  40% (PL: 40)  9  90% (PL: 90)  3  30% (PL: 30)  8  80% (PL: 80)  2  20% (PL: 20)  7  70% (PL: 70)  1  10% (PL: 10)  6  60% (PL: 60)  0  0% (PL: 00)  5  50% (PL: 50)     ...
  • Page 16: Microwave + Grill Cooking

    The  longest  cooking  time  is  99  minutes,  99  seconds.  The  grill  cooking  is  particularly  useful  for  thin  slices  of  meat,  steaks,  chops,  kebabs,  sausages  of  piece  of  chicken.  It  is  also  suitable  for  hot  sandwiches and au gratin dishes.  For example, suppose you want to grill for 12 minutes.  Grill Press   button once.  Touch number pad to enter cooking time.  Start/Add 30Sec Press ...
  • Page 17: Microwave + Convection Cooking

    the oven reaches the programmed temperature, beeps will sound.  Open the door and place container of food at the center of the turntable.  Touch number pad to enter cooking time.  Start/Add 30Sec Touch   pad.    NOTE: The longest preheat time is 30 minutes and the time cannot be set. When the temperature  reaches the preheat temperature, the countdown stop with sound every 6 seconds for 30 minutes.  If you don’t open the oven door within the 30 minutes, the system will stop automatically  Microwave + Convection Cooking  F →350  F →300  F→250 F. You  This oven has four different combination cooking temperatures 400  Combi can  choose  it  by  touching    pad.  It’s  easy  to  cook  with  both  convection  heat  and  microwave  automatically. The longest cooking time is 99 minutes, 99 seconds. During cooking, the current cooking   Combi temperature can be seen by touching  pad.   Combi Press  pad to choose cooking temperature: ...
  • Page 18: Vent Delay Off

    cycle gears:  Vent/4 Speed Press   button  Working Mode  Once  Boost  Twice  High  3 times  Medium  4 times  Low  5 times  Off    NOTE:     When you use microwave or convection cooking programs, if the range hood has been turned  on, it will maintain works in original gear and you can manual switch it.   When  you  use  grill  cooking  program,  if  the  range  hood  has  been  turned  on,  it  will  maintain  works in original gear, otherwise, it will auto switch into low gears. You can manual adjust.  ...
  • Page 19: Turntable Control

     SOUND ON/OFF  My Settings 1. In standby, press   once    2. Press number pad   to enter the Key‐touch beep setting. You can press number pad   to select  sound on, “SOUND ON” will display. If you want to have the oven operate with no audible signals,  press number pad   to select sound off, “MUTE” will display.   My Settings 3. Press  to confirm you choose.   DAYLIGHT SAVE TIME HINT   My Settings 1. In standby, press  once.  2. Press  number  pad    to  enter  the  Daylight  Saving  Time  setting.  The  display  will  show  “CURRENT  STATE IS OFF, 1‐ON,2‐SKIP” or ”CURRENT STATE IS ON ,1‐OFF,2‐ SKIP” ...
  • Page 20: Special Features

    SPECIAL FEATURES  Setting Auto Cook  For foods such as Popcorn, Melt/Soften, Beverage, Cake, Keep warm and Chicken, it is not necessary to  program the time and the cooking power. It is sufficient to indicate the type of food that you want to  cook as well as the weight of this food.     POPCORN  Popcorn 1. In standby mode, press   pad once, the display will cycle show”1‐3.5 oz, 2‐3 oz”.   2 2. Press number pad   or  to select food weight.   Start/Add 30Sec 3. Press  pad to start cooking.  Press number pad  Weight(oz or gr)  Cooking time  1  3.5 oz. (100 gr)  2:00  2  3 oz. (85 gr)  1:50   Melt/Soften  Melt/Soften In  standby  mode,  press    pad  once,  the  display  will  cycle  show”1‐  CHEESE,  2‐  ICE  CREAM, 2‐ BUTTER”. ...
  • Page 21: Sensor Cook

    NOTE: You can choose 1‐3 cups (250ml/cup).   Cake   Cake In standby mode, press  pad once. The display will show”16 oz” or “453gr”.   Start/Add 30Sec Press  pad to start cooking.   Keep Warm   Keep Warm In standby mode, press  pad once, the display shows”30:00”.  Start/Add 30Sec Press   pad.  Start/Add 30Sec NOTE: If you want to change keep warm cooking time, before press   pad, press  number pad to enter cooking time, the longest time you can set is 99 minutes, 99 seconds, and then  Start/Add 30Sec press   pad start cooking.   Chicken  Chicken  In standby mode, press  pad once, the display will cycle show” 1‐28 oz., 2‐35 oz., 3‐42 oz.,  4‐50 oz.” or ”1‐0.8kg, 2‐1.0kg, 3‐1.2kg, 4‐1.4kg”.  1, 2, 3, or 4 Press number pad   to select food weight.  Start/Add 30Sec Press   pad.  Press    Weight (oz. or gr) Cooking time ...
  • Page 22: Weight Defrost

    NOTE: The weight range is 5‐24 oz.(or 150‐700gr).   POTATO  For example you want to cook two potatoes.  1. Place potato into the oven and close the door.  Potato 2. Press   pad once, the display show ”POTATO”.  Start/Add 30Sec 3. Press   pad start cooking.  NOTE:     The  number of  serving  is  1‐3 potatoes (6‐8  oz./each or  170‐230gr/each),  the  longest  cooking  time is 15 minutes.     For best result, slice the potatoes and place them on the plate before heating   REHEAT  For example, you want to cook pasta.  1. Place the pasta into the oven and close the door.  Reheat  2. Press  pad once, the display will cycle display”1‐DINNER PLATE, 2‐CASSEROLE, 3‐PASTA”.   “3” ...
  • Page 23: 1Lb Defrost

    NOTE:     During  defrost,  the  oven  will  sound  beep  and  pause,  the  display  will  cycle  shows  “Turn  the  Start/Add 30Sec food over” to remind user to turn the food over, after that, press   pad to  resume.   After  the  last  stage,  small  sections  may  still  be  icy.  Let  stand  to  continue  thawing.  Do  not  defrost until all ice crystals are thawed. ...
  • Page 24: Express Cooking

    Express Cooking   1‐6 In standby mode, touch one of number pad from .  Start/Add 30Sec  Touch  pad to confirm. The oven will start cooking at full power level.  Setting the Timer  Suppose you want to time a 3 minutes cooking.    Clock/Timer 1. In standby mode, touch   pad twice “ENTER KITCHEN TIMER” will cycle display.  2. Use the number pads to enter time.    Start/Add 30Sec 3. Touch   pad.  NOTE:     The longest time you can set is 99 minutes and 99 seconds.     Once you have set the timer function, in either cooking or standby mode, you can check the  Clock/Timer countdown by press  pad twice. Child Lock  The  child  lock  prevents  unsupervised  operation  by  children  and  this  program  only  works  in  standby  mode ...
  • Page 25: Clear And Care

    Stop/Cancel  pad to return normal condition.  E‐23‐ Maximum time alarm: When the humidity sensor cooking reached the longest time, the oven  Stop/Cancel will  sound  beep  and  show”E‐23”,  after  troubleshooting,  press    pad  to  return  normal  condition.  E‐24:  During  sensor  menu  cooking  process,  if  you  open  the  oven  door  for  5s,  the  system  will  sound  Stop/Cancel beep and the display will show”E‐24”, after troubleshooting, press   pad to return normal  condition.  E‐d1‐ Button adhesion alarm: In any state, if any pad on the control panel is closed for 10 seconds, the ...
  • Page 26 Odor Removal  Occasionally, a cooking odor may remain in the oven. To remove, combine 1 cup water, grated peel  and juice of 1 lemon and several whole cloves in a 2‐cup glass measuring cup. Boil for several minutes  using 100% power. Allow to set in oven until cool. Wipe interior with a soft cloth.  Turntable/Turntable Support  The  turntable  and  turntable  support  can  be  removed  for  easy  cleaning.  Wash  them  in  mild,  sudsy  water; for stubborn stains use a mild cleanser and non‐abrasive scouring sponge as described above.  They are also dishwasher‐proof. Use upper rack of dishwasher. The turntable motor shaft is not sealed,  so excess water or spills should be wiped up immediately.  Grease Filters    Filters should be cleaned at least once a month. Never operate the fan or oven without the filters in  place.  Pull down slightly on the tab toward the front of the oven and remove the filter. Repeat for the other  filter.  Soak the filter in a sink or dish pan filled with hot water and detergent. DO NOT use ammonia or other  alkali; they will react with the filter material and darken it.  Agitate and scrub with a brush to remove embedded dirt.  Rinse thoroughly and shake dry.  Replace by fitting the filter back into the opening.    Light  To replace light bulbs, first disconnect power to the oven at the circuit breaker panel or by unplugging.  To release cover, remove the screw on the light cover. (See illustration.)        DO NOT USE A BULB LARGER THAN 30 WATTS. ...
  • Page 27     Charcoal Filter  Charcoal filter is used for nonvented, recirculated installation. The filter should be changed every 6 to  12 months depending on use.   Disconnect power to the oven at the circuit breaker panel or by unplugging.   Remove the louver mounting screw from the top center of the louver and push down carefully on  the tab at each end of the louver to disengage it. (See illustration.)   Pull the louver away from the unit.   Change the charcoal filter.   Carefully push the louver back into place and replace the screw remove in step 2.  Oven Light  Remove the louver per instructions 1~3 above and charcoal filter, if used. ...
  • Page 28  Open light cover located behind filter mounting by carefully pulling up on the front edge.       DO NOT USE A BULB LARGER THAN 30 WATTS.   Replace the oven light cover by carefully pushing into place. Replace the charcoal filter, if used.  Push the louver back into place and replace the louver mounting screw. ...
