CONVECTION MICROWAVE OVEN
M i c r o w a v e O v e n
O w n e r ' s M a n u a l
Please read these instructions carefully before installing and operating the oven.
Record in the space below the SERIAL NO. found on the nameplate on your oven and retain
this information for future reference.
SERIAL NO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD900EP23-K7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Galanz WD900EP23-K7

Summary of Contents for Galanz WD900EP23-K7

  • Page 1 CONVECTION MICROWAVE OVEN M i c r o w a v e O v e n O w n e r ' s M a n u a l Please read these instructions carefully before installing and operating the oven. Record in the space below the SERIAL NO.

  • Page 2: Table Of Contents

    Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

  • Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    Power Consumption: 120V/60Hz 1500W(Microwave) 1450W(Convection) 1050W (Grill) Rated Microwave Output: 1000W Operation Frequency: 2450MHz Outside Dimensions(H×W×D): 17in×25 11/16in×17 11/16 in Oven Cavity Dimensions(H×W×D): 8 11/16in×14 13/16in×15 7/8in Oven Capacity: 1.2 cu.ft Cooking Uniformity: Turntable System Net Weight: Approx. 47.73 lbs When using electrical appliances, basic safety appliance.

  • Page 4: Save These Instructions

    always present. THEIS COULD RESULT not let cord hang over edge of table or IN VERY HOT LIQUIDS SUDDENLY counter. BOILING OVER WHEN A SPOON OR 18. Use only thermometers, which OTHER UTENSIL IS INSERTED INTO specifically designed THE LIQUID. To reduce the risk of injury microwave ovens.

  • Page 5: Installation Guide

    Make sure that all the packing materials materials. are removed from the inside of the door. Do not operate the oven without glass Check the oven for any damage, such tray and roller support in their proper as misaligned or bent door, damaged positions.

  • Page 6: Utensils Guide

    longer cord should be arranged so that it personal injury resulting from failure to observe will not drape over the counter top or the electrical connection procedures. table top where it can be pulled on by Radio or TV Interference children or tripped over unintentionally.

  • Page 7: Cooking Techniques

    Your microwave makes cooking easier than conventional cooking, provided you keep these considerations in mind: TIRRING Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the center. The oven will turn off when you open the door to stir your food.

  • Page 8: Part Names

    1. Door Safety Lock System 2. Oven Window 3. Roller Ring 4. Shaft 5. Door Release Button 6. Control Panel 7. Wave Guide (Please do not remove the mica plate covering the wave guide) 8. Glass Tray 9. Grill Heater 10.

  • Page 9: Control Panel

    DISPLAY WINDOW Used to indicate clock, cooking time, etc. QUICK COOK BUTTONS: CAKE, POTATO, POPCORN, BEVERAGE, PIZZA, CHICKEN, REHEAT, SPAGHETTI NUMBER PADS Use to enter clock, cooking time, temperature, etc. GRILL Press to set a grill-cooking program. CONVECTION Press to program convection cooking. MICRO.

  • Page 10: How To Set The Oven Controls

    1. If you want to temporarily stop a cooking SETTING THE CLOCK session, press the STOP pad once and When the oven is first plugged in, you can set the then you can start the cooking again by clock time. To set the clock time later, pressing START;...

  • Page 11: Microwave +Grill

    Suppose you want to preheat to 340℉ and then Number Temperature (℃) cook 30 minutes. COMB1 1. Press CONVECTION. COMB2 2. Press number pad 7 to indicate convection COMB3 temperature 340℉. COMB4 3. Press START button. “PREH” will flicker in the display until it reaches the designated Suppose you want to bake food for 24 minutes on temperature.

  • Page 12: Menu Cook

    temperature. Convection cooking 5. Use the number pads to enter convection cooking time. 6. Press START button. 1. Press POWER LEVEL button to set power level. NOTE: WEIGHT DEFROST and MENU COOK cannot be set in a multi-stage cooking program. 2.

  • Page 13: Other Convenient Features

    TIMER To use the timer feature, when you need to be reminded of the cooking or some other things, Press TIMER button. Use the number pads to enter the time to be counted down. Press START button. NOTE: 1. When the countdown ends, the system buzzer will beep. Time countdown can be seen in display for 5 seconds before clock or cooking time is returned to exhibit.

  • Page 14: Cleaning And Care

    Turn off the oven and remove the power plug from the wall socket before cleaning. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray and other harsh cleaners as they may stain, streak or dull the door surface.
