- Page 1 Ducted Split System Air Conditioners Technical Data ISD 380, 465, 570, 670, 840, 950 Cooling Capacity Heating Capacity 37.6kW - 94.9kW 35.9kW - 90.1kW...
-
Page 2: Table Of Contents
Ducted Split System Air Conditioners Contents ISD 380–950 PERFORMANCE DATA General Cooling Capacity (kW) Applications Indoor Air Flow Correction Factors @ nominal conditions Air Flow Selection Pipe Length Capacity Loss Features Heating Capacity (kW) Refrigerant R410A Air Handling Economical Sound Levels Efficient Quiet Performance... -
Page 3: Isd 380-950
Ducted Split System Air Conditioners ISD 380–950 Series The ISD indoor unit, together with its associated OSA outdoor unit, provides a reverse cycle (heat pump) split system air conditioner designed and developed to comply with and exceed AS/NZS 3823 specified conditions. -
Page 4: Applications
Applications using full or high proportions of fresh air should be High humidity levels can occur in tropical or subtropical conditions, referred to your nearest temperzone sales office to establish the and/or when heavily moisture laden fresh air is introduced. -
Page 5: Control Option
Vertical supply air configuration. Filters - EU4/G4 rated. The standard unit allows for a line length up to 60 m or more ; refer temperzone TZT-100 Room T/stat, or SAT-2 (24V) Controller kit specifications table pages 19 & 20. (for non-digitals). -
Page 6: Plug Fan Advantages
- the system is set up for the EC motor to be controlled variably by a 0–10 volt DC signal that can be supplied either by a BMS system, a sophisticated controller or temperzone's optional TZT-100 Controller. - significant power savings are possible by slowing the fan during low occupancy or after hours (75% airflow ≈... -
Page 7: Performance Data
Ducted Split System Air Conditioners Performance Data COOLING CAPACITY ( KW ) Total = Total Capacity (kW). Note: Capacities are gross and do not include allowance for fan motor heat loss. Capacities Sens. = Sensible Capacity (kW). are for close coupled systems. Interconnecting pipework will reduce capacity. E.A.T. -
Page 8: Indoor Air Flow Correction Factors
Ducted Split System Air Conditioners Performance Data INDOOR AIR FLOW CORRECTION FACTORS @ NOMINAL CONDITIONS Indoor Air Flow (%) -10. Rated Total Capacity 0.95 0.975 1.025 Sensible Capacity 0.89 0.950 1.050 PIPE LENGTH CAPACITY LOSS On Cooling Cycle due to Pressure Drop Note: Loss percentage is approximate only. -
Page 9: Heating Capacity (Kw)
Ducted Split System Air Conditioners Performance Data HEATING CAPACITY ( KW ) G = Gross Heating Capacity kW, based on nominal air flow. N = Net Heating Capacity kW allowing for average defrost. = Nominal Capacity (kW). Indoor Entering Air Models Temp. -
Page 10: Air Handling
Ducted Split System Air Conditioners Performance Data AIR HANDLING Airflows are for a dry coil. Reduce airflow by 10% in high moisture removal conditions. In a free blow or low resistance application, beware of exceeding indoor fan motor’s full load amp limit.. Refer page 11 for Filter Pressure Drop. ISD 380KBY ISD 380KB-P (c/w Plug fans) ISD 380KBY... - Page 11 Ducted Split System Air Conditioners Performance Data AIR HANDLING Airflows are for a dry coil. Reduce airflow by 10% in high moisture removal conditions. In a free blow or low resistance application, beware of exceeding indoor fan motor’s full load amp limit.. ISD 670KB-P (c/w Plug fans) ISD 670KB l/s - Pa...
-
Page 12: Sound Levels
Ducted Split System Air Conditioners Performance Data SOUND LEVELS Sound Power Levels (SWL) Test Conditions: BS 848 PT2 1985. Installation Type A (free inlet and outlet). Direct method of measurement (reverberant room). Measured in decibels re 1 picowatt, at nominal airflow. INDOOR UNIT - SUPPLY AIR OUTLET OCTAVE BAND FREQUENCY Hz Models... - Page 13 Ducted Split System Air Conditioners Performance Data OUTDOOR UNIT OCTAVE BAND FREQUENCY Hz Models FAN SPEED SWL dB(A) SOUND POWER LEVELS dB OSA 380 HIGH OSA 465 HIGH OSA 570 HIGH OSA 670 HIGH OSA 840 HIGH OSA 950 HIGH Sound Pressure Level (SPL) in decibels re 20 µPa.
-
Page 14: Dimensions (Mm)
Ducted Split System Air Conditioners Dimensions (mm) ISD 380KBY INDOOR UNIT Not to Scale 2183 MOUNTING STRAP & OPTIONAL SPRING MOUNTING CENTRES PROJECTION 1706 REFRIGERANT CONNECTIONS CORNER LOADS (kg) OPTIONAL SPRING MTG CTRS Refer matched Outdoor Unit for recommended pipe sizes HOLES 17 ID 2100... - Page 15 Ducted Split System Air Conditioners Dimensions (mm) ISD 465KB INDOOR UNIT Not to Scale 1405 PROJECTION FILTER ACCESS EITHER SIDE ELECTRICAL REFRIGERANT CONNECTIONS CORNER LOADS (kg) Refer matched Outdoor Unit for recommended pipe sizes REFRIGERANT ELECTRICAL CONNECTIONS VERTICAL ACCESS DISCHARGE PANEL MODEL ACCESS PANEL...
- Page 16 Ducted Split System Air Conditioners Dimensions (mm) ISD 570 / 670 KB INDOOR UNIT Not to Scale 1435 FILTER ACCESS EITHER SIDE PROJECTION REFRIGERANT CONNECTIONS CORNER LOADS (kg) Model ISD 570 ISD 670 ELECTRICAL ELECTRICAL Refer matched Outdoor Unit for VERTICAL ACCESS DISCHARGE...
- Page 17 Ducted Split System Air Conditioners Dimensions (mm) ISD 840 / 950 KB INDOOR UNIT Not to Scale 2005 FILTER ACCESS PROJECTION EITHER SIDE ELECTRICAL REFRIGERANT CONNECTIONS DIM. CORNER LOADS (kg) Model ISD 840KB 1070 955 ISD 950KB 1280 1165 Refer matched Outdoor Unit for ELECTRICAL VERTICAL ACCESS...
-
Page 18: Osa Outdoor Units
Ducted Split System Air Conditioners Dimensions (mm) OSA 380RKTB ( G ) OUTDOOR UNIT Not to Scale 500 MIN. CLEARANCE OUTDOOR PROJECTION AIR FLOW ACCESS CORNER LOADS (kg) 1480 PANELS OUTDOOR AIR FLOW Recommended Pipe Sizes 2000 MIN. CLEARANCE 500 MIN. CLEARANCE Suction: 22 mm OD (x2) Liquid: 13 mm OD (x2) - Page 19 Ducted Split System Air Conditioners Dimensions (mm) OSA 570 / 670 RKTB OUTDOOR UNIT 500 MIN. CLEARANCE Not to Scale OUTDOOR AIR FLOW PROJECTION ACCESS PANEL DIM. CORNER LOADS (kg) 1480 Model OSA 570 1345 1263 OSA 670 1390 1231 OUTDOOR AIR FLOW Recommended Pipe Sizes...
- Page 20 Ducted Split System Air Conditioners Specifications System Indoor Unit ISD 380KBY ISD 380KB-P ISD 465KB Outdoor Unit OSA 380RKTB OSA 380RKTB OSA 465RKTVB Nominal Cooling Capacity * 37.6 37.1 44.6 Net Cooling Capacity 36.4 35.9 42.6 Heating Capacity * 38.8 (35.9) 38.5 (35.7) 44.0 EER / AEER (Cooling)
-
Page 21: Specifications
Ducted Split System Air Conditioners Specifications System Indoor Unit ISD 570KB ISD 570KB-P ISD 670KB ISD 670KB-P ISD 840KB ISD 950KB Outdoor Unit OSA 570RKTB OSA 570RKTB OSA 670RKTB OSA 670RKTB OSA 840RKTB OSA 950RKTB Nominal Cooling Capacity * 56.1 56.6 65.9 65.5... - Page 22 Phone +86 (21) 5648 2078 Phone (07) 3308 - 8333 or 1800 - 897 - 253 (07) 3308 - 8330 PERTH Phone (08) 6399 - 5900 AS/NZS (08) 6399 - 5932 ISO 9001: 2015 Available from © temperzone limited 2016 Pamphlet No. 4075 08/16...
