U-CONTROL
UCA202
5. AUDIO CONNECTIONS
Although there are various ways to integrate the UCA202 into your studio or live set-up, the audio
connections to be made will basically be the same in all cases:
5.1 Wiring
Please use standard RCA cables to connect the UCA202 to other audio equipment. You can also use an
adapter cable.
Fig. 5.1: RCA cable
16
5. AUDIO CONNECTIONS
