User’s Manual
Version 1.3
February 2006

Advertisement

Table of Contents
loading

Related Manuals for Behringer EURORACK UB1204-PRO

Summary of Contents for Behringer EURORACK UB1204-PRO

  • Page 1 All manuals and user guides at all-guides.com User’s Manual Version 1.3 February 2006...
  • Page 2 All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of electric shock, do not remove the top cover (or the rear section). No user serviceable parts inside; refer servicing to qualified personnel.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO TABLE OF CONTENTS 1. INTRODUCTION ......................4 1.1 General mixing console functions ........................4 1.2 The user’s manual ............................5 1.3 Before you get started ............................5 1.3.1 Shipment ..............................5 1.3.2 Initial operation ............................

  • Page 4: Introduction

    All other mixer functions can be included in this main function. The interface of BEHRINGER mixing consoles is optimized for these tasks enabling you to easily keep track of the signal path. Uli Behringer...

  • Page 5: The User’S Manual

    2.1.2 Equalizer Should your BEHRINGER product malfunction, our goal is to have it repaired as quickly as possible. To arrange for warranty All mono input channels include a 3-band equalizer. All bands service, please contact the retailer from whom the equipment provide boost or cut of up to 15 dB.

  • Page 6: Aux Sends

    All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO 2.1.4 Routing switch, solo and channel fader Fig. 2.2: The equalizer of the input channels The upper (HI) and the lower band (LO) are shelving filters that increase or decrease all frequencies above or below their cut-off frequency.

  • Page 7: Equalizer Stereo Channels

    All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO 2.3.2 Aux send connectors 1 and 2 For level matching, the stereo inputs feature a LEVEL switch which selects between +4 dBu and -10 dBV. At -10 dBV (home-recording level), the input is more sensitive than at +4 dBu (studio level).

  • Page 8: Stereo Aux Return

    Alternatively, the output signal of a second appropriate signal level. EURORACK or BEHRINGER ULTRALINK PRO MX882 can also be connected. If you connect a hi-fi amplifier with a source selection When recording to a digital device, the recorder’s peak meter switch to the TAPE INPUT, you can easily switch between should not exceed 0 dB.

  • Page 9: Alt 3-4 And Main Mix Fader

    All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO 2.3.7 Alt 3-4 and main mix fader The MODE switch determines whether the channels’ SOLO switch operates as PFL (Pre Fader Listen) or as solo (Solo In Place). To activate the PFL function, depress the MODE switch.

  • Page 10: Voltage Supply, Phantom Power And Fuse

    All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO 2.4.2 Voltage supply, phantom power and fuse 3. DIGITAL EFFECTS PROCESSOR Fig. 2.15: Voltage supply and fuse Fig. 3.1: Digital effects module (only UB1204FX-PRO) The console is connected to the mains via the cable supplied which meets the required safety standards.

  • Page 11: Installation

    All manuals and user guides at all-guides.com EURORACK UB1204 /UB1204FX -PRO -PRO 4. INSTALLATION 4.1 Rack mounting The packaging of your mixing console contains two 19" rack mount wings which can be installed on the side panels of the console. Before you can attach the rack mount wings to the mixing console, you need to remove the screws holding the left and right side panels.

  • Page 12: Specifications

    Impedance approx. 20 kW bal. / 10 kW unbal. BEHRINGER is constantly striving to manintain the highest professional standards. As a Max. input level +22 dBu result of these efforts, modifications may be made from time to time to existing products without prior notice.

  • Page 13: Warranty

    No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER ®...
