3. OPERATING ELEMENTS AND CONNECTIONS
3.1 Front panel
1
LED
2
3
4
Fig. 3.1: Front panel UCA202
The LED indicates the status of the USB power supply.
DIGITAL OUTPUT: The Toslink jack carries an S/PDIF signal which can be connected via a fiber
optic cable, for example, to the digital input of an effects device.
Use the
jack to connect a standard pair of headphones equipped with a 1/8" TRS connector.
