Summary of Contents for Snapper GT600 Series

Page 1 Operator’s Manual Brugsanvisning Bedienungsanleitung Manuel d’utilisation Manuale per l’operatore Gebruikershandleiding Bruksanvisning GT600 Series (CE/Export) Hydro Tractor & Mower Deck Mfg. No. Description 2690634 ESGT27540D, Tractor, 4WD, 3P (CE) 2690667 ESGT27540D, Tractor, 4WD, 3P & 54” Mower (CE) Mower Deck Mfg. No.
Page 2: Table Of Contents
Warranty ......................34 General Information Thank you for purchasing this quality-built SNAPPER riding mower. We’re pleased that you’ve placed your confidence in the SNAPPER brand. When operated and maintained according to the instructions in this manual, your SNAPPER product will provide many years of dependable service.
Page 3: Operator Safety
Operator Safety Important Safety Instructions CaUTION indicates a hazard which, if not avoided, could result in minor or moderate injury. SaVE THESE INSTRUCTIONS - This manual contains im- portant instructions that should be followed during the initial NOTICE indicates a situation that could result in damage set-up, the operation, and the maintenance of the equipment.
Page 4 Safe Operation Practices Operating Safety Power equipment is only as safe as the operator. If it is misused, or not properly maintained, it can be dangerous! Remember, you are responsible for your safety and that of those around you. Use com- mon sense, and think through what you are doing.
Page 5 Slope Operation You could be seriously injured or even killed if you use this unit on too steep an incline. Using the unit on a slope that is too steep or where you don’t have adequate traction can cause you to lose control or roll over. A good rule of thumb is to not operate on any slope you cannot back up (in 2-wheel drive mode).
Page 6 Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects. The triangle in text signifies important cautions or warnings which must be followed.
Page 7 SlOPE OPERaTION WaRNING Slopes are a major factor related to loss-of-control and tip-over accidents, which can result in severe injury or death. Operation Never operate on slopes greater than 17.6 percent on all slopes requires extra caution. If you cannot back up the (10°) which is a rise of 3-1/2 feet (106 cm) vertically in slope or if you feel uneasy on it, do not operate on it.
Page 8 SERVICE aND MaINTENaNCE 12. Do not use gasoline containing METHANOL, gasohol containing more than 10% ETHANOL, gasoline addi- Safe Handling of Gasoline tives, or white gas because engine/fuel system damage 1. Extinguish all cigarettes, cigars, pipes, and other sources could result. of ignition.
Page 9 Safety Decals If any of these decals are lost or damaged, replace them at once. See an authorized dealer for replacements. All DANGER, WARNING, CAUTION and instructional messages on your rider and mower should be carefully These labels are easily applied and will act as a constant visual reminder to you, and others who may use the read and obeyed.
Page 10 Safety Icons Warning: Read Operator’s Danger: Machine Rollover. Manual. Do not use this machine on slopes Read and understand the greater than 10°. Operator’s Manual before using this machine. Danger: Dismemberment. Danger: Thrown Objects. This machine can amputate limbs. This machine is capable of throwing Keep bystanders and children away objects and debris.
Page 11: Features And Controls
Features and Controls Figure 1. Controls Front axle Oil level Plug Choke (Select Models) (4WD Models Only) Close the choke for cold starting. Open the choke once The front axle oil check plug/dipstick is used to check the engine starts. A warm engine may not require chok- the front axle oil level and to add oil to the axle.
Page 12 attachment lift Control lever Ground Speed Pedals When using the mower deck, lift the deck off the ground The tractor’s forward ground speed is controlled by while transporting to and from the job site. DO NOT cut the forward ground speed control pedal. The tractor’s with the mower in the raised, transport position.
Page 13 Differential lock Pedal Transmission Oil level Check Plug Depressing this pedal locks the transmission differential, Transmission oil check plug/dipstick is used to check locking both rear wheels into “drive”. transmission oil level and to add oil to the transmission. See TRANSMISSION MAINTENANCE for oil level check Use this feature if the tractor is stuck because one wheel and fill procedures.
Page 14 Parking Brake Function applying the Parking Brake - See Figure 2. To lock the parking brake, release the ground speed pedals (A), fully depress the brake pedal (B), pull the parking brake knob (C) out, and then release brake pedal. Releasing the Parking Brake - See Figure 2.
Page 15 Dashboard Display Functions The dashboard display (Figure 3) shows a variety of engine operation and control status information, as explained in the descriptions below. a. Irregular Voltage Indicates that the voltage being produced by the charging system and battery is higher or lower than normal levels. B.
Page 16: Operation
Operation adding Fuel Safety Interlock System Tests This unit is equipped with safety interlock switches and To add fuel: other safety devices. These safety systems are present for 1. Remove the fuel cap (A, Figure 4). your safety: do not attempt to bypass safety switches, and 2.
Page 17 Stopping the Tractor & Engine Mowing in Reverse 1. Return the ground speed control(s) to neutral and WaRNING engage the parking brake. 2. Disengage the PTO and wait for all moving parts to The engine will shut off if the reverse ground stop.
Page 18 WaRNING If you cannot back up a hill in 2WD, Do not operate on it. Use extra caution on slopes. To increase traction and provide four-wheel braking, engage mechanical front wheel drive (4WD) when driving on slopes. Be aware that 4WD can improve access to dangerously sloped terrain, thereby increasing the possibility of tipover.
Page 19 Hydraulic System Functions General All of the inboard and auxiliary hydraulics are controlled by the attachment lift control lever. The attachment lift control lever raises and lowers attachments that utilize the tractor’s hydraulic lift cylinder. This lever also controls attachments that use the tractor’s auxiliary hydraulics via the quick couplers on the front left and right sides of the frame.
Page 20 Figure 7. auxiliary Hydraulics Using auxiliary Hydraulics The attachment lift control is also used to control attach- ments that use the tractor’s auxiliary hydraulic couplers located on the right and left front frame rails. The left set of quick couplers is activated when the front / rear hydrau- lic switch is turned to the FRONT position (this disables the inboard hydraulic cylinder).
Page 21 Optional 3-Point Hitch Operation (Select Models) Max. Attachment Weight attachment Weight limit The maximum allowable attachment weight is determined by the gross weight of the attachment verses the distance from the end of the tractor hitch arm to the attachment’s center of gravity (Figure 10).
Page 22 Figure 13. Install Chains Figure 12. Install Sway arms Hitch arms Installation 1. Attach the upper lift link (D, Figure 12) to the hitch using a clevis pin (F) and safety clip (E). 2. Attach the sway arms (A, Figure 12) to the hitch assembly using clevis pins (C) and hair pin clips (B).
Page 23 540 Rear PTO Operation (Select Models) Checks Before Starting Refer to the Maintenance & Adjustments sections of this manual and perform any needed service. Connecting a Drive Shaft 1. Disengage the PTO, set the parking brake, stop the engine, and wait for all moving parts to stop. 2.
Page 24 540 attachment Recommendations STaRT-up and STOpping LOadS GENERal This PTO can be used with direct drive attachments This rear PTO was designed and tested with the 540 that have small start-up and stopping loads like tillers or RPM rear tiller sold by Simplicity Manufacturing. There mower decks.
Page 25 attaching a Trailer The maximum weight of a towed trailer should be less than 800 lbs (363 kg). Secure the trailer with an appropri- ately sized clevis pin (A, Figure 17) and clip (B). Excessive towed loads can cause loss of traction and loss of control on slopes.
Page 26: Maintenance
Maintenance Maintenance Chart TRaCTOR aND MOWER ENGINE Every 8 Hours or Daily First 5 Hours Check safety interlock system Change engine oil Clean debris off tractor and mower deck Every 8 Hours or Daily Clean debris from engine compartment Check engine oil level Every 25 Hours or annually * Every 25 Hours or annually * Check tire pressure...
Page 27 Check Transmission Oil level Do not allow dirt, water, or other debris to enter the expansion chamber or transmission. Even a small amount of dirt can damage the transmission Service Interval: Every 25 Hours Oil Type: Type F Automatic Transmission Fluid 1.
Page 28 Battery Charging Check Mower Blade Stopping Time The mower should come to a complete stop within five seconds after PTO switch is turned off. WaRNING 1. With tractor in neutral, PTO disengaged and operator Keep open flames and sparks away from the in seat, start the engine.
Page 29 Headlight Replacement 1. Open the hood (Figure 22). 2. Remove the forward heat shield. 3. Remove the light bulb socket from the bezel by twist- ing it counterclockwise and pulling it out. 4. Use a rag or gloves to remove and replace the light bulb with an identical halogen bulb.
Page 30: Troubleshooting
Troubleshooting Troubleshooting the Tractor PROBlEM lOOK FOR REMEDY Brake pedal is not Fully depress the brake pedal. depressed. PTO is engaged. Disengage the PTO. Out of fuel. If engine is hot, allow it to cool, then refill the fuel tank. Engine flooded.
Page 31 Troubleshooting the Tractor (Continued) PROBlEM lOOK FOR REMEDY Internal brake worn. See authorized dealer. Brake will not hold. Steering linkage is loose. See authorized dealer. Improper tire inflation. See Check the Tire Pressure section. Tractor steers hard or handles poorly. Front wheel spindle See authorized dealer.
Page 32: Specifications
Specifications ENGINE: TRaNSaxlE: Briggs & Stratton Make Tuff Torq Type K92 Integrated Hydrostatic Pump & Transaxle Make Briggs & Stratton Hydraulic Fluid Type F Automatic Transmission Fluid Model DM 950 D - Model 582447 Capacity 4WD-540: 9.5 qt /9,0 L 58.1 cu in (952 cc) Displacement Speeds...
Page 33: Warranty
For warranty service, find the nearest Authorized Service Dealer using our dealer locator at www.BriggsandStratton.com or www.Snapper.com. There is no other express warranty. Implied warranties, including those of merchantability and fitness for a particular purpose, are limited to one year from purchase or to the extent permitted by law.
