- Page 1 Installation Manual SENTRON 3/6 Bus Plug with Optional SEM3™ Package usa.siemens.com/busway...
- Page 2 AGREEMENT, COMMITMENT OR RELATIONSHIP. THE SALES CONTRACT CONTAINS ALL OBLIGATIONS OF SIEMENS INDUSTRY, INC. THE WARRANTY CONTAINED IN THE CONTRACT BETWEEN THE PARTIES IS THE SOLE WARRANTY OF SIEMENS INDUSTRY, INC. ANY STATEMENT CONTAINED HEREIN DOES NOT CREATE NEW WARRANTIES OR MODIFY THE EXISTING WARRANTIES.
-
Page 3: Table Of Contents
9.0 Additions to the Network 10.0 Contact Information and Support 11.0 Notes 14-17 This document makes frequent reference to both the Storage, Installation and Maintenance Instructions for SENTRON Busway Systems and the SEM3™ – Embedded Micro Metering Module™ User Guide. -
Page 4: Definitions
Real-time values may be viewed on the controller web pages. If Modbus SEM3™ Website: www.usa.siemens.com/SEM3 RTU is required for your application, please contact Siemens Customer Service, (see Section 10.0). Siemens Busway Website: www.usa.siemens/com/busway The controller web interface is used to configure the SEM3™... -
Page 5: Energy Management System
Instructions for SENTRON Busway Systems (Section 11.7) for protection functions. These include applications where the installation and removal procedure of the SENTRON 3/6 Bus devices perform energy limiting functions or provide Plug. If possible, de-energize the busway when installing this protection of people from injury. -
Page 6: Sem3™ Fcc Notice
Communication cables are available in 6, 12, 24, 36, 60, 120 and 240 inch lengths. CAUTION: It is recommended to de-energize the SENTRON busway when installing the communication cables for the Communication cable length for any network should be limited metered bus plugs. - Page 7 RJ45 modular connector). The Ethernet port is capable of data rates up to 100Mbps. TIP: It is generally recommended to balance the number of meter modules connected to ports R1 and R2 on the controller bus plugs. SENTRON 3/6 Bus Plug with Optional SEM3™ Package...
-
Page 8: Other Sem3™ Components
Three and six meter 1) Current Transformers (CTs) for use in the SEM3™ system racks are available in the SENTRON 3/6 Bus Plug. The three and six module racks have a rotary switch to allow them are 100 mA output and are self protecting/shorting. - Page 9 The fusible switch may be used to turn off the controller. Control power for the SEM3™ is tapped off the bus on the line side of the breakers, so metering continues even when the breakers are in the OFF position. SENTRON 3/6 Bus Plug with Optional SEM3™ Package...
-
Page 10: Configuring The Metering System
To start: Connect the controller to a PC using the Ethernet / Modbus TCP port. The port labeled PC is located on the front surface of the control module as shown in Figure 9. Connection to this port requires a CAT6 cable. This PC port may alternately be connected to an Ethernet switch to consolidate multiple ontroller outputs. SEM3™ Metered Bus Plug for SENTRON Busway Systems... -
Page 11: Assign Static Ip Address
2) Then when the Network and Sharing Center opens, click on To confirm, open the command prompt and do an "ipconfig" Change adapter settings. to see if the network adapter settings have been successfully changed. SEM3™ Metered Bus Plug for SENTRON Busway Systems... -
Page 12: Web User Interface
Figure 10: Six Pole Meter Module Rack with 10 Position Rotary controller can monitor is 45 (given cable length restrictions in Switch section 6.3). SEM3™ Metered Bus Plug for SENTRON Busway Systems... - Page 13 *Rotary switch adressing setting of 0 is identical to that of 8, similarly 1 is identical to 9. This means racks with switch settings of 0 and 8 or 1 and 9 cannot be connected to the same controller for the six meter module racks. SEM3™ Metered Bus Plug for SENTRON Busway Systems...
-
Page 14: Sample Network Topology
The rotary switches on the racks are set to unique identifiers for each rack, ranging from 0 in the left-most plug to 7 in the right. The isolated communication cable is "daisy chained" SEM3™ Metered Bus Plug for SENTRON Busway Systems... -
Page 15: Additions To The Network
FOR THE PURCHASER’S PURPOSES, THE MATTER SHOULD additional plug to be uniquely addressed, then a controller BE REFERRED TO THE LOCAL SIEMENS SALES OFFICE OR plug is not required. Simply install the additional plug per CALL 1-800-241-4453 FOR EMERGENCY CUSTOMER Section 6.0. -
Page 16: Notes
Notes: SEM3™ Metered Bus Plug for SENTRON Busway Systems... - Page 17 Notes: SEM3™ Metered Bus Plug for SENTRON Busway Systems...
- Page 18 Notes: SEM3™ Metered Bus Plug for SENTRON Busway Systems...
- Page 19 Notes: SEM3™ Metered Bus Plug for SENTRON Busway Systems...
- Page 20 Siemens Industry, Inc. Subject to change without prior notice 5400 Triangle Parkway Order No. BUIM-SEN36-0516 Norcross, GA 30092 Printed in USA All rights reserved 1-800-241-4453 © 2016 Siemens Industry, Inc. info.us@siemens.com usa.siemens.com/busway...
