ADDICTIVE DESERT DESIGNS®
Preparation:
• Disconnect the negative battery terminal. Park the vehicle on level ground and set the emergency brake.
• We recommend reading through the installation instructions in whole before performing the work.
• Estimated Installation Time: 2 Hours
**This installation requires 2 people for best results**
You will need the following tools:
- Ratchet
- Utility Knife
Included in Kit:
8
- Hex Head Bolts
8
- Nylon Lock Nuts
Removal:
1. From underneath the front driver side of the vehicle, unplug the main fog light and parking sensor harnesses.
(Fig A)
Fig A
2. From underneath the truck, remove the 18mm Nuts (3 per side) holding the bumper to the frame rails. Then,
remove the bumper from the vehicle. (Fig B)
Fig B
Addictive Desert Designs® | Page 1
- 18mm Socket
(3/8-16 x 1")
(3/8"-16)
2009-2018 Ram 1500
ADD Lite™ Front Bumper Installation Instructions
- 9/16" Socket & Wrench
16 - Flat Washers
(3/8")
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADD 2009-2018 Ram 1500 ADD Lite
Summary of Contents for ADD 2009-2018 Ram 1500 ADD Lite
- Page 1 ADDICTIVE DESERT DESIGNS® 2009-2018 Ram 1500 ADD Lite™ Front Bumper Installation Instructions Preparation: • Disconnect the negative battery terminal. Park the vehicle on level ground and set the emergency brake. • We recommend reading through the installation instructions in whole before performing the work.
- Page 2 6. Using a utility knife, trim your inner fender liners to preference. We suggest following a line similar to what is shown in (Fig D). 7. Stand back and enjoy your new ADD Lite Front Bumper. 8. Check and retighten, if needed, all mounting bolts after 100 miles and periodically thereafter.
