SMC Networks CEU2 User Manual

Brake position determination system's, monosashi-kun with brake, controller
Hide thumbs Also See for CEU2:
Table of Contents

Advertisement

Quick Links

Download this manual
Brake Position Determination System's
PRODUCT NAME : MONOSASHI-KUN WITH BRAKE
MODEL
○ Read this operation manual carefully to
understand before installation and operation.
○ Pay extra attention on the clause concerning the
safety.
○ Keep this operation manual available whenever
necessary.
User Guide
: CE2:MONOSASHI-KUN WITH BRAKE
CEU2:CONTROLLER
SMC CORPORATION
DOCUMENT No.: CE*-OMG0104-F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CEU2 and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks CEU2

Summary of Contents for SMC Networks CEU2

  • Page 1 Brake Position Determination System’s User Guide PRODUCT NAME : MONOSASHI-KUN WITH BRAKE MODEL : CE2:MONOSASHI-KUN WITH BRAKE CEU2:CONTROLLER ○ Read this operation manual carefully to understand before installation and operation. ○ Pay extra attention on the clause concerning the safety.

  • Page 2: Table Of Contents

    Contents Read Before Use ··············································································· 1 1. General ························································································ 7 1-1. Features 1-2. Position Control 1-3. Positioning at Stroke End 2. System Configuration ······································································ 8 2-1. System Checking Flow Chart 2-2. System Configuration 2-3. Recommended Circuit Design 3. Specifications ··············································································· 13 3-1.
  • Page 3 9-2. Program Setting 9-2-1 Input Method 9-2-2 Confirmation of Input Data 9-3. Selection of Dip Switch 10. Driving ······················································································· 44 10-1. Setting of Origin Direction 10-2. Adjustment of Air Balance 11. Error Messages & Countermeasures ··············································· 45 11-1. Controller 11-2. Brake Unit’s Life Span 12.

  • Page 4: Read Before Use

    Read before Use These safety instructions are intended to prevent a hazardous situation and/or equipment damage. These instructions indicate the level of potential hazard by label of “Caution”, ”Warning”, or ”Danger”. To ensure safety, follow the instructions below as well as ISO/IEC, JIS and other safety laws ！...
  • Page 5 Operating and Storage Environments catching hands or feet in the machinery, or damage to the machinery itself may occur. Warning ！ 2. Provide a cover to minimize the risk of human injury. 1. Envionments to avoid When a driven object or moving parts of a Avoid using or storing the products in the cylinder may cause the risk of human injury, following...
  • Page 6 8. Consider emergency stops. 35% or less of holding force (Maximum static Design the machinery so that human injury load) and/or damage to machinery and equipment will Note) For applications such as drop prevention, not be caused when machinery is stopped by a consider situations in which the air source safety device under abnormal conditions, a is shut off, and make selections based on...
  • Page 7 ① Operating pressure: the lock. Actuating part: 0.1 – 1.0MPa When the locked stop time is too short, the Braking part: 0.3 – 0.5MPa piston rod may lurch at a speed greater than the ② Fluid & ambient temperature: 0 to 60C control speed of the speed controller.
  • Page 8 Wiring Lubrication Warning Caution ！ ！ 1. Preparation for wiring 1. Lubrication of cylinder Shut off the power before wiring (including ①This cylinder is pre-lubricated and can be used insertion and removal of connectors). Mount a without lubrication. protective cover on the terminal block after ②In case of lubrication, use a equivalent of the wiring.
  • Page 9 cover has to be removed, shut off the power before removal. Welding machine 4. Disposal Request a special agent for handling industrial waste to dispose the products. Operating range 3. Do not pull sensor cable strongly. Such action may cause failure. 4.

  • Page 10: General

    １．General 1-1 Features Controller (CEU2) is a special controller designed for Monosashi-kun with Brake. Upon the input, controller will stop the cylinder, smoothly and precisely at position as inputted. Stopping positions of Monosashi-kun with Brake are stored into “Step”, ranging from step 1 to 32. Steps will be grouped together and form as “Program”.

  • Page 11: Position Control

    2. System Configuration 2-1 System Checking Flow Chart 《CE2 (Monosashi - kun with brake) + CEU2 (Controller)》 Refer to check Flow, showing at next page, to determine brake position, so as to reduce the possibility of occurring errors, which are mostly due to the stopping precision, caused by brake position.
  • Page 12 Start Allowable Kinetic Energy Graph Refer to graph for selection. Whether selected bore size's loading is within allowable φ100 kinetic energy level. φ100 Whether cylinder φ80 speed is within speed level as φ80 shown in allowable φ63 kinetic energy graph. φ63 φ50 φ50...
  • Page 13 Whether magnetic Whether it is Count will field affects the operated at mulfunction and results. environment which control will be out Thus, lead to failure of operation. Whether there is Whether there is Wear or damage on coolant, oil, air, dust protection, such as sensor, packing, etc.

  • Page 14: System Configuration

    2-2 System Configuration １１...

  • Page 15: Recommended Circuit Design

    2-3 Recommended Circuit Design Horizontal Mounting Downward Mounting Upward Mounting <Air Circuit Diagram> Recommended Pneumatic Equipment Directional Brake Speed Bore Regulator Tubing Silencer valve valve Controller φ40 Nylon φ8/6 VFS24□0R VFS21□0 AR425 AN200-02 AS4000-02 φ50 Nylon φ10/7.5 VFS24□0R VFS21□0 AR425 AN200-02 AS4000-02 φ63...

  • Page 16: Specifications

    750mm Brake Type Integrated Pneumatic and Spring φ7－500mm & Oil Resistant Sensor Cord Length & Type Hardware JIS B0209 3-2 Controller Specifications Type CEU2 CEU2P Model Nomenclature Controller Mounting Surface Mounting (Din Rail or Screw) Operating Modes PRESET・PROGRAM・RUN Display Back lighted Display Position Setting Capacity 1－16 Programs, Each Program 1－32 steps...

  • Page 17: Sensor Specifications

    3-3 Sensor Specifications φ7, 6 Core Twisted Pair Shielded Wire Cable (Oil, heat and flame resistance cable) (Connector : R03-R8M, Tajima Musen Denki Company) Max. Transmission Distance 20m (6 core twisted pair shielded wire) Magnetive Scaled Piston Rod & Detection Head Position Detection Method (50cm Cable, Incremental Type) Magnetive Field Resistance...

  • Page 18: Model

    Range of manufacturable stroke Tube Bore(mm) Without Gaiter With Gaiter Without Gaiter With Gaiter 25～850 25～700 1200 25～800 25～650 1150 1150 25～800 25～650 25～750 25～600 1100 25～750 25～600 1100 4-2 Controller CEU2 Output Method None NPN Open Collector PNP Open Collector １５...

  • Page 19: Extension Cable

    4-3 Extension Cable CE1-R Length of Cable Postscript None Extension Cable Extension Cable + Connector Connector’s Connection Symbol Core Wire Color White Yellow C , D Brown, Blue Black (Shield) １６...

  • Page 20: External Dimension Drawing

    5. External Dimension Drawing 5-1 Monosashi-kun with Brake １７...
  • Page 21 １８...

  • Page 22: Controller

    5-2 Controller １９...

  • Page 23: Extension Cable

    5-3 Extension Cable ２０...

  • Page 24: Part Identification

    6. Part Identification 6-1 Monosashi-kun with Brake １ ４ ５ ６ ７ ９ 1１ １０ ①Piston Rod ②Cover ③Pin Guide ④Rod Cover ⑤Sensor Cover ⑥Cylinder Tube ⑦Tie Rod ⑧Head Cover ⑨Cushion Valve ⑩Connector ⑪Cable ①External Input Terminal ②Sensor Input Terminal ③AC Power Supply Input Terminal ④Earth Terminal ⑤DC Input Terminal...

  • Page 25: Installation & Wiring

    7. Installation & Wiring 7-1 Installation 7-1-1 Installation of Cylinder 1. During installation of metal fitting onto the end (screw thread) of piston rod, prevent from the induction of impact and unbalance loading acting upon it. 2. During mounting of cylinder and load, care should be taken not to give misalignment non twist. Please attach floating joint between the connection.
  • Page 26 * Note 1. Clamp and fix the connector and sensor connection to reduce tension acting on them. 2. Separate cable with power line to prevent from the occurring of noise. 3. When cable is necessary to have U bend, set the bending radius to be above 25mm. Bending Ability: According to drawing shown below, life span 4 million cycles or more can be achieved.

  • Page 27: Input Signal's Wiring

    7-3 Input Signal Wiring 7-3-1 Input Signal Wiring Diagram ２４...

  • Page 28: Input Signal Content

    7-3-2 Input Signal Content Start･･･････････Once started, setting position will be inputted. One step of movement per one shot (above 50msec). Note: Start signal (above 50msec’s signal) will be received and activated to carry out subsequence step, only if homing has been performed and origin signal has been fed back to controller.

  • Page 29: Input Signal Wiring

    Signal’s name: Position Detected, Origin Calculated, Program End, Error Maximum terminal Voltage: DC +30V Maximum Current: 50mA (0℃～50℃) Output Internal’s Circuit Connection Method Model NPN Output Transistor Controller: CEU2 Load DC +30V , 50mA CEU2 Controller: CEU2P PNP Output Transistor Load...

  • Page 30: Solenoid Valve Wiring

    7-3-5 Solenoid valve’s wiring Solenoid valve Driving Output consists of 3 signals. +5v together with photo-coupler is in isolation state. Signal’s name: Brake, Driving A & B Maximum terminal’s Voltage +24V DC Maximum current 80mA (0℃～50℃) Solenoid Output’s internal Circuit is shown below. External Supply ＋24V...

  • Page 31: Timing Chart

    8. Timing Chart Homing Timing Chart (Input) Reset Homing (*3) MIN50msec SetHome Man'l / Auto Start Program Selection Man'l (+) Man'l (-) (Output) Driving(+) Driving(-) Brake (*1) Origin Determined (*2) Position Determined (*2) Program END (*1) Error Cylinder Movement Origin POWER ON Note: Homing will be executed only on RUN mode and during automatic executing.
  • Page 32 Automatic Executing’s Timing Chart (Input) Reset Homing SetHome Man'l / Auto MIN50msec(*2) Start Program Selection Man'l (+) Man'l (-) (Output) Driving(+) Driving(-) Brake Origin Determined Position Determined (*1) (*1) (*1) Program END Error Cylinder Movement Origin Note: After starting, program selection is not valid until program END. Perform program selection before inputting START signal.
  • Page 33 Automatic Execution Timing Chart (Activation of Manual mode during motion) (Input) Reset Homing SetHome Man'l / Auto MIN50msec(*2) Start Program Selection Man'l (+) Man'l (-) (Output) Driving(+) Driving(-) Brake Origin Determined Position Determined (*1) (*1) Program END (*1) Error Cylinder Movement Origin Note: If Manual mode or Run Mode is activated during Auto Mode, motion will stop.
  • Page 34 Manual Executing Timing Chart (Input) Reset Homing SetHome Man'l / Auto Start Program Selection Man'l (+) Man'l (-) (Output) Driving(+) Driving(-) Brake Origin Determined Position Determined (*1) (*1) Program END Error Cylinder Movement Origin Note: During manual operation, Start signal is not effective. Pressing Man’l (+) and Man’l (-) together will not take effect too.
  • Page 35 Pause during homing Timing Chart (Input) Reset MIN50msec(*2) Homing SetHome Man'l / Auto Start Man'l (+) Man'l (-) Pause (Output) Driving(+) Driving(-) Brake Origin Determined (*1) Position Determined (*1) Program END Error Cylinder Movement Origin POWER ON Note: Homing will be executed, only on RUN mode and during automatic executing. (*1) Timing from stopping till output is the preset timing t1 (preset data P7).
  • Page 36 Pause during Automatic Execution Timing Chart (Input) Homing SetHome Man'l / Auto Start Program Selection Man'l (+) Man'l (-) Pause (Output) Driving (+) Driving (-) Brake Origin Determined (*1) (*1) Position Determined Program END (*1) Error Cylinder Movement Origin Note: During manual operation, Pause is effective less. (*1)Timing from stopping till output is 0.2sec (max).
  • Page 37 Emergency Stop (Automatic Execution) Timing Chart (Input) Homing SetHome Man'l /Auto Start Program Selection Man'l (+) Man'l (-) Pause (Output) Driving(+) Driving(-) Brake Origin Determined (*1) Position Determined (*1) Program END (*1) Error (*2) Cylinder Movement Origin Note: When Emergency Stop is set to be ON, error will be also set ON. Vice versa. Therefore, the display of error does not really show that error output.
  • Page 38 Data Error (Program free of error) Timing Chart Program No.1 Data Error (or no) Program No.2 Data Normal (or error) (Input) Reset Homing SetHome Man'l / Auto MIN50msec(*2) Start Program Selection Program No1 Program No2 Man'l (+) Man'l (-) (Output) Driving(+) Driving(-) Brake...

  • Page 39: Data Setting

    9. Data Setting 9-1 Data Presetting 9-1-1 Data Classification & Content P1―Cylinder Stroke Input stroke. P2―Tolerance Input positioning tolerance range. Retries will assure the positioning within the tolerance range. P3―Retries Input no. of retries. Maximum retries will be 9. Since Err9 (positioning error) will appear and the system will stop when positioning is not able to be set within the range, it is advisable to set the max.
  • Page 40 Press either READ or WRITE to proceed to the input ＰＲＧ ＳＴＥＰ Ｐ １ condition for cylinder stroke setting. The first decimal point will start to blink. ″ １０００．０ 〟 Use LEFT and RIGHT buttons to select digit to be changed and set the digit to the desired setting through UP and DOWN buttons.
  • Page 41 During initial setup, predictive control is executing. Hence, it is suggested to set the maximum retries to 5 or above. ＰＲＧ ＳＴＥＰ Ｐ ４ After setting of maximum retries, press WRITE to switch to the next input condition. The display will ″...

  • Page 42: Confirmation Of Set Data

    After reviewing of number of brake operation, press ＰＲＧ ＳＴＥＰ Ｐ ７ WRITE to switch to next input operation. The display will indicate PRG STEP P7 and present origin ″ detection time. ２００ 〟 Next, enter desired origin detection time. The setting range is 0～9.99sec (1 unit as 10msec).
  • Page 43 9-2 Program Setting Input desired cylinder positions. 9-2-1 Input Method Turn the controller switching mode to PROGRAM. Note: ″ ＰＲＧ １ ＳＴＥＰ ０ 〟 Step 0 for every program is END. Ｅｎｄ Program no. “1” will start blinking. Set the program no. through UP & DOWN buttons. 点滅...
  • Page 44 <Input example> 　　　　　Program Step 50.0 68.0 300.0 30.5 30.0 Turn the controller switching mode to PROGRAM. ″ Press WRITE 2 times. ＰＲＧ １ ＳＴＥＰ ０ 〟 The display “End” will be replaced by “0000.0”, leading to the input STEP 1. Ｅｎｄ...
  • Page 45 Press WRITE one time. ＰＲＧ １ ＳＴＥＰ ３ Press LEFT 2 times to shift the blinking cursor. ″ ００００．０ 〟 Blinking Press UP 3 times to set the value of 3. ＰＲＧ １ ＳＴＥＰ ３ ″ ００３０．０ 〟 Blinking ＰＲＧ １ ＳＴＥＰ...
  • Page 46 ＰＲＧ ８ ＳＴＥＰ １ First, press LEFT one time. Next, use DOWN to set the value of “8”. ″ ００６８．０ Press LEFT one time. 〟 Then, use DOWN to set the value of “6”. Blinking ＰＲＧ ８ ＳＴＥＰ ２ Press WRITE one time. Press UP 5 times to set the value of “5”.
  • Page 47 9-3 Selection of Dip Switch No.1･･･The Identification of Origin OFF････When cylinder stops, if there is no signal feedback from sensor within t1 (Preset data,P7), counter value will be reseted to “0” and origin is obtained / recognized. Generally, origin will be at the stroke end. If origin is set within the stroke, install stopper with respect to the origin.
  • Page 48 Therefore, do not cut off power supply, even during interchanging of battery. [Replacement in Japan] The part No. of the replacement battery assembly is CEU2-H0125. Please refer to the Battery assembly replacement procedure CE*-OMM0038-* for replacement. Or please prepare a battery equivalent to the following conditions and purchase a replacement battery holder assembly (Part No.: CEU2-H0446) from SMC.Please refer to the Battery assembly...
  • Page 49 Err4: Backup Error Content : After power supply is on or Reset signal is inputted, backup checking is conducted, error is detected during output. Each and individual data is checked through backup checking. Once, error is detected, clear the error and at the same time, data will be deleted too.
  • Page 50 Stopping Point Braking Point Setting Point Braking Point Next Stopping Point Stopping Point There is no braking point within the moving distance. Solution : Reset or re-providing power supply. Countermeasure : Verify air balancing. Verify whether there is any impact or momentum acting upon cylinder during positioning.
  • Page 51 Solution : Press either ON or RESET. When ON is used to remedy situation, next program step will be executed. However, Err5 will occur if the stopping position when Err9 occurs, is less than 5mm away from the next program step’s specified value. In this case, homing should be done.
  • Page 52 12. Appendix 12-1 Data Sheet ● Parameter Preset Data Dip Switch Setting Data Name Setting Cylinder Stroke No.1 OFF　　ON Tolerence No.2 OFF　　ON Retries No.3 OFF　　ON Bore Size No.4 OFF　　ON Load Rate No. of Brake Operation Origin Confirmation Time Err12's Confirmation Time ●Program Data (Determined Position Data) Program Step...
  • Page 53 Program Step ５０...
