1
HRW***-* -Y
2
DI control kit (optional)
Operation Manual
Applicable model: Series HRW
(Thermo Chiller)

Introduction

Thank you very much for purchasing DI control kit for our Thermo Chiller, Series HR W .
This manual is for operators who have enough knowledge for general industrial equipment and devices, and al so
thoroughly understand assembling, handling, and maintenance of them. Before assembling, handling, a nd
maintenance, read and understand this manual and the one for Thermo Chiller, Series HRW carefull y.
Installing of accessories has to be performed by a customer according to this manua l.
Refer to the operation manual for Thermo Chiller for warrant y.
This manual is subject to change without prior notic e .
Summary of option
- It is possible to control the electric resistance of circulating fluid as you like by using an ion exchange resin filt
(hereafter DI filter) and electric resistance meter (hereafter DI sensor ).
- DI filter is not attached. Purchase our HRZ-DF001 separately if you need. If the DI filter is used at temperature out of
the range, 20 to 40degC, also purchase a thermal insulator, HRZ-DF002, to prevent frostbite and a bur n.

Safety instruction

- Understand the meaning of the following signs before reading the body of this manual, and keep the instructio
Indication
Meaning
! Warning
Operator error could result in serious injury or loss of lif e.
Operator error could result in injury or equipment damag e .
Caution
!
  Warning
!
- Before using, understand the specification range thoroughly.
This product is designed as an option for Thermo Chiller, Series HRW. Do not use this product for the oth er
purpose, or outside of the specification rang e .
- Understand the contents of this manual and the working procedure thoroughly.
Understand this manual and the one for Thermo Chiller (Document no: HRX-OM-K003) thoroughly. Ke ep
this operation manual so that you can refer whenever necessar y.
- Do not perform installation work while power is on.
Perform lock-out and tag-out of the power securely. Otherwise, Thermo Chiller may operate unexpectedl y.
- Perform installation work without any circulating fluid in Thermo Chiller.
Perform the work before supplying circulating fluid in or after exhausting all the circulating fluid fr om
Thermo Chiller. The circulating fluid shoud be exhausted after the fluid gets to be ambient temperatur e.
Otherwise, an operator may get a burn or frostbit e.
  Caution
!
- Do not disassemble or modify.
Otherwise it may cause leakage and operation failur e .
- Confirm there is no leakage or condensation after installation.
Confirm there is no leakage or condensation with Thermo Chiller operated. If leakage is found, stop Ther mo
Chiller immediately.
Things to prepare
Spanner (width across flats: (1) 9/16 inch, (2) 1/2 inch, (3) 5/8 inch, (4) 11/16 inch )
1
HRX-OM-K018-B

Accessory installation

Introduction
Refer to the accessory list on the back, and confirm the number of the accessory. In addition, confirm the
model no. plate on the body has "-Y" indication, which is symbol for this optio n.
Fig. 1
Procedure 1
er
Confirm that a nut, a ferrule, and an insert are installed at the end of the DI tube for IN (Fig. 1). Insert the DI tu be
for IN to the end of the DI circuit Supply, and tighten the nut by hand. At that time, use two spanners, (1) and (2 ),
not to rotate the self-align fitting. Turn the hand-tightened nut by 1/4 rotatio n.
Procedure 2
Confirm that a nut, a ferrule, and a insert are installed at the end of the DI tube for OUT (Fig. 1). Insert the DI tu be
for OUT to the end of the DI circuit RETURN, and tighten the nut by hand. At that time, use two spanners, (3) a nd
n.
(4), not to rotate the self-align fitting. Turn the hand-tightened nut by 1/4 rotatio n.
DI tube for OUT
Fig. 2
3
Procedure
Mount a therml insulator for DI filter as shown at Fig. 2, and set it in the drain pan (only for the customers who purchas
it).
Procedure 4
Supply circulating fluid from IN side of the DI filter to exhaust air. Continue to supply until OUT side is fill ed
with circulating fluid.
Procedure 5
Connect the DI tube for OUT and DI tube for IN to OUT side and IN side of the DI filter respectively. As the DI
tube has a strainer and a packing at the DI filter connection part, be careful not to drop them (Refer to Fig. 3 ).
Procedure 6
Perform trial operation in accordance with Thermo Chiller operation manual, HRX-OM-K003. Initially, the DI
filter has water. If ethylene glycol solvent is used, the concentration may be decreased. Confirm the concentrati
after the trial operation. The proper concentration of ethylene glycol is 60%. If no leakage is found, install a
insulator to a ball valve connected to the DI tube, and fix it with a band (Refer to Fig. 4).
Insert
Ferrule
Nut
Circulating fluid Supply
DI circuit Return
(DI tube connecting port for OUT)
DI circuit Supply
(DI tube connecting port for IN)
Circulating fluid Return
DI tube for IN
Fig. 3
Fig. 4
on
2
Indication on the operation display pan el
When shipped
Indication
Set range
from factory
DI PV
-
-
DI level at the circulating fluid Supply, measured by the DI sens or
DI SP
0 to 20Mohm
0.5Mohm
Setting for DI level
DI ACC
Yes/No
No
Accumulated ON time of the solenoid valve (accumulated fluid-running time through the DI filte r)
DI SV
ON/OFF
-
Status of the solenoid valve (ON=open, OFF=close d )
DI HYS
0 to 0.9Mohm
0.3Mohm
Refer to "DI HYS" below.
When the DI level gets lower than the setting, an indication "DI L O W
LOW DI
0 to 20Mohm
0.0Mohm
LEVEL WRN" will be shown, and a buzzer will be given of f.
If the setting has "0.0", no alarm will be given of f.
DI HYS
DI SP
DI LEVEL
Operation
condition
Solenoid
valve

Operation with operation display panel

(1) Setting of DI SP

Plate a cursor on "DI SP" on the screen "Setting", and press [ENT] key. Set the value to the one you desi re
with [ ], [ ], and [ ] keys. After setting the value, press [ENT] ke y .

(2) Setting of DI HYS

Set a cursor on "DI HYS" on the screen "Initial setting 4", and press [ENT] key. Set the value to the one y ou
desire with [ ], [ ], and [ ] keys. After setting the value, press [ENT] ke y.

(3) Setting of DI level lowering alarm (LOW DI)

Set a cursor on "LOW DI" on the screen "Initial setting 4", and press [ENT] key. Set the value to the one y ou
desire with [ ], [ ], and [ ] keys. After setting the value, press [ENT] ke y .

(4) Reset of DI ACC

Press [ ] and [ ] keys while the screen "DI ACC reset" is shown, and select [YES]. Then, press [ENT] ke y.

(5) Status of DI circuit

You can confirm it on the screen "Status 3 ".
External communincati on
Only DI PV can be output by external communication (serial RS-485). Refer to the separate manua l,
"Communication Specification/ HRX-PS-K005", for detail. If analog communication (option) is us ed
refer to "Communication Specification/HRX-PS-K018 " .
Operation panel sequence
SEL
     <MENU>
 Thermo Chiller
1.SETTING
 HRW□□□-□□-Y
2.REMOTE/LOCAL
    Rev.□□□
3.INITIAL SET
    SMC Co.
Model indication
TEMP PV    23.8℃
     <MENU>
FLOW PV  20.0LPM
4.MAINTENANCE
PRESS    0.85MPa
5.OPTION
R.TEMP     23.8℃
ed
Status 1
SEL
ENT
TEMP PV    23.8℃
 <MAINTENANCE>
TEMP SV    25.0℃
1.DI ACC RESET
OFFSET      0.0℃
2.VALUE OPEN
OFFSET:      OFF
Status 2
SEL
ENT
 <DI ACC RESET>
DI PV      1.0MΩ
DI SP      0.5MΩ
DI ACC        0h
DI ACC        0h
DI SV        OFF
DATA RESET? No
Status 3
© 2006 SMC CORPORATION All Rights Reserved
3
Description
DI HYS
Operation
Stop
ON(open)
OFF(closed)
SEL
   <SETTING>
TEMP SP    25.0℃
DI SP      0.5MΩ
Menu 1
Setting
SEL
 <INITIAL SET>
OFFSET      0.0℃
OFFSET:      OFF
HIGH TEMP    93℃
Menu 2
Initial setting 1
 <INITIAL SET>
LOW FLOW    0LPM
FLOW  UNIT   LPM
PRESS UNIT   MPa
Maintenance
Initial setting 2
 <INITIAL SET>
SLAVE ADRS.  1CH
OUT:         N/A
E OUT:       N/A
DI ACC reset
Initial setting 3
 <INITIAL SET>
DI HYS     0.3MΩ
LOW DI     0.0MΩ
F.LOW  TEMP  10℃
Initial setting 4
