Summary of Contents for Wildfire EffectsMaster EM-22L
- Page 1 Operation Manual Ultraviolet LED Lighting Fixtures EM-44L EM-42L EM-22L...
-
Page 2: Table Of Contents
Table of Contents Introduction Safety Information Specifications Setup and Operation Unpacking Optional Accessories Setup Maintenance & Troubleshooting Lamp Replacement Cleaning Troubleshooting Diagrams Isometric & Line Views EM-22L Isometric & Line Views EM-42L Isometric & Line Views EM-44L Exploded View & Part List EM-22L Exploded View &... -
Page 3: Introduction
Introduction Congratulations on your purchase of an Effects Master LED Series Fixture by Wildfire. These powerful and versatile ultraviolet LED lighting fixtures feature Wildfire’s SableLED UV LED tube lamps. Each Effects Master LED Fixture is precision engineered to provide you with years of trouble free service. Please take a moment to read this manual thoroughly before attempting to operate this fixture. -
Page 4: Specifications
IP Rating: IP-20 Indoor use Warranty: Three Year Parts and Labor Standard Equipment: Wildfire SableLED UV LED Tube Lamps, Adjustable Mounting Brackets, Power Cord, PowerCON Power Out Cable Connector Optional Accessories: Twenty Clamp (147-021) Safety Cable (147-002) Floor Mount (147-006) -
Page 5: Setup And Operation
Setup & Operation Unpacking Unpack the fixture and carefully inspect it for any signs of physical damage. Report any damage to Wildfire or your local distributor immediately. Included with each unit should be the following items: 1. Power Cord 2. PowerCON power output cable connector (used to power link additional fixtures) 3. -
Page 6: Maintenance & Troubleshooting
Maintenance & Troubleshooting LED Lamp Replacement Turn the power switch to the off position and unplug the fixture. If this is not possible then steps should be taken that would allow the fixture to remain in an off state while re-lamping. Holding the lamp firmly with two hands, one hand near each end of the lamp, rotate the lamp about its long center-line axis, one quarter (1/4) turn either clockwise or counter-clockwise. -
Page 7: Diagrams
Diagrams Isometric & Line Views EM-22L 27.375" 24.125" 4.25" 5.00"... -
Page 8: Isometric & Line Views Em-42L
Diagrams Isometric & Line Views EM-42L 51.375" 48.125" 4.25" 5.00"... -
Page 9: Isometric & Line Views Em-44L
Diagrams Isometric & Line Views EM-44L 51.375" 48.125 " 4.25" 6.50"... -
Page 10: Exploded View & Part List Em-22L
Exploded View & Part List EM-22L QTY. PART # PART NAME PART # PART NAME QTY. 104-064-03 Housing, Effects Master 2' 142-001 Lamp, LED, SableLED, T9, BLB, 24”, 15W 104-059-03 Cover, Housing, Side 121-033 Kepnut, 4-40, 18-8 SS 121-005 Screw, M, PHL, PH, 6-32 x 1/4" 18-8 SS 121-003 Screw, M, PHL, PH, 4-40 x 3/8”... -
Page 11: Exploded View & Part List Em-42L
Exploded View & Part List EM-42L QTY. PART # PART NAME PART # PART NAME QTY. 104-065-07 Housing, 4' 104-004-01 Bracket, Lens Retaining (Optional Lens Kit) 104-059-03 Cover, Housing, Side 124-016-01 Lens, Clear, UVT, 4’ x 4 3/4” (Optional Lens Kit) 121-005 Screw, M, PHL, PH, 6-32 x 1/4"... -
Page 12: Exploded View & Part List Em-44L
Exploded View & Part List EM-44L QTY. PART # PART NAME QTY. PART# PART NAME Housing Effects Master VHO 104-066-06 121-017 Screw, SM, PHL, PH, #8 x 3/8”, 18-8 SS Cover Housing Side VHO 104-060-03 141-002 Lamp, LED, SableLED, T9, BLB, 48”, 30W Screw, M, PHL, PH, 6-32 x 1/4”... -
Page 13: Schematic Em-22L
Schematic, LED Series EM-22L AC INPUT AC OUTPUT POWER SWITCH BLACK WHITE GREEN... -
Page 14: Schematic Em-42L
Schematic, LED Series EM-42L AC INPUT AC OUTPUT POWER SWITCH BLACK WHITE GREEN... -
Page 15: Schematic Em-44L
Schematic, LED Series EM-44L AC INPUT AC OUTPUT POWER SWITCH BLACK WHITE GREEN... -
Page 16: Spectral Output Graph
Spectral Output Graph VISIBLE LIGHT UV-B UV-A WAVELENGTH /NM Photometrics Chart Model EM-44L Model EM-42L Distance in Feet / Meters Distance in Feet / Meters Beam Diameter Feet 17.3 34.6 69.3 103.9 138.6 173.2 207.8 242.5 277.1 Beam Diameter Feet 17.3 34.6 69.3... -
Page 17: Limited Warranty
Wildfire, Inc. Three Year Limited Warranty Wildfire, Inc. warrants to the original owner or retail customer, that for a period of three years from the date of delivery of any Wildfire Fixture; whether used in a portable or permanent installation, such fixtures will be free from defects in material and workmanship under normal use and conditions. - Page 18 2908 Oregon Ct. Suite G1, Torrance, CA 90503 P: 310.755.6780 800.937.8065 F: 310.755.6781 wildfirelighting.com mail@wildfirelighting.com 2017 Wildfire, Inc. 215-011-03...
