Product Manual
Cheetah NS 10K.2 FC
ST3600002FC
ST3450802FC
ST3300602FC
100516227
Rev. B
July 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHEETAH NS 10K.2 FC ST3600002FC and is the answer not in the manual?

Questions and answers

Related Manuals for Seagate CHEETAH NS 10K.2 FC ST3600002FC

Summary of Contents for Seagate CHEETAH NS 10K.2 FC ST3600002FC

  • Page 1 Product Manual Cheetah NS 10K.2 FC ST3600002FC ST3450802FC ST3300602FC 100516227 Rev. B July 2009...
  • Page 2 In addition, some of the listed capacity is used for formatting and other func- tions, and thus will not be available for data storage. Seagate reserves the right to change, without notice, product offerings or specifications.

  • Page 3: Table Of Contents

    Scope............... . 1 Standards, compliance and reference documents .
  • Page 4 6.4.2 Relative humidity ..........32 6.4.3 Effective altitude (sea level) .
  • Page 5 Seagate Technology support services ........
  • Page 6 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 7: Scope

    Cheetah NS 10K.2 FC drives support the Fibre Channel Arbitrated Loop and SCSI Fibre Channel Protocol specifications to the extent described in this manual. The Fibre Channel Interface Manual (part number 100293070) describes the general Fibre Channel Arbitrated Loop characteristics of this and other Seagate Fibre Channel drives.
  • Page 8 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 9: Standards, Compliance And Reference Documents

    Mounting by bottom holes must meet the requirements of Section 8.4. Standards The Cheetah NS 10K.2 FC family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate Fibre Channel Interface Manual, part number 100293070.

  • Page 10: Compliance

    • External modem • Mouse Although the test system with this Seagate model complies with the directives/standards, we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide the appropriate marking for their product.

  • Page 11: Reference Documents

    Specification for 40-pin SCA-2 Connector with Parallel Selection Specification for 40-pin SCA-2 Connector with Bidirectional Enclosure Services Interface (SCSI-2) (SCSI-3) Architecture Model (SCSI-3) Enclosure Services Seagate part number: 30553-001 Seagate P/N 30190-001 (under 100 lb.) Seagate P/N 30191-001 (over 100 lb.)
  • Page 12 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 13: General Description

    General description Cheetah NS 10K.2 FC drives provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. Cheetah NS 10K.2 FC drives support 4-Gbit Fibre Channel which can transfer data at up to 800 Mbytes per second and 1600 Mbytes per second in dual-loop configurations.

  • Page 14: Standard Features

    Standard features Cheetah NS FC drives have the following standard features: • Perpendicular recording technology • 4-Gbit Fibre Channel interface • Integrated dual port FC-AL controller • Concurrent dual port transfers • Support for FC arbitrated loop, private and public attachment •...

  • Page 15: Performance

    1,132,015,600 1,115,749,556 2. Seagate drives also may be used at the maximum available capacity at a given sector size, but the excess capacity above the guaranteed level will vary between 10K and 15K families and from generation to gener- ation, depending on how each sector size actually formats out for zone frequencies and splits over servo bursts.

  • Page 16: Programmable Drive Capacity

    Programmable drive capacity Using the Mode Select command, the drive can change its capacity to something less than maximum. See the Mode Select Parameter List table in the SCSI Commands Reference Manual. Refer to the Parameter list block descriptor number of blocks field. A value of zero in the number of blocks field indicates that the drive shall not change the capacity it is currently formatted to have.

  • Page 17: Performance Characteristics

    Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Cheetah NS 10K.2 FC drives. Internal drive characteristics ST3600002FC Drive capacity* Read/write data heads Tracks per inch 165,000 Peak bits per inch 1,347 Areal density Internal data rate 1.01 to 1.84 disk rotation speed Avg rotational latency...

  • Page 18: Format Command Execution Time (Minutes)

    4.2.2 Format command execution time (minutes) ST3600002FC Maximum (with verify) Maximum (without verify) Execution time measured from receipt of the last byte of the Command Descriptor Block (CDB) to the request for a Status Byte Transfer to the Initiator (excluding connect/disconnect). When changing sector sizes, the format times shown above may need to be increased by 30 minutes.

  • Page 19: Prefetch/Multi-Segmented Cache Control

    Prefetch/multi-segmented cache control The drive provides a prefetch (read look-ahead) and multi-segmented cache control algorithms that in many cases can enhance system performance. Cache refers to the drive buffer storage space when it is used in cache operations. To select this feature, the host sends the Mode Select command with the proper values in the applicable bytes in page 08h.

  • Page 20: Caching Write Data

    4.5.1 Caching write data Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored while the drive performs the Write command. If read caching is enabled (RCD=0), then data written to the medium is retained in the cache to be made avail- able for future read cache hits.

  • Page 21: Reliability Specifications

    Reliability specifications The following reliability specifications assume correct host and drive operational interface, including all inter- face timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Read Error Rates Recovered Data Unrecovered Data Miscorrected Data Interface error rate: Mean Time Between Failures (MTBF) Annualized Failure Rate (AFR): Preventive maintenance:...

  • Page 22: Seek Errors

    5.1.3 Seek errors A seek error is defined as a failure of the drive to position the heads to the addressed track. After detecting an initial seek error, the drive automatically performs an error recovery process. If the error recovery process fails, a seek positioning error (Error code = 15h or 02h) will be reported with a Hardware error (04h) in the Sense Key.

  • Page 23: Controlling S.m.a.r.t

    The Pass-through state is disabled while the drive performs self test of the FC interface. The control line for an external port bypass circuit remains in the Enable Bypass state while self test is running. If the bypass circuit is present, loop operation may continue.

  • Page 24: Thermal Monitor

    Reporting control Reporting is controlled by the MRIE bits in the Informational Exceptions Control mode page (1Ch). Subject to the reporting method, the firmware will issue to the host an 01-5Dxx sense code. The error code is preserved through bus resets and power cycles. Determining rate S.M.A.R.T.

  • Page 25: Drive Self Test (Dst)

    DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive.
  • Page 26 A Drive Not Ready condition is reported by the drive under the following conditions: • Motor will not spin • Motor will not lock to speed • Servo will not lock on track • Drive cannot read configuration tables from the disk In these conditions, the drive responds to a Test Unit Ready command with an 02/04/00 or 02/04/03 code.

  • Page 27: Product Warranty

    Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure.
  • Page 28 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 29: Physical/Electrical Specifications

    Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the drive. AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector.
  • Page 30 Table 3: DC power requirements for ST3450802FC model Voltage Regulation Avg idle current DCX Maximum starting current (peak DC) DC 3σ (peak AC) AC 3σ Delayed motor start (max) DC 3σ Peak operating current: Typical DCX Maximum DC 3σ Maximum (peak) DC 3σ...
  • Page 31 Table 4: DC power requirements for ST3300602FC model Voltage Regulation Avg idle current DCX Maximum starting current (peak DC) DC 3σ (peak AC) AC 3σ Delayed motor start (max) DC 3σ Peak operating current: Typical DCX Maximum DC 3σ Maximum (peak) DC 3σ...

  • Page 32: Conducted Noise Immunity

    6.2.1 Conducted noise immunity Noise is specified as a periodic and random distribution of frequencies covering a band from DC to 10 MHz. Maximum allowed noise values given below are peak-to-peak measurements and apply at the drive power connector. +5 V = 250 mV pp from 0 to 100 kHz to 20 MHz.
  • Page 33 Figure 2. Typical ST3450802FC drive, 4 Gbit, +5V and +12V current profiles Cheetah NS 10K.2 FC Product Manual, Rev. B...
  • Page 34 Figure 3. Typical ST3300602FC drive, 4 Gbit, +5V and +12V current profiles Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 35: Power Dissipation

    Power dissipation ST3600002FC Typical power dissipation under idle conditions in 4 Gbit operation is 6.55 watts (22.33 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
  • Page 36 ST3450802FC Typical power dissipation under idle conditions in 4 Gbit operation is 5.92 watts (20.21 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
  • Page 37 ST3300602FC Typical power dissipation under idle conditions in 4 Gbit operation is 5.50 watts (18.76 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.

  • Page 38: Environmental Limits

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 86°F (30°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp.

  • Page 39: Effective Altitude (Sea Level)

    6.4.3 Effective altitude (sea level) a. Operating –1,000 to +10,000 feet (–305 to +3,048 meters) b. Non-operating –1,000 to +40,000 feet (–305 to +12,192 meters) 6.4.4 Shock and vibration Shock and vibration limits specified in this document are measured directly on the drive chassis. If the drive is installed in an enclosure to which the stated shock and/or vibration criteria is applied, resonances may occur internally to the enclosure resulting in drive movement in excess of the stated limits.
  • Page 40 >600 cu in (>9,800 cu cm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.

  • Page 41: Acoustics

    There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive.

  • Page 42: European Union Restriction Of Hazardous Substances (Rohs) Directive

    6.4.8 European Union Restriction of Hazardous Substances (RoHS) Directive Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. A new law, the European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances, including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006.

  • Page 43: Mechanical Specifications

    Mechanical specifications Refer to Figure 9 for detailed physical dimensions. See Section 8.4, “Drive mounting.” Height (max): 1.013 in Width (max): 3.999 in Depth (max): 5.769 in Weight (max): 1.482 pounds Figure 9. Mounting configuration dimensions Cheetah NS 10K.2 FC Product Manual, Rev. B 25.73 mm 101.57 mm 146.53 mm...
  • Page 44 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 45: Defect And Error Management

    SCSI defect and error management involves drive internal defect/error management and FC system error con- siderations (errors in communications between the initiator and the drive). In addition, Seagate provides the following technologies used to increase data integrity and drive reliability: •...
  • Page 46 The drive firmware error recovery algorithms consists of 11 levels for read recoveries and five levels for write. Each level may consist of multiple steps, where a step is defined as a recovery function involving a single re- read or re-write attempt. The maximum level used by the drive in LBA recovery is determined by the read and write retry counts.

  • Page 47: Fc-Al System Errors

    FC-AL system errors Information on the reporting of operational errors or faults across the interface is given in the Fibre Channel Interface Manual. The FCP Response returns information to the host about numerous kinds of errors or faults. The Receive Diagnostic Results reports the results of diagnostic operations performed by the drive. Status returned by the drive to the initiator is described in the Fibre Channel Interface Manual.

  • Page 48: Deferred Auto-Reallocation

    DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location.

  • Page 49: Installation

    Installation Cheetah NS 10K.2 FC disk drive installation is a plug-and-play process. There are no jumpers, switches, or terminators on the drive. Simply plug the drive into the host’s 40-pin Fibre Channel backpanel connector (FC- — SCA) no cables are required. See Section 9.5 for additional information about this connector. Use the FC-AL interface to select drive ID and all option configurations for devices on the loop.

  • Page 50: Drive Mounting

    (F) is applied to the fourth point. Before mounting the drive in any kind of 3.5-inch to 5.25-inch adapter frame, verify with Seagate Note.

  • Page 51: Grounding

    Grounding Signal ground (PCBA) and HDA ground are connected together in the drive and cannot be separated by the user. The equipment in which the drive is mounted is connected directly to the HDA and PCBA with no electri- cally isolating shock mounts. If it is desired for the system chassis to not be connected to the HDA/PCBA ground, the systems integrator or user must provide a nonconductive (electrically isolating) method of mount- ing the drive in the host equipment.
  • Page 52 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 53: Interface Requirements

    Interface requirements This section partially describes the interface requirements as implemented on Cheetah NS 10K.2 FC drives. Additional information is provided in the Fibre Channel Interface Manual (part number 100293070). FC-AL features This section lists the Fibre Channel-specific features supported by Cheetah NS 10K.2 FC drives. 9.1.1 Fibre Channel link service frames Table 6 lists the link services supported by Cheetah NS 10K.2 FC drives.

  • Page 54: Fibre Channel Task Management Functions

    9.1.2 Fibre Channel task management functions Table 7 lists the Fibre Channel SCSI Fibre Channel Protocol (FC SCSI FCP) task management functions sup- ported. Table 7: Fibre Channel SCSI FCP task management functions Task name Supported Terminate task Clear ACA Target reset Clear task set Abort task set...

  • Page 55: Fibre Channel Port Login

    9.1.4 Fibre Channel port login Table 9 identifies the required content of the N_Port Login (PLOGI) payload from an initiator. Table 9: N_Port login (PLOGI) payload Bytes 0-15 16-31 32-35 36-47 48-51 52-63 64-67 68-79 80-83 84-95 96-99 100-111 112-115 Indicates a four-bit (hex) field is not checked.

  • Page 56: Fibre Channel Port Login Accept

    9.1.5 Fibre Channel port login accept Table 10 identifies the N_Port Login access payload values. Table 10: N_Port Login Accept (ACC) payload Bytes 0-15 16-31 32-35 36-47 48-51 52-63 64-67 68-79 80-83 84-95 96-99 100-111 112-115 Bytes (22, 23 and 24) and (30, 31 and 32) are currently factory set to 00 04 CF respectively (subject to change). Receive buffer field size.

  • Page 57: Fibre Channel Process Login Accept

    9.1.7 Fibre Channel Process Login Accept Table 12 lists Cheetah NS 10K.2 FC process login accept payload data. Table 12: Process Login Accept (ACC) payload Bytes 0-15 16-31 9.1.8 Fibre Channel fabric login Table 13 lists the fabric login payload from the drive. Table 13: Fabric Login (FLOGI) payload Bytes...

  • Page 58: Fibre Channel Fabric Accept Login

    9.1.9 Fibre Channel fabric accept login Table 14 lists the required content of the Fabric Login Accept (ACC) payload from the fabric. Table 14: Fabric Login Accept (ACC) payload Bytes 0-15 16-31 32-35 36-47 48-51 52-63 64-67 68-79 80-83 84-95 96-99 100-111 112-115 XX...

  • Page 59: Fibre Channel Arbitrated Loop Options

    9.1.10 Fibre Channel Arbitrated Loop options Table 15 lists the FC-AL options supported by Cheetah NS 10K.2 FC drives. Table 15: FC-AL options supported Option Supported OPEN Half Duplex Accepted from another device. OPEN Full Duplex Sent to open another device. Accepted from another device. Private Loop Public Loop Old Port State...

  • Page 60: Scsi Commands Supported

    SCSI commands supported Table 16 lists the SCSI commands supported by Cheetah NS 10K.2 FC drives. Table 16: Supported commands Command code Supported [4] Command name Test unit ready Rezero unit Request sense Extended sense Field pointer bytes Actual retry count bytes Format unit [1] Reassign blocks Read...
  • Page 61 Table 16: Supported commands (continued) Command code Supported [4] Cheetah NS 10K.2 FC Product Manual, Rev. B Command name Verify error recovery page (07h) Caching parameters page (08h) Control mode page (0Ah) Fibre Channel Interface Control page (19h) Power control page (1Ah) Information exceptions control page (1Ch) Background Scan mode subpage (01h) Start unit/stop unit...
  • Page 62 Table 16: Supported commands (continued) Command code Supported [4] 42-4Bh Command name Search data low Set limits Prefetch Synchronize cache Lock-unlock-cache Read defect data Compare Copy and verify Write buffer Write combined header and data mode (0) Write data mode (2) Download microcode mode (4) Download microcode and save modes (5) Download microcode with offsets mode (6)
  • Page 63 Table 16: Supported commands (continued) Command code Supported [4] 4E-4Fh 53-54h 58-59h 5B-5Dh 60-7Fh 83-8Fh C0-DFh EO-FFh Cheetah NS 10K.2 FC drives can format to 512, 520, 524 or 528 bytes per logical block. Warning. Power loss during flash programming can result in firmware corruption. This usually makes the drive inoperable.

  • Page 64: Inquiry Data

    9.3.1 Inquiry data Table 17 lists the Inquiry command data that the drive should return to the initiator per the format given in the Fibre Channel Interface Manual. Table 17: Cheetah NS 10K.2 FC inquiry data Bytes Data (hex) 0-15 xx** 16-31 32-47...

  • Page 65: Current Values

    On standard OEM drives, the saved values are taken from the default values list and stored into the saved values storage location on the media prior to shipping. 3. Current values Current values are volatile values being used by the drive to control its operation. A Mode Select command can be used to change the values identified as changeable values.
  • Page 66 Table 18: Mode Sense data saved, default and changeable values for ST3600002FC drives MODE DATA HEADER 00 00 05 12 8B 00 70 02 MODE SENSE PAGES DATA DEF 80 06 00 80 0F 00 00 00 CHG 80 06 B7 C0 8F 00 00 00 DEF 81 0A C0 0B FF 00 00 00 05 00 FF FF CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF DEF 82 0E 80 80 00 00 00 00 00 00 01 3A 00 00 00 00...
  • Page 67 Table 19: Mode Sense data default and changeable values for ST3450802FC drives MODE DATA HEADER 00 00 05 12 8B 00 70 02 MODE PAGES DEF 80 06 00 80 0F 00 00 00 CHG 80 06 B7 C0 8F 00 00 00 DEF 81 0A C0 0B FF 00 00 00 05 00 FF FF CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF DEF 82 0E 80 80 00 00 00 00 00 00 01 3A 00 00 00 00...
  • Page 68 Table 20: Mode Sense data default and changeable values for ST3300602FC drives MODE DATA HEADER 00 00 05 12 8B 00 50 02 MODE PAGES DEF 80 06 00 80 0F 00 00 00 CHG 80 06 B7 C0 8F 00 00 00 DEF 81 0A C0 0B FF 00 00 00 05 00 FF FF CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF DEF 82 0E 80 80 00 00 00 00 00 00 01 3A 00 00 00 00...

  • Page 69: Miscellaneous Operating Features And Conditions

    Miscellaneous operating features and conditions Table 21 lists various features and conditions. A “Y” in the support column indicates the feature or condition is supported. An “N” in the support column indicates the feature or condition is not supported. Table 21: Miscellaneous features Supported Feature or condition...

  • Page 70: Fc-Al Physical Interface

    FC-SCA connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s Fibre Channel drives are provided in the Fibre Channel Interface Manual.. J1 interface connector Figure 11.

  • Page 71: Connector Requirements

    9.5.2 Connector requirements The FC-AL SCA device connector is illustrated in Figure 13. Figure 13. FC-AL SCA device connector dimensions 9.5.3 Electrical description Fibre Channel drives use the FC-SCA connector for: • DC power • FC-AL interface • Drive select (device identification) •...

  • Page 72: Fc-Al Transmitters And Receivers

    Table 23: FC-SCA pin descriptions Signal name Signal type -EN bypass port A Low Voltage TTL output 12 Volts 12 Volts 12 Volts -Parallel ESI Ground Active LED out Open collector out Reserved Start_1 TTL input Start_2 TTL input -EN bypass port B Low Voltage TTL output SEL_6 TTL input/output...

  • Page 73: Power

    9.5.6 Power Power is supplied through the FC-SCA with support for +5 volts and +12 volts. All of the voltage pins in the drive connector are the same length. Four 12 volt pins provide +12 volt power to the drive. The current return for the +12 volt power supply is through the common ground pins.

  • Page 74: Active Led Out

    9.5.8 Active LED Out The Active LED Out signal is driven by the drive as indicated in Table 24. Table 24: Active LED Out conditions Normal command activity Spun down and no activity Spun down and activity (command executing) Spun up and no activity Spun up and activity (command executing) Spinning up or down Format in progress...

  • Page 75: Sel_6 Through Sel_0 Id Lines

    Table 25: Motor start control signals Case Start_2 Start_1 High High 9.5.11 SEL_6 through SEL_0 ID lines The SEL_6 through SEL_0 ID lines determine drive address, and, optionally, for an Enclosure Services Inter- face. When the Parallel ESI line is high, the enclosure backpanel must provide address information on the SEL line.
  • Page 76 Table 26: Arbitrated loop physical address (AL_PA) values AL_PA SEL ID Setting (hex) (hex) (dec) AL_PA SEL ID Setting (hex) (hex) (dec) Cheetah NS 10K.2 FC Product Manual, Rev. B AL_PA SEL ID Setting (hex) (hex) (dec)

  • Page 77: Device Control Codes

    9.5.12 Device control codes The drive inputs a Device Control Code on the DEV_CTRL_CODE lines at power up to determine the link rate on the Fibre Channel ports. Both ports run at the same rate. If the backpanel does not connect to these lines, the drive has 10K ohm pull up resistors that default the device control code to 7 (1.0625 GHz).

  • Page 78: Led Driver Signals

    9.6.2 LED driver signals Fault and Active LED signals are located in the FC-SCA connector (J1). See Table 29 for the output character- istics of the LED drive signals. Table 29: LED drive signal State Current drive available LED off, high 0 <...
  • Page 79 Figure 16 provides the data valid eye diagram for typical and minimum requirements to recover data at the specified interface error rate. The inputs are AC coupled on the drive. 941 ps 659 ps 376 ps Figure 16. Receive eye diagram Table 32: Eye diagram data values Link rate...
  • Page 80 Cheetah NS 10K.2 FC Product Manual, Rev. B...

  • Page 81: Seagate Technology Support Services

    Global Customer Support Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com or through one of our call...

  • Page 82: Usa/Canada/Latin America Support Services

    Seagate Customer Service Operations (CSO) representative for warranty- related issues. Resellers or end users of drive products should contact their place of purchase or Seagate war- ranty service for assistance. Have your serial number and model or part number available.
  • Page 83 Index Numerics 12 volt pins 67 3rd party reserve command 57 5 volt pins 67 Abort Sequence (ABTS) 47 abort task set function 48 AC coupling 66 AC power requirements 23 ACA active status 63 ACA active, faulted initiator status 63 Accept (ACC) 47 acoustics 35 active LED Out signal 68...
  • Page 84 DAR 42 data block size modifing the 9 data heads read/write 11 data rate internal 11 data transfer rate 12 data valid eye 73 Date code page command 54 DC power 65 requirements 23 defect and error management 39 defects 39 Deferred Auto-Reallocation 42 deferred error handling 63 description 7...
  • Page 85 corruption 57 Firmware download option command 56 Firmware numbers page command 54 flawed sector reallocation 8 FLOGI received on Port A 51 received on Port B 51 Force unit access command 55 form factor 8 format 43 Format command execution time 12 Format page (03h) command 54 Format unit command 54 FS 49...
  • Page 86 Parameter rounding 63 Queue tagging 63 Reporting actual retry count 63 Segmented caching 63 SMP = 1 in Mode Select command 63 Synchronized (locked) spindle operation 63 Zero latency read 63 miscellaneous status support ACA active 63 ACA active, faulted initiator 63 Busy 63 Check condition 63 Condition met/good 63...
  • Page 87 Prefetch command 56 prefetch/multi-segmented cache control 13 preventive maintenance 15 private loop FC-AL options 53 Proc Assc 49 Process Accept (ACC) 51 Process Login (PRLI) 47 Process Login Accept (ACC) payload 51 process login payload data 50 Process Logout (PRLO) 47 programmable drive capacity 10 public loop FC-AL options 53...
  • Page 88 single-unit shipping pack kit 10 SMART 9 SMP = 1 in Mode Select command 63 SO 49 spindle brake 8 Stacked connection req. 49 standards 3 Start unit/stop unit command 55 start/stop time 12 support services 75 Supported diagnostics pages command 55 surface stiffness allowable for non-flat surface 44 switches 43...
  • Page 90 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100516227, Rev. B, Printed in USA...
