Seagate Cheetah ST3450657SS Product Manual

Hide thumbs Also See for Cheetah ST3450657SS:
Table of Contents

Advertisement

Quick Links

Download this manual
Product Manual
Cheetah
15K.7 SAS
®
Standard models
ST3600057SS
ST3450857SS
ST3300657SS
100516226
Rev. F
December 2012
Self-Encrypting Drive models
ST3600957SS
ST3450757SS
ST3300557SS
SED FIPS 140-2 models
ST3600857SS
ST3450657SS
ST3300457SS

Advertisement

Table of Contents
loading

Related Manuals for Seagate Cheetah ST3450657SS

Summary of Contents for Seagate Cheetah ST3450657SS

  • Page 1 Product Manual Cheetah 15K.7 SAS ® Standard models Self-Encrypting Drive models ST3600057SS ST3600957SS ST3450857SS ST3450757SS ST3300657SS ST3300557SS SED FIPS 140-2 models ST3600857SS ST3450657SS ST3300457SS 100516226 Rev. F December 2012...
  • Page 2 Publication number: 100516226, Rev. F December 2012 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Cheetah and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.

  • Page 3: Table Of Contents

    ONTENTS ® T ......... . 1 EAGATE ECHNOLOGY UPPORT...
  • Page 4 ONTENTS 6.2.2 Power sequencing ..........21 6.2.3 Current profiles.
  • Page 5 ONTENTS 11.4 ......47 ISCELLANEOUS OPERATING FEATURES AND CONDITIONS 11.4.1 SAS physical interface ..........47 11.4.2 Physical characteristics .

  • Page 6: Seagate Technology Support Services

    Authorized Service Centers For information regarding Warranty Support, visit http://www.seagate.com/support/warranty-and-returns/ For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit https://direct.seagate.com/portal/system For Seagate reseller portal, visit http://spp.seagate.com Cheetah 15K.7 SAS Product Manual, Rev. F...

  • Page 7: Scope

    Cheetah 15K.7 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of Cheetah 15K.7 and other Seagate SAS drives. The Self-Encrypting Drive (SED) Users Guide, part number 100515636 describes the interface, general operation and security features available on SED drives.

  • Page 8: Standards , Compliance And Reference Documents

    Mounting by bottom holes must meet the requirements of Section 10.3. TANDARDS The Cheetah 15K.7 SAS family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071.

  • Page 9: Uropean Nion Estriction Of Azardous Ubstances Hs)

    Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our supplier contracts require compliance with our chemical substance restrictions, and our suppliers document their compliance with our requirements by providing material content declarations for all parts and materials for the disk drives documented in this publication.

  • Page 10: General Description

    ENERAL DESCRIPTION Cheetah 15K.7 drives provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. The Serial Attached SCSI interface is designed to meet next-generation computing demands for performance, scalability, flexibility and high-density storage requirements. Cheetah 15K.7 drives support the Serial Attached SCSI Protocol as described in the ANSI specifications, this document, and the SAS Interface Manual (part number 100293071) which describes the general interface characteristics of this drive.

  • Page 11: Standard Features

    TANDARD FEATURES Cheetah 15K.7 drives have the following standard features: • 1.5 / 3 / 6 Gbit Serial Attached SCSI (SAS) interface • Integrated dual port SAS controller supporting the SCSI protocol • Support for SAS expanders and fanout adapters •...

  • Page 12: Reliability

    Seagate designs specify capacity points at certain block sizes that Seagate guarantees current and future products will meet. We recommend customers use this capacity in their project planning, as it ensures a stable operating point with backward and forward compatibility from generation to generation.

  • Page 13: Performance Characteristics

    ERFORMANCE CHARACTERISTICS This section provides detailed information concerning performance-related characteristics and features of Cheetah 15K.7 drives. NTERNAL DRIVE CHARACTERISTICS ST3600057SS ST3450857SS ST3300657SS ST3600957SS ST3450757SS ST3300557SS ST3600857SS ST3450657SS ST3300457SS Drive capacity Gbytes (formatted, rounded off value) Read/write data heads Tracks per inch 165,000 165,000 165,000...

  • Page 14: General Performance Characteristics

    4.2.3 General performance characteristics Sustainable disk transfer rate*: Minimum 122 Mbytes/sec (typical) Maximum 204 Mbytes/sec (typical) SAS Interface maximum instantaneous transfer rate 600 Mbytes/sec* per port Logical block sizes Default is 512-byte data blocks Sector sizes variable to 512, 520, and 528 kbytes. Read/write consecutive sectors on a track Flaw reallocation performance impact (for flaws reallocated at format time using Negligible...

  • Page 15: Cache Operation

    ACHE OPERATION Note. Refer to the SAS Interface Manual for more detail concerning the cache bits. Of the 16 Mbytes physical buffer space in the drive, approximately 13,000 kbytes can be used as a cache. The buffer is divided into logical segments from which data is read and to which data is written. The drive keeps track of the logical block addresses of the data stored in each segment of the buffer.

  • Page 16: Caching Write Data

    4.5.1 Caching write data Write caching is a write operation by the drive that makes use of a drive buffer storage area where the data to be written to the medium is stored while the drive performs the Write command. If read caching is enabled (RCD=0), then data written to the medium is retained in the cache to be made available for future read cache hits.

  • Page 17: Reliability Specifications

    ELIABILITY SPECIFICATIONS The following reliability specifications assume correct host and drive operational interface, including all interface timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Less than 10 errors in 10 seeks Read Error Rates Recovered Data Less than 10 errors in 10 bits transferred (OEM default settings) Unrecovered Data...

  • Page 18: Annualized Failrue Rate (Afr) And Mean Time Between Failure (Mtbf)

    5.2.1 Annualized Failrue Rate (AFR) and Mean time between failure (MTBF) These drives shall achieve an AFR of 0.55% (MTBF of 1,600,000 hours) when operated in an environment that ensures the HDA case temperatures do not exceed the values specified in Section 6.4. Operation at case temperatures outside the specifications in Section 6.4 may increase the AFR (decrease the MTBF).

  • Page 19: Thermal Monitor

    Performance impact S.M.A.R.T. attribute data is saved to the disk so that the events that caused a predictive failure can be recreated. The drive measures and saves parameters once every two hours subject to an idle period on the drive interfaces. The process of measuring off-line attribute data and saving data to the disk is uninterruptable.

  • Page 20: Drive Self Test (Dst)

    If DST encounters an error during either of these tests, it reports a fault condition. If the drive fails the test, remove it from service and return it to Seagate for service. 5.2.6.1 DST failure definition The drive will present a “diagnostic failed”...
  • Page 21 DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive.

  • Page 22: Product Warranty

    Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure.

  • Page 23: Physical / Electrical Specifications

    HYSICAL ELECTRICAL SPECIFICATIONS This section provides information relating to the physical and electrical characteristics of the drive. POWER REQUIREMENTS None. POWER REQUIREMENTS The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector. The standard drive models and the SED drive models have identical hardware, however the security and encryption portion of the drive controller ASIC is enabled and functional in the SED models.
  • Page 24 Table 4 450 GB DC power requirements BIT MODE BIT MODE OTES Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current [1] [7] 0.39 0.68 0.41 0.66 Maximum starting current (peak DC) DC 3σ 0.65 1.94 0.67...
  • Page 25 Table 5 300 GB DC power requirements BIT MODE BIT MODE OTES Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current [1] [7] 0.34 0.58 0.35 0.58 Maximum starting current (peak DC) DC 3σ 0.53 1.92 0.54...

  • Page 26: Conducted Noise Immunity

    General DC power requirement notes. 1. Minimum current loading for each supply voltage is not less than 1.7% of the maximum operating current shown. 2. The +5V and +12V supplies should employ separate ground returns. 3. Where power is provided to multiple drives from a common supply, careful consideration for individual drive power requirements should be noted.
  • Page 27 Figure 2. Typical 450GB current profiles Figure 3. Typical 300GB current profiles 15K.7 SAS P HEETAH RODUCT ANUAL...

  • Page 28: Power Dissipation

    OWER DISSIPATION model 600GB Typical power dissipation under idle conditions in 6Gb operation is 11.62 watts (39.65 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.

  • Page 29: Environmental Limits

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 68°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. 15K.7 SAS P...

  • Page 30: Relative Humidity

    DA T emp Check Point Figure 7. Location of the HDA temperature check point 6.4.2 Relative humidity The values below assume that no condensation on the drive occurs. a. Operating 5% to 95% non-condensing relative humidity with a maximum gradient of 20% per hour. b.

  • Page 31: Shock And Vibration

    36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.
  • Page 32 Figure 8. Recommended mounting 6.4.4.2 Vibration a. Operating—normal The drive as installed for normal operation, shall comply with the complete specified performance while subjected to continuous vibration not exceeding 10 – 300 Hz 1.0 G RMS (0 to peak) 301– 500 Hz 0.5 G RMS (0 to peak) Vibration may be applied in the X, Y, or Z axis.

  • Page 33: Acoustics

    There will not be any discrete tones more than 10 dB above the masking noise on typical drives when measured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive.

  • Page 34: Electromagnetic Susceptibility

    6.4.9 Electromagnetic susceptibility See Section 2.1.1.1. ECHANICAL SPECIFICATIONS Refer to Figure 9 for detailed physical dimensions. See Section 10.3, “Drive mounting.” Height: 1.03 in 26.10 mm Width: 4.00 in 101.60 mm Depth: 5.79 in 147 mm Weight (max): 1.76 pounds 0.80 kilograms 26.11 MAX (1.028 MAX)

  • Page 35: About Fips

    FIPS 140-2 Level 2 requirements. In order to operate in FIPS Approved Mode of Operation, these SEDs require security initialization. For more information, refer to 'Security Rules' section in the 'Security Policy' document uploaded on the NIST website - Cert# 1299: Seagate Secure® Enterprise Self-Encrypting Drives FIPS 140 Module: http://csrc.nist.gov/groups/ STM/cmvp/documents/140-1/140val-all.htm...

  • Page 36: About Self - Encrypting Drives

    The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SCSI commands: •...

  • Page 37: Drive Locking

    In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1.

  • Page 38: Defect And Error Management

    SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive). In addition, Seagate provides the following technologies used to increase data integrity and drive reliability: •...

  • Page 39: Sas System Errors

    Table 6 Read and write retry count maximum recovery times [1] RITE EAD RETRY AXIMUM RECOVERY TIME PER AXIMUM RECOVERY TIME PER RETRY COUNT CUMULATIVE MSEC CUMULATIVE MSEC COUNT 51.87 23.94 59.85 35.91 203.49 39.9 231.42 51.87 295.26 79.8 327.18 5 (default) 107.73 359.10...

  • Page 40: Background Media Scan

    DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location.

  • Page 41: Installation

    10.0 I NSTALLATION Cheetah 15K.7 disk drive installation is a plug-and-play process. There are no jumpers, switches, or terminators on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive.

  • Page 42: Drive Mounting

    Above unit Under unit Note. Air flows in the direction shown (back to front) or in reverse direction (front to back) Above unit Under unit Note. Air flows in the direction shown or in reverse direction (side to side) Figure 11. Air flow 10.3 RIVE MOUNTING...

  • Page 43: Interface Requirements

    11.0 I NTERFACE REQUIREMENTS This section partially describes the interface requirements as implemented on Cheetah 15K.7 drives. Additional information is provided in the SAS Interface Manual (part number 100293071). 11.1 FEATURES This section lists the SAS-specific features supported by Cheetah 15K.7 drives. 11.1.1 task management functions Table 7 lists the SAS task management functions supported.

  • Page 44: Scsi Commands Supported

    11.3 SCSI COMMANDS SUPPORTED Table 9 lists the SCSI commands supported by Cheetah 15K.7 drives. Table 9 Commands supported by Cheetah 15K.7 SAS family drives Command name Command code Supported Change Definition Compare Copy Copy and Verify Format Unit [1] DPRY bit supported DCRT bit supported STPF bit supported...
  • Page 45 Table 9 Commands supported by Cheetah 15K.7 SAS family drives (continued) Command name Command code Supported Start-stop Cycle Counter page (0Eh) Temperature page (0Dh) Verify Error Counter page (05h) Write error counter page (02h) Mode Select (same pages as Mode Sense 1Ah) Y [2] Mode Select (10) (same pages as Mode Sense 1Ah) Mode Sense...
  • Page 46 Table 9 Commands supported by Cheetah 15K.7 SAS family drives (continued) Command name Command code Supported Reserve (10) 3rd Party Reserve Extent Reservation Rezero Unit Search Data Equal Search Data High Search Data Low Seek Seek Extended Send Diagnostics Supported Diagnostics pages (00h) Translate page (40h) Set Limits Start Unit/Stop Unit (spindle ceases rotating)

  • Page 47: 11.3.1 Inquiry Data

    11.3.1 Inquiry data Table lists the Inquiry command data that the drive should return to the initiator per the format given in the SAS Interface Manual. Table 10 Cheetah 15K.7 inquiry data YTES 0-15 xx** Vendor ID 16-31 Product ID 32-47 48-63 64-79...
  • Page 48 4. Changeable values Changeable values form a bit mask, stored in nonvolatile memory, that dictates which of the current values and saved values can be changed by a Mode Select command. A one (1) indicates the value can be changed. A zero (0) indicates the value is not changeable.
  • Page 49 11.3.2.1 600GBmodel Mode Sense data MODE DATA HEADER: 01 6e 00 10 00 00 00 08 BLOCK DESCRIPTOR: 45 dd 2f b0 00 00 02 00 MODE PAGES: DEF 81 0a c0 0b ff 00 00 00 05 00 ff ff CHG 81 0a ff ff 00 00 00 00 ff 00 ff ff DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
  • Page 50 11.3.2.2 450GB model Mode Sense data MODE DATA HEADER: 01 76 00 10 00 00 00 08 BLOCK DESCRIPTOR: 34 65 f8 70 00 00 02 00 MODE PAGES: DEF 81 0a c0 0b ff 00 00 00 05 00 ff ff CHG 81 0a ff ff 00 00 00 00 ff 00 ff ff DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
  • Page 51 11.3.2.3 300GB model Mode Sense data MODE DATA HEADER: 01 76 00 10 00 00 00 08 BLOCK DESCRIPTOR: 22 ec b2 5c 00 00 02 00 MODE PAGES: DEF 81 0a c0 0b ff 00 00 00 05 00 ff ff CHG 81 0a ff ff 00 00 00 00 ff 00 ff ff DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...

  • Page 52: Miscellaneous Operating Features And Conditions

    Figure 12 shows the location of the SAS device connector J1. Figures 13 and 14 provide the dimensions of the SAS device. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.. SAS Interface connector Figure 12.
  • Page 53 0.80 (6X) 5.92 7.62 4.65 0.52 0.08 x 45 2.00 (3X) 0.45 0.03 (7X) 5.08 0.10 M E 42.73 REF. 41.13 0.15 0.20 B 0.30 0.05 (2X) 1.10 4.00 0.08 C OF DATUM D 0.15 D R0.30 0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43...
  • Page 54 Detail A 6.10 0.30 0.05 x 45 (5X) 2.25 0.05 0.40 0.05 X 45 (3X) 4.85 0.05 0.10 B CORING ALLOWED IN THIS AREA. 4.40 0.15 R0.30 0.08 SEE Detail 2 1.95 0.08 0.35 0.05 SECTION C - C 3.90 0.15 SECTION A - A CONTACT SURFACE FLUSH...

  • Page 55: 11.4.2 Physical Characteristics

    11.4.2 Physical characteristics This section defines physical interface connector. 11.4.3 Connector requirements The SAS connector on the drive complies with SFF-8482. Contact your preferred connector manufacturer for mating part information. The SAS device connector is illustrated in Figures 13 and 14. 11.4.4 Electrical description SAS drives use the device connector for: •...

  • Page 56: 11.4.6 Sas Transmitters And Receivers

    11.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 15. The receiver is AC coupling to eliminate ground shift noise. Figure 15. SAS transmitters and receivers 11.4.7 Power The drive receives power (+5 volts and +12 volts) through the SAS device connector. Three +12 volt pins provide power to the drive, 2 short and 1 long.

  • Page 57: 11.5.2 Differential Signals

    DDITIONAL INFORMATION Please contact your Seagate representative for SAS electrical details, if required. For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068.
  • Page 58 NDEX Numerics check condition status 47 chemical pollutants 28 12 volt Cipher Block Chaining 31 pins 51 class B limit 3 5 volt pins 51 clear ACA function 38 6 Gbps 52 clear task set function 38 commands supported 39 abort task set function 38 condensation 25 AC coupling 51...
  • Page 59 signal characteristics 51 inquiry data 42 specifications 18 installation 36 electromagnetic compatibility 3 interface electromagnetic susceptibility 29 commands supported 39 EMI requirements 3 error rate 12 encryption engine 31 errors 12 encryption key 32 illustrated 47 environment 36 physical 47 environmental requirements 38 limits 24...
  • Page 60 18 SAS Interface Manual 3 peak-to-peak measurements 21 SCSI interface performance characteristics commands supported 39 detailed 8 Seagate Technology Support Services 1 general 9 Secure ID 31 performance degradation 26 security partitions 31 performance highlights 6 Security Protocol In 31...
  • Page 61 shipping 17 shipping container 24 zero latency read 47 shock 26 zone bit recording (ZBR) 6 and vibration 26 shock mount 37 SID 31 signal characteristics 51 single-unit shipping pack kit 7 SMART 7 SMP = 1 in Mode Select command 47 SNW-3 training gap 52 spindle brake 6 standards 3...
  • Page 62 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100516226, Rev.
