Unitech TB160 Service Manual

10.1” rugged tablet computer
Hide thumbs Also See for TB160:
Table of Contents

Advertisement

Quick Links

See also: User Manual
10.1" Rugged Tablet Computer
- TB160 -
Service Manual
Version 1.1
© 2017 unitech Electronics Co., Ltd. All rights reserved.
unitech is a registered trademark of unitech Electronics Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TB160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unitech TB160

Summary of Contents for Unitech TB160

  • Page 1 10.1” Rugged Tablet Computer - TB160 - Service Manual Version 1.1 © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 2 Revision History Date Change Description Version 2017/12/29 first published version 2018/1/4 Update TB160-Work Instruction © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 3: Table Of Contents

    3.1 How to install Recovery SW via SD card ..........17 Appendix I – Worldwide Support............22 Worldwide Support ..................22 © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 4: Chapter 1 - Overall Looks

    Chapter 1 – Overall Looks 1.1 Product Detail TB160 Front View Left view Front view Rear view Right view Rubber bumpers Bottom view © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 5 Wi-Fi LED F2 key (Programmable function key) FN LED F1 key (Programmable function key) Home key FN key (Programmable function key) © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 6 TB160 User’s Manual TB160 Rear View Battery Rear camera Barcode reader NFC sensing area Securing holes Expansion bay Stylus holder © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 7 Left I/O compartment cover DC-IN Jack Tether hole RS-232 USB 2.0 DC-IN cover Battery switch Right I/O compartment cover Micro SIM slot © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 8 TB160 User’s Manual Docking connector Kensington lock Pass-through © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 9: Chapter 2 - Assembly

    BOARD VER:1.0 ASS'Y W/KITS LR_75-20279-01 spare parts IPC BOARD PM-521(TB160) NFC+USB 607117G BOARD VER:1.0 ASS'Y W/KITS LR_75-20450-01 spare parts 不含 RF cable & FFC © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 10 (EOL) LAN WIRELESS UNIT IEEE 802.11a/c + BT4.0 PCIE Half Mini Card 607140G AC 7260 7260.HMWWB.R Intel LR_71-40473-01 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 11 T10S RENE LR_21-21025-20 spare parts BATTERY PACK 10.8V 4500mAh 48.6Wh NCA103450 LI-ION PRISMATIC FOR 1400-900042G PX501 JMS-T10SXSYM6 JMS LR_21-93078-01 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 12 PM-521(TB160) CASE ASSY T10B BOTTOM COVER (BLACK BUMPER) 607130G TAIDOC + LENS W/O BARCODE + UNITECH RATING LABEL W/KITS LR_75-20448-00 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 13 LR_22-12652-A1 spare parts *CABLE 2M webcam GBE for T10S 205746G LR_22-12653-A1 spare parts *CABLE 5M webcam GBE for PX-501 205747G LR_22-12654-A1 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 14 LR_22-21666-40 spare parts FFC Barcode ED40 WINTAC for T10S 205753G LR_22-21668-40 spare parts *FFC NFC+USB WINTAC for T10B 205754G LR_22-21669-40 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 15 LR_24-89PFJ-01 spare parts CONDUCTIVE TAPE T10C 385150G TP6-12*0.12*20+3M9707 SUNNY-TEK LR_24-89PGU-01 spare parts CONDUCTIVE TAPE T10C TP6-5*0.12*20+3M9707 Stamping 385151G process SUNNY-TEK LR_24-89PGW-01 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 16 GASKET for FBI GP6+Y46-10.0*9.0*15.0 385157G + 6mm3M9707 SUNNY-TEK LR_24-89PVB-01 spare parts CASE ASSY T10S IO DOOR TAIDOC 607174G LR_24-47702-00 spare parts © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 17 ： Note If you are going to replace any defective components or boards, please order the additional spare parts from unitech. Do not swap components or boards between the terminals. © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 18: Assembly Procedures

    2.2 Assembly Procedures Naming Rule: TB160 - □ x □ x □ x □ x □ x □ x □ x G ( □ = D1 x D2 x D3 x D4 x D5 x D6 x D7 x Green part)

  • Page 19: Tb160-Work Instruction

    TB160 User’s Manual 2.3 TB160 Work Instruction For TB160 work instruction, please download it via: http://w3.tw.ute.com/pub/cs/product\TB160\WI\TB160 WI ‐2018.pptx  © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 20: Chapter 3 - Os Update Procedure

    TB160 Service Manual Chapter 3 – OS Recovery Procedure To restore your Windows operating system on TB160 back to factory default, please use the following instructions to operate: If user account is not encrypted or you are able to log into Windows, read section 1.If you are not able to log into Windows system and is...
  • Page 21 6. When Ready to reset this PC appears, hit Reset to resume and the system will start the reset process. © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 22 1. If login password is lost, please press shift and hit restart 2. When Choose an option appears, hit Troubleshoot to resume © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 23 5. In Reset your PC, hit Fully clean the drive to resume 6. In Reset this PC, hit Reset to start system resetting © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 24 Patch download link: http://w3.tw.ute.com/pub/cs/firmware\TB160\Crazy Mouse Patch.zip Once the system reset is done, please do the following steps to eliminate crazy mouse issue aroused by GPS module on TB160. 1. Check the registry below is added or not using regedit.exe. [HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Enum\ACPI\PNP0501\3\Device Parameters] "SkipEnumerations"=dword:ffffffff...

  • Page 25: Appendix I - Worldwide Support

    TB160 Service Manual Appendix I – Worldwide Support Worldwide Support unitech’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact the nearest unitech regional service representative. For complete contact information please visit the Web sites listed below: Taipei, Taiwan –...
