- Page 1 NFC & Smart Card Reader SnapON Module - TB160 - Quick Guide Version 1.0 © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
- Page 2 Unlock the battery Remove the battery © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
- Page 3 I‐3. Remove expansion bay cover and pull the expansion connector clip to unlock. Keep the expansion by cover and its screw for future use. © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
- Page 4 I‐7. Install the battery and set the DIP switch to ON. © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
- Page 5 II‐3. Pull connector clip to release connection. © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
- Page 6 II‐5. Push connector clip to its original place. Align the expansion bay cover and secure with its screw. II‐6. Install the battery and set the DIP switch to ON. © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
- Page 7 Item Description Frequency 13.56MHz ISO/IEC 14443A, 14443B, 15693 Tag type MIFARE 1K/4K, Ultralight NFC‐IP2 protocol Smart Card Reader ISO7816 compliant Standards EMV2000 (EMV 4.1) compatible Support PC/SC1.0 & PC/SC2.0 Atmel: AT88sc1608, AT88sc153 Atmel: AT24c128, AT24c256 Card ST: M14C16, M14C04 Siemens 2‐wire link protocol: sle4432/42 Siemens serial 3‐wire bus: sle4418/28 © 2017 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
