7" Rugged Tablet Computer
-TB120-
User's Manual
401161G Version 1.1
© 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TB120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unitech TB120

Summary of Contents for Unitech TB120

  • Page 1 7” Rugged Tablet Computer -TB120- User’s Manual 401161G Version 1.1 © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 2 Change Log Date Change Description Version 20151028 1. update preface 2. Add information of MSR © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 3: Preface

    –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 4: Canadian Compliance Statement

    Interference-Causing Equipment Regulations. Cet appareil numerique de la classe B respecte les exigences du Reglement sur le material broilleur du Canada. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 5 European Conformity Statement unitech Electronics co., Ltd herewith declares that the unitech product is in compliance with the essential requirements and all other provisions of the R&TTE 1999/5/EC directive, the EMC 2004/108/EC directive and the Low Voltage 2006/95/EC directive. The declaration of conformity is available for download at : https://portal.unitech.eu/public/Safetyregulatorystatement...
  • Page 6 Taiwan NCC Warning Statement 交通部電信總局低功率電波輻射性電機管理辦法 第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者 均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有 干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備 之干擾。 注意事項: 1. 使用過度恐傷害視力。 2. 使用30分鐘請休息10分鐘；2歲以下幼兒不看螢幕，2歲以上每天看螢幕不要超過 1小時。 SAR 標準值 2.0W/Kg，送測產品實測值為 w/Kg © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 7: Laser Information

    Laser Information The unitech product is certified in the U.S. to conform to the requirements of DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 825-1. Class II and Class 2 products are not considered to be hazardous. The...

  • Page 8: Battery Notice

    It may not be functional anymore. Please only use the original battery from unitech. Using a third party battery can damage our products. Please note that when such damage occurs, it is not covered by unitech’s warranty policy.
  • Page 9 Please follow the limitation of suggested temperature conditions to avoid failure, damage or malfunction. *For applicable temperature conditions, please refer to the specification of each product. © 2015 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 10: Adapter Notice

    Please remove the power adapter when the battery is fully recharged. The bundled power adapter that comes with your unitech product is not meant to be used outdoors. An adapter exposed to water or rain, or a very humid environment can cause damage to both the adapter and the product.

  • Page 11: Worldwide Support

    Worldwide Support unitech’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact the nearest unitech regional service representative. For complete contact information please visit the Web sites listed below: Taipei, Taiwan –...

  • Page 12: Warranty Policy

    The warranty period is varied from each country. Please consult with your supplier or unitech local office for actual length of warranty period to your purchased product. Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the users.

  • Page 13: Table Of Contents

    Table of content Preface ............................i Regulatory Compliance Statements..................i Laser Information........................v LED Information........................v Battery Notice .........................vi Adapter Notice ........................viii Hearing Damage Warning ....................viii Worldwide Support .........................ix Warranty Policy........................x Table of content........................xi 1. Package Contents ........................ 1 2.

  • Page 14: Package Contents

    1. Package Contents USB cable TB120 (Standard USB to Micro USB) Power adapter Battery Hand Strap...

  • Page 15: Getting Started

    2. Getting started unitech TB120 is an Android platform device. Android platform device has great flexibility that allows you to make customized configurations and enhancements by install and remove Apps. With Android operation system, your device has limitless possibilities to update to latest features and improvements.

  • Page 16: Device Overview (With Msr Reader)

    Device overview (with MSR reader) 11. 12. 11. Micro USB port 12. DC-IN port 13. Earphone jack 14. Cradle connector...
  • Page 17 15. Bar code Scan Engine 16. MSR reader...

  • Page 18: Physical Keyboard Overview

    Physical keyboard overview 13. 14. 1. Power on/off key 8. Escape key 2. Android BACK key 9. Alpha/Numeric keys 3. Android HOME key 10. Enter key 4. Android APP List key 11. H.E.S. keys (programable) 5. Soft keypad on/off key 12.

  • Page 19: Assembly

    2.2 Assembly Accessing battery, Micro SD card and SIM card 1. Using a proper tool (ex. a coin) to loosen the two screws on the battery cover by turning anticlockwise. 2. Remove the back cover and pull the battery out. 3.
  • Page 20 Put battery back to TB120 1. Using a proper tool (ex. a coin) to loosen the two screws on the battery cover by turning anticlockwise. 2. Put battery into battery compartment and put back cover. 3. Lock the two screws on the battery cover by turning clockwise.

  • Page 21: Charging The Battery

    2.3 Charging the battery Connect TB120 to the charger, it will be charged automatically. 1. Plug the power adapter into the DC-IN port at the bottom. 2. Plug the power adapter into a wall outlet. If needed, attach a plug converter onto the power...

  • Page 22: Data Communicating With Pc Device

    2.4 Data Communicating with PC Device 1. Connect the standard USB connector to the USB port of the PC device. 2. Connect the micro USB connector to the micro USB port at the bottom. 2.5 LED status Green The battery is fully charged Lights Red The battery is charging.

  • Page 23: To Check The Battery Level And To Access The Battery Usage Menu

    2.6 To check the battery level and to access the battery usage menu 1. From your Home screen, tap 2. Find and tap Settings. 3. Find and tap Battery.

  • Page 24: Basic Operation

    3. Basic Operation 3.1 Accessing and using applications To open the Application screen From your Home screen, tap To browse the Application screen From the Application screen, flick right or left. To create a shortcut to an application on the Home screen 1.

  • Page 25: Barcode Scanning (For Imager Version Only)

    3.2 Barcode Scanning (For Imager Version only) 1. Tap the ScanService 2. Aim the Bar code Scan Engine to the barcode and press one of two trigger buttons.

  • Page 26: Serial Port Api Sample

    3.3 Serial Port API Sample 1. From your Home screen, tap 2. Find and tap Serial Port API sample Find Console...
  • Page 27 Please swipe your card with MSR ( Magnetic Stripe Readers) After swiping the card, the card information will be shown on the reception section. Card information To go back on the menu, please press...

  • Page 28: Specification

    4. Specification Features Android 4.3 Ultra-Rugged Construction: IP65 rated, 1.2M drop and MIL-STD-810G certified Lightweight and compact design: Only 735g with 1D engine and battery Large 7-inch color multi-touch sunlight-readable display Built in 1D / 2D scanner, keypad, and 5 Megapixel camera Latest Bluetooth v4.0, GPS, Wi-Fi and wireless LAN 802.11 a/b/g/n quad-mode radios Swappable Battery: 5200mAh Li-ion battery pack System Features...
  • Page 29 5M Pixels Rear Camera CMOS Sensor Camera with Auto focus, LED flash light External storage Support MicroSD memory card up to 32GB USB 2.0 OTG WLAN IEEE 802.11 a/b/g/n Bluetooth Bluetooth 4.0 with Bluetooth SIG certification WWAN GSM/GPRS/EDGE 850/900/1800/1900 MHzUMTS 850/900/1700/1900/2100 MHz WCDMA modem, HSPA+, DL: 21Mbps/ UL: 5.76Mbps.
