Anybus Wireless Bolt Reference Manual

At commands
Hide thumbs Also See for Wireless Bolt:

Advertisement

Quick Links

Wireless Bolt
/ Wireless Bridge II
AT Commands
REFERENCE GUIDE
SCM-1202-004 EN 1.7 ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wireless Bolt and is the answer not in the manual?

Questions and answers

Summary of Contents for Anybus Wireless Bolt

  • Page 1 ™ ™ Wireless Bolt / Wireless Bridge II AT Commands REFERENCE GUIDE SCM-1202-004 EN 1.7 ENGLISH...
  • Page 2 USA and other countries. Anybus ® is a registered trademark of HMS Industrial Networks AB. All other trademarks mentioned in this document are the property of their respective holders. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 3: Table Of Contents

    WLAN Client (STA) Commands ..................38 Informational Commands....................49 Miscellaneous Commands....................50 Bluetooth Low Energy Commands ................60 3.10 Bluetooth Low Energy GATT Client Commands..............69 3.11 Unsolicited events......................78 S Registers........................80 ATS S Registers ......................80 ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 4 This page intentionally left blank...
  • Page 5: Preface

    Preface About This Document This document describes the available AT commands for Anybus Wireless Bolt/Bridge II. The reader of this document is expected to be familiar with the product and have a good knowledge of wireless communication and network technology.
  • Page 6: Introduction

    Used for Ethernet and Bluetooth MAC addresses. Addresses must be entered as six groups of two hexadecimal digits in one of the following formats: 00A0F7101C08 00:A0:F7:10:1C:08 00–A0–F7–10–1C–08 ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 7: At Commands

    AT* List Available Commands Returns a list of all available AT commands Syntax: Example: Input: AT*<br>Output:<br>AT&F<br>AT*<br>AT<br>AT*ANDHCP?<br>AT*ANDHCP= <br>AT*ANIP?<br>AT*ANIP=<br>AT*ANHN?<br>AT*ANHN=<br>AT*BCP=<br>... <br> 3.1.3 AT Attention Attention command determining the presence of a DCE Syntax: ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 8: Network Commands

    If store is 1 the new value is stored permanently. Requires a reboot for the changes to take effect. AT*ANDHCP? Read the current DHCP setting Syntax: AT*ANDHCP? Example: AT*ANDHCP?<br>*ANDHCP:<dhcp_client>,<dhcp_server> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 9 If store is 1 the new value is stored permanently. Requires a reboot for the changes to take effect. AT*ANDHCPSTA? Read the DHCP start address offset. Syntax: AT*ANDHCPSTA? Example: INPUT: AT*ANDHCPSTA? <br>OUTPUT: *ANDHCPSTA:<start_address_offset> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 10 If store is 1 the new value is stored permanently. Requires a reboot for the changes to take effect. AT*ANIP? Get the IP settings Syntax: AT*ANIP? Example: AT*ANIP?<br>*ANIP:<ip_addr>,<netmask>,<gateway> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 11 Boolean If store is 1 the new value is stored permanently. Requires a reboot for the changes to take effect. AT*ANHN? Get hostname Syntax: AT*ANHN? Example: AT*ANHN?<br>*ANHN:<hostname> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 12: Bluetooth Classic Commands

    The handle of the connection to close. If set to 0 and there is no connection with handle 0 any ongoing connection attempts and retries will be aborted. Example: Input: AT*BCC=0 gives OK when the connection with handle 0 is closed. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 13 Syntax: AT*BDD Example: Input: AT*BDD returns *BDD:<bd_addr>,<cod>,<device_name_ valid>,<bluetooth_name>,<rssi> for each found device followed by OK or ERROR. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 14 12 (88) 3.3.6 AT*BI Inquiry AT*BI Perform a Bluetooth inquiry. Syntax: AT*BI Example: Input: AT*BI returns *BI:<bd_addr>,<cod>,<device_name_ valid>,<bluetooth_name>,<rssi> for each found device followed by OK or ERROR. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 15 Input: AT*BSP=101 sets the device to the Network Access Point role. AT*BSP? Gets the Bluetooth server profile. Syntax: AT*BSP? Example: Input: AT*BSP? returns the server profile. See AT*BSP= for values. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 16 If store is 1 the new value is stored permanently. AT*BPM? Get the pairing mode for BT. Pairing off = 1, Pairing on = 2. Syntax: AT*BPM? Example: Input: AT*BPM? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 17 If store is 1 the new value is stored permanently. AT*BSM? Get the security mode used for BT. See AT*BSM= for values. Syntax: AT*BSM? Example: Input: AT*BSM? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 18 AT*BBD? Output Parameters: Type Description Name bd_addr String Bluetooth address of the bonded device. is_le_device Boolean 0: BT Classic Device 1: BT LE Device Example: AT*BBD?<br>*BBD:<bd_addr1>,<is_le_device1><br>*BBD:<bd_addr2>,<is_le_ device2><br>...<br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 19 FFFFFFFFFFFF is selected, all bonded devices will be removed. Note: Deleting seperate BLE devices is not supported, to delete BLE device bonds FFFFFFFFFFFF have to be used. Example: Input: AT*BUB=8C8B83EE2ACB ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 20 Boolean If store is 1 the new value is stored permanently. AT*BLEM? Get the current Low Emission Mode. See AT*BLEM= for values. Syntax: AT*BLEM? Example: Input: AT*BLEM? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 21 Boolean If store is 1 the new value is stored permanently. AT*BDM? Get the current GAP discoverability mode. See AT*BDM= for values. Syntax: AT*BDM? Example: AT*BDM?<br>*BDM:<gap_mode> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 22 Name handle Integer The handle of the connection, received in the *BCI Connect Indication. accept Boolean Set to 1 to accept the connection, 0 to reject it. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 23 Get the RSSI for a connection. Syntax: AT*BRSS=<handle> Input Parameters: Type Description Name handle Integer The handle of the connection to get the RSSI for. Example: AT*BRSS=<handle><br>*BRSS:<rssi> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 24 Integer The time (in seconds) the unit will be pairable. Valid time is 0 to 300 seconds. Values less than 0 will be treated as 0. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 25 Bit mask used to enable or disable channels 64 to 78 (Bit 0 = Channel 64). store Boolean If store is 1 the new value is stored permanently. AT*BCHM? Read the Bluetooth channel map. Syntax: AT*BCHM? Example: AT*BCHM?<br>*BCHM: <ch0to15>,<ch16to31>,<ch32to47>,<ch48to63>,<ch64to78> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 26 4:As 3 but with 3-EDR enabled store Boolean If store is 1 the new value is stored permanently. AT*BPP? Get the Bluetooth packet policy. Syntax: AT*BPP? Example: AT*BPP?<br>*BPP:<policy> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 27 1: Always let the connecting device select master/slave role on incoming connections. store Boolean If store is 1 the new value is stored permanently. AT*BMSP? Get the Bluetooth Master Slave Role Policy. Syntax: AT*BMSP? Example: AT*BMSP?<br>*BMSP:<policy> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 28 AT*BRCD? Retrieves the MAC address and handle of every connected Bluetooth device. Syntax: AT*BRCD? Example: AT*BRCD? returns *BRCD:<bd_addr>,<handle> for each connected device followed by OK or ERROR. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 29 Example: AT*BCLR=2<br>*BCLR:<2>,<bd_addr>,<name>,<role> AT*BCLR? Reads the list of Connections that the unit can use. Syntax: AT*BCLR? Example: AT*BCLR?<br>returns *BCLR:<index>,<bd_addr>,<name>,<role> for each entry in the list followed by OK. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 30 103: PAN, This will first try to connect to PANU, and if it fails, connect to NAP, All others:Reserved store Boolean If store is 1 the new value is stored permanently. Example: AT*BCLW=0,00026F668FA8,dut1,101,1<br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 31 3: Both MAC and NAME store Boolean If store is 1 the new value is stored permanently. AT*BPPCM? Reads the PANU PANU Connection Mode. Syntax: AT*BPPCM? Example: AT*BPPCM?<br>*BPCCM:<mode> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 32: Wlan Commands

    Requires a reboot for the changes to take effect. Example: Input: AT*WMODE=1 sets WLAN mode to AP. AT*WMODE? Get WLAN mode, Station (0) or AP (1) Syntax: AT*WMODE? Example: AT*WMODE?<br>*WMODE:<mode> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 33 Integer 1...4 pKey String The key to use. Max 63 characters. store Boolean If store is 1 the new value is stored permanently. Example: Input: AT*WKEYI=2,Sesame,1. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 34 Boolean If store is 1 the new value is stored permanently. AT*WACTKEY? Get the index of the active Encryption/Authentication Key, 1..4. Syntax: AT*WACTKEY? Example: Input: AT*WACTKEY? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 35 Requires a reboot for the changes to take effect. Example: Input: AT*WMIMO=2 enable WLAN MIMO. AT*WMIMO? Get WLAN MIMO, MIMO off (1) or MIMO on (2) Syntax: AT*WMIMO? Example: AT*WMIMO?<br>*WMIMO:<mode> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 36 Requires a reboot for the changes to take effect. Example: Input: AT*WWM=0 disable WLAN World Mode. AT*WWM? Get WLAN World Mode, World Mode off (0) or World Mode on (1) Syntax: AT*WWM? Example: AT*WWM?<br>*WWM:<mode> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 37: Wlan Ap Commands

    The SSID to set. Max 32 characters. Requires a reboot for the changes to take effect. AT*WASSID? Gets the SSID for AP mode. Syntax: AT*WASSID? Example: AT*WASSID?<br>*WASSID:<ssid> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 38 The channel to use. Valid channels are 1-11 for 2.4 GHz and 36, 40, 44, 48 for 5 GHz. Requires a reboot for the changes to take effect. AT*WACH? Gets the channel for AP mode. Syntax: AT*WACH? Example: AT*WACH?<br>*WACH:<channel> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 39 Authentication Mode: 0 = Open, 2 = WPA/WPA2 PSK Requires a reboot for the changes to take effect. AT*WAAM? Get the AP Authentication Mode. Syntax: AT*WAAM? Example: Input: AT*WAAM? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 40: Wlan Client (Sta) Commands

    Type Description Name MACAddress The MAC address to set. Requires a reboot for the changes to take effect. AT*WSMAC? Get the MAC address. Syntax: AT*WSMAC? Example: AT*WSMAC?<br>*WSMAC:<mac> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 41 3.6.3 AT*WSC Connect AT*WSC Connect to Access Points as specified in the Connection List. Syntax: AT*WSC Example: Input: AT*WSC returns OK if the connection succeeds, ERROR otherwise. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 42 Integer The channel to use. 0 for any channel in the channel map. Example: Input: AT*WSCP=8C8B83EE2ACB,dut,0 will return OK if the connection succeeds, ERROR otherwise. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 43 OK. AT*WSSCAN? Scan the surroundings for access points. Will return 0...48 access points in the immediate surroundings, then return OK. Syntax: AT*WSSCAN? Example: Input: AT*WSSCAN?<br>*WSSCAN: [bssid],[ssid],[channel],[rssi],[authentication_suit],[unicast_ ciphers],[group_cipher] ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 44 Input: AT*WSAM? 3.6.8 AT*WSRSS Read RSSI AT*WSRSS? Read RSSI value of the connection. Syntax: AT*WSRSS? Example: Input: AT*WSRSS? returns ERROR if there currently is no Station mode connection. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 45 The user name to set (max 63 characters) store Boolean If store is 1 the new value is stored permanently. Example: Input: AT*WSUSER=Joe,1 AT*WSUSER? Get the user name. Syntax: AT*WSUSER? Example: Input: AT*WSUSER? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 46 The domain to set. Max 63 characters. store Boolean If store is 1 the new value is stored permanently. Example: Input: AT*WSDOMAIN=Cool,1 AT*WSDOMAIN? Get the domain. Syntax: AT*WSDOMAIN? Example: Input: AT*WSDOMAIN? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 47 The pass phrase to set. Max 63 characters. store Boolean If store is 1 the new value is stored permanently. Example: Input: AT*WSPASS=Secret,1 AT*WSPASS? Get the pass phrase. Syntax: AT*WSPASS? Example: Input: AT*WSPASS? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 48 Clears all the entries in the Connection list. Syntax: AT*WSCLC=<store> Input Parameters: Type Description Name store Boolean If store is 1 the new value is stored permanently. Example: AT*WSCLC=1 ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 49 AT*WSCLR? Reads the list of Connections (Access Points) that the unit can use. Syntax: AT*WSCLR? Example: AT*WSCLR?<br>returns *WSCLR:<index>,<bssid>,<ssid>,<channel> for each entry in the list followed by OK. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 50 The SSID of the AP. Max 32 characters. channel Integer The channel of the AP. store Boolean If store is 1 the new value is stored permanently. Example: AT*WSCLW=0,00026F668FA8,dutAP1,11,1<br>AT*WSCLW= 1,00026F668FA8,dutAP2,6,1 ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 51: Informational Commands

    Reads the the MAC for the specified interface Syntax: AT*AIMAC=<interface> Input Parameters: Type Description Name interface Integer The MAC to get. 0: Ethernet 1: WLAN 2: Bluetooth Example: AT*AIMAC=<interface><br>*AIMAC:<mac> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 52: Miscellaneous Commands

    Example: AT*AMLI=<password> AT*AMLI? Returns 1 if logged in Syntax: AT*AMLI? Example: AT*AMLI? 3.8.2 AT*AMLO Logout AT*AMLO Log out from the AT command interface Syntax: AT*AMLO Example: AT*AMLO ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 53 0: Terse, 1: Verbose. Example: AT*AMSTAT=0<br>*AMSTAT: Uptime:25<br><br>*AMSTAT: WLAN Mode:Station, MAC:02:01:2E:00:24:00, state:3<br>*AMSTAT: Connected to AP:02:01:2E:00:28:00, channel:1, rssi:-35<br><br>*AMSTAT: Bluetooth: MAC:8C:8B:83:EE:2A:E6, State:1<br>*AMSTAT: Local name: dut<br><br>*AMSTAT: Ethernet: MAC:02:00:2E:00:24:00, State:1, Type:1<br>*AMSTAT: IP_ADDR:192.168.0.99<br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 54 Executes the specified Easy Configuration Mode AT*AMEECM= Executes the supplied Easy Configuration Mode. Syntax: AT*AMEECM=<mode> Input Parameters: Type Description Name mode Integer The mode number to execute. Example: AT*AMEECM=3<br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 55 Type Description Name device_ip NetworkAddress The IP that the device shall use during the upgrade procedure server_ip NetworkAddress TFTP server IP address filename String Firmware filename (.fwz) ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 56 Get the supported interfaces Syntax: AT*AMSI? Example: AT*AMSI?<br>*AMSI:Ethernet<br>*AMSI:WLAN (2.4 GHz)<br>*AMSI:WLAN (5.0 GHz)<br>*AMSI:WLAN (MIMO) 3.8.11 AT*AMSBC Supported Bluetooth Configuration AT*AMSBC? Get the supported Bluetooth configuration Syntax: AT*AMSBC? Example: AT*AMSBC?<br>*AMSBC:<nap>,<panu>,<max_connections_classic> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 57 Boolean If store is 1 the new value is stored permanently. Example: Input: AT*AMGD=1,1,1,1 gives OK when... AT*AMGD? Read previously written data. Syntax: AT*AMGD? Example: AT*AMGD?<br>*AMGD:<data> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 58 Syntax: AT*AMBD=<disable>,<store> Input Parameters: Type Description Name disable Boolean 0: Bridging Enabled 1: Bridging Disabled store Boolean If store is 1 the new value is stored permanently. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 59 Requires a reboot for the changes to take effect. AT*AMLCR? Get AT over layer 2 configuration Syntax: AT*AMLCR? Example: AT*AMLCR?<br>*AMLCR:<eth_type>,<enabled> 3.8.16 AT*AMREBOOT Reboot AT*AMREBOOT Reboot device Syntax: AT*AMREBOOT ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 60 Read state of PROFIsafe mode. Syntax: AT*AMPSM? Example: Input: AT*AMPSM?<br>Output:<br>*AMPSM:<profisafe_mode> 3.8.18 AT*AMIC Interface configuration AT*AMIC? Command to read back interface configuration bit mask Syntax: AT*AMIC? Example: AT*AMIC?<br>*AMIC:<iface_config> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 61 AT*AMLOG=<clear> Input Parameters: Type Description Name clear Boolean Set this to 1 to clear the event log. AT*AMLOG? Read the event log. Syntax: AT*AMLOG? Example: Input: AT*AMLOG? ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 62: Bluetooth Low Energy Commands

    Boolean If store is 1 the new value is stored permanently. Example: AT*BLEAD=0102000305FF,1<br>OK AT*BLEAD? Get the data currently being advertised by this device. Syntax: AT*BLEAD? Example: AT*BLEAD?<br>*BLEAD:<data> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 63 Boolean If store is 1 the new value is stored permanently. Example: AT*BLESRD=0102000305FF,1<br>OK AT*BLESRD? Get the data currently being responded by this device. Syntax: AT*BLESRD? Example: AT*BLESRD?<br>*BLESRD:<data><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 64 If store is 1 the new value is stored permanently. Requires a reboot for the changes to take effect. Example: AT*BLEOM=1,1<br>OK AT*BLEOM? Get the current BLE operating mode. Syntax: AT*BLEOM? Example: AT*BLEOM?<br>*BLEOM:<mode><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 65 XXy" where "y" is "p" or "r" depending on if the address is private or random. Output Parameters: Type Description Name devicename String Devicename of found BLE device. The value is limited to a maximum of 19 bytes. Example: AT*BLEND=<bd_addr><br>*BLEND:<devicename><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 66 Enter/Exit RAW BLE mode. 0: Exit RAW BLE mode. 1: Enter RAW BLE mode. Example: AT*BLERM=<mode><br>OK AT*BLERM? Get the current RAW BLE mode. Syntax: AT*BLERM? Example: AT*BLERM?<br>*BLERM:<mode><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 67 3: BLE general discoverable mode store Boolean If store is 1 the new value is stored permanently. Example: AT*BLEDM=<mode>,<store><br>OK AT*BLEDM? Get the current BLE discoverability mode. Syntax: AT*BLEDM? Example: AT*BLEDM?<br>*BLEDM:<mode><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 68 2: BLE connectable mode store Boolean If store is 1 the new value is stored permanently. Example: AT*BLECM=<mode>,<store><br>OK AT*BLECM? Get the current BLE connectability mode. Syntax: AT*BLECM? Example: AT*BLECM?<br>*BLECM:<mode><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 69 Integer RSSI. name String Complete local name of BLE device, if included in data. data String Advertise/Scan response data as a HEX string. Example: AT*BLEDD=<type>,<length>,<scan><br>*BLEDD:<bd_ addr>,<rssi>,<name>,<data><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 70 Initiate an attempt to disconnect from a BLE device. The result will come in an unsolicited *BLED event. Syntax: AT*BLED=<con_handle> Input Parameters: Type Description Name con_handle Integer Connection handle. Output Parameters: Type Description Name con_handle Integer Hexadecimal formatted connection handle. Example: AT*BLED=<con_handle><br>OK<br>*BLED:<con_handle> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 71: Bluetooth Low Energy Gatt Client Commands

    Integer Decimal formatted end group handle. uuid Integer 128-bit UUID on the format 00112233-4455-6677-8899- aabbccddeeff, 00112233445566778899aabbccddeeff or 16-bit UUID on hexadecimal format 0011. Example: AT*BGCPSD=<con_handle><br>*BGCPSD:<attr_handle>,<start_group_ handle>,<end_group_handle>,<uuid><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 72 Output Parameters: Type Description Name attr_handle Integer Decimal formatted attribute handle. start_group_handle Integer Decimal formatted start group handle. end_group_handle Integer Decimal formatted end group handle. Example: AT*BGCPSDU=<con_handle>,<uuid><br>*BGCPSDU:<attr_handle>,<start_ group_handle>,<end_group_handle><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 73 Integer Decimal formatted end group handle. uuid Integer 128-bit UUID on the format 00112233-4455-6677-8899- aabbccddeeff, 00112233445566778899aabbccddeeff or 16-bit UUID on hexadecimal format 0011. Example: AT*BGCFIS=<con_handle>,<start_handle>,<end_handle><br>*BGCFIS:<attr_ handle>,<start_group_handle>,<end_group_handle>,<uuid><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 74 * Bit 7: Extended property available value_handle Integer Decimal formatted value handle. uuid String 128-bit UUID on the format 00112233-4455-6677-8899- aabbccddeeff, 00112233445566778899aabbccddeeff or 16-bit UUID on hexadecimal format 0011. Example: AT*BGCDCS=<con_handle>,<start_handle>,<end_handle><br>*BGCDCS:<attr_ handle>,<properties>,<value_handle>,<uuid><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 75 Decimal formatted handle to the characteristic. attr_handle Integer Decimal formatted attribute handle. uuid String 128-bit UUID on the format 00112233-4455-6677-8899- aabbccddeeff, 00112233445566778899aabbccddeeff or 16-bit UUID on hexadecimal format 0011. Example: AT*BGCDCD=<con_handle>,<value_handle>,<end_handle><br>*BGCDCD:<char_ attr_handle>,<attr_handle>,<uuid><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 76 Handle to the characteristic or descriptor value. offset Integer Offset where to start read from. Output Parameters: Type Description Name data String Data formatted as a hexadecimal string. Example: AT*BGCRC=<con_handle>,<attr_handle>,<offset><br>*BGCRC:<data><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 77 UUID to look for. Output Parameters: Type Description Name attr_handle Integer Handle to the attribute read. data String Data formatted as a hexadecimal string. Example: AT*BGCRCU=<con_handle>,<start_handle>,<end_handle>,<uuid><br>*BGCRCU: <attr_handle>,<data><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 78 Integer Connection handle. attr_handle Integer Handle to the characteristic or descriptor value. data String Data to write as a HEX string with max 20 bytes. Example: AT*BGCWC=<con_handle>,<attr_handle>,<data><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 79 The last write should have the flag set to 0. Set the flag to 2 to abort the write. offset Integer Offset of the data to write. Example: AT*BGCWCL=<con_handle>,<attr_ handle>,<data>,<reliable>,<flag>,<offset><br>OK ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 80: Unsolicited Events

    Output Parameters: Type Description Name con_handle Integer Hexadecimal formatted connection handle. attr_handle Integer Handle to the attribute. value String Value as a HEX string. Example: Event: *BLENR:<con_handle>,<attr_handle>,<value> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 81 Output Parameters: Type Description Name con_handle Integer Hexadecimal formatted connection handle. attr_handle Integer Handle to the attribute. value String Value as a HEX string. Example: Event: *BLEIR:<con_handle>,<attr_handle>,<value> ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 82: S Registers

    Bit mask representing Easy Config LED Mode when LED Mode smart mode is finished Value 0: Link quality LEDs are off Value 1: WLAN RSSI Value 2: BT Link Quality ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 83 *BRHC - Roaming handover candidate *BRH - Roaming handover 1014 Easy Config 0..4294967296 5000 Maximum time to wait for first push on SMART Mode Timeout button in milliseconds ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 84 When a matching name is found, a connection attempt will be done. If the connection fails, it will try with the next found and so on. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 85 Interval 3006 Reconnect 0..4294967296 5000 The interval in milliseconds Interval 3007 RSSI poll 0..65535 1000 RSSI poll interval in milliseconds interval 3008 Reserved 3009 Reserved 3010 Reserved ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 86 Default Value 5100 Reserved 5101 Profinet 0..1 Set prioritization for PROFINET. Prioritization 0: Disable 1: Enable 5102 Prioritized 0..65535 0x8892 The 16-bit Ethernet type to prioritize Ethernet Type ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 87 Window). Unit in multiples of 0.625 ms. 6016 Bond Scan 16..16384 Bond scan window (must be <= Bond Scan Interval). Window Unit in multiples of 0.625 ms. ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
  • Page 88 Interval 6023 Remote 16..16384 Remote name request scan window (must be <= Name Remote Name Request Scan Interval). Unit in Request Scan multiples of 0.625 ms. Window ™ ™ Wireless Bolt / Wireless Bridge II Reference Guide SCM-1202-004 EN 1.7...
