INSTALLER: Please leave this manual for the consumer.
CONSUMER: Please retain this manual for future reference.
Patio Heater Model: HCPHSSQ
WARNING: For outdoor use only.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately call gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
PLEASE retain this manual for reference.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Read the instructions
thoroughly before installing or servicing this
equipment.
Ce produit peut vous exposer à des produits chimiques, y compris le
monoxyde de carbone, qui est connu dans l'État de Californie pour causer
le cancer, des malformations congénitales et / ou d'autres problèmes de
reproduction. Pour plus d'informations, visitez www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
852788-3103F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCPHSSQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HomComfort HCPHSSQ

Summary of Contents for HomComfort HCPHSSQ

  • Page 1 Patio Heater Model: HCPHSSQ WARNING: For outdoor use only. FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, immediately call gas supplier. FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.

  • Page 2: General Safety Information

    General Safety Information WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the instructions thoroughly before installing or servicing this equipment. WARNING: For Outdoor Use Only LPG Cylinders to be used must be constructed and marked in accordance with US DOT specifications. Storage of the heater indoors is permissible only if the gas cylinder is turned off and removed.
  • Page 3 • After a long break of operation,the gas parts in the control box of the heater and the hose should be inspected for spiders,spider webs or other insects. • Check the heater immediately if any of the following exists: 1. There is smell of gas; 2.

  • Page 4: Leak Testing

    Leak Testing WARNING: Do not smoke while leak testing. Gas connections on the heater are leak tested at the factory prior to shipment. Possible mishandling of the heater during the shipment might contribute to product integrity as a whole. A complete gas leakage test must be performed again at the installation site.

  • Page 5: Parts List

    Parts List Part No. Part Name Picture Remarks Middle Plate Control Box Bottom Plate Lower Support Upper support Upper plate Plate cover Glass Tube Damper Pre-assembled in the upper plate Reflector Lower Protection Guard Wheels Fixing Bracket Side panel 2 side panel with round holes, 1 without hole Front panel 3/16”...
  • Page 6 Assembly STEP 1 STEP 4 Attach wheels (12) to the bottom plate (3) and Connect the control box (2) to the middle plate ( 1) secure using 4 screws on each wheel. Please note the if it is not connected already. Then place the middle wheels are facing downward and the bottom plate is plate between the 4 support beams (4) and attach upside down as well.
  • Page 7 STEP 7 tube covers the center hole of the middle plate. Fix Screw in 3 double sided bolts (25) into the top of the 3 side panels (15) with screws (17). Make sure front damper (9) if not already assembled. panel (16, with handle) is opposite of wheels.

  • Page 8: Operation

    Operation PREPARATION You will need to purchase a standard 20 lb. LPG cylinder designed to be used with the regulator purchased or supplied. For correct operation of the gas system follow the instructions supplied with the regulator supplied. Connect the hose to the hose connector in the control box. WARNING: Always test the hose and connections for leaks with soapy water at the end of all connections.

  • Page 9: Maintenance & Storage

    Maintenance / Storage CLEANING & MAINTENANCE To enjoy years of outstanding performance from your heater make sure you perform the following maintenance routines on a regular basis: • Keep exterior surfaces clean: - Use warm soapy water for cleaning. Never use flammable, corrosive or abrasive cleaners - While washing your unit, be sure to keep the area around the burner and pilot assembly dry at all times.

  • Page 10: Troubleshooting

    Trouble Shooting PROBLEM PROBABLE CAUSE SOLUTION Gas valve may be OFF Turn the gas valve ON Fuel tank is empty Refill LPG cylinder Pilot will not light Orifice blocked Clean or replace orifice Air in supply system Purge air from lines Loose connection Check all fittings Debris around pilot...
  • Page 11 Notes...
  • Page 12 Notes...
  • Page 13 Distributed By: United States Stove Company www.usstove.com 227 Industrial Park Rd (800) 750-2723 South Pittsburg, TN 37380 1 year limited warranty - Customers in the Continental US All components are warranted for a period of 1 year after date of purchase by the original owner against defects in materials and workmanship under normal use.
