Mocha Patio Heater
Model: HCPHPRM
Conforms to ANSI STD Z83.26a-2008
Certified to CSA STD 2.37a-2008
IMPORTANT:
Read this manual carefully before
assembling, using or servicing this heater.
Keep this manual for future reference.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish open flame.
3. If odor continues, keep away from the
appliance and immediately call your
gas supplier or the fire department.
United States Stove Company
227 Industrial Park Rd
South Pittsburg, TN 37380
www.usstove.com (800) 750-2723
852989-1203H
Advertisement
Table of Contents
Related Manuals for HomComfort HCPHPRM
Summary of Contents for HomComfort HCPHPRM
- Page 1 Mocha Patio Heater Model: HCPHPRM Conforms to ANSI STD Z83.26a-2008 Certified to CSA STD 2.37a-2008 IMPORTANT: Read this manual carefully before assembling, using or servicing this heater. Keep this manual for future reference. FOR YOUR SAFETY If you smell gas: 1.
-
Page 2: General Safety Information
General Safety Information • This manual contains important information about the assembly, operation and maintenance of this patio heater. General safety information is presented in these first few pages and is also located throughout the manual. • Keep this manual for future reference and to educate new users of this product. This manual should be read in conjunction with the labeling on the product. - Page 3 Precautions WARNING: We cannot foresee every use which may WARNING: be made of our heaters. Check with your local fire EXPLOSION· FIRE HAZARD safety authority if you have questions about heater • Never store propane near high heat, open use. Other standards govern the use of fuel gases flames, pilot lights, direct sunlight, other ignition and heat producing products for specific uses.
-
Page 4: Additional Requirements
Assembly Instructions COMPONENTS Remove all components from package. WARNING: California Proposition 65 combustion by products produced when using this product contain chemicals known to the state of California to cause cancer, birth defects, and other reproductive harm. Part Description Qty. Reflector Head Assembly Post... - Page 5 Step 1 Step 4 If your model did not come with a wheel assembly, • Attach the post support to the top of the support proceed to step 2. legs using M6 x 22 bolts and M6 nuts. • Align the holes in the wheel assembly with the holes in the base.
- Page 6 Step 7 Step 9 • Remove the 4 pre-assembled screws from the • Slide three large flat washers over the threaded head assembly and attach the post with these 4 end of the studs. screws. • Place the reflector assembly over the studs and •...
-
Page 7: Leak Check
LEAK CHECK • A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your WARNING: cylinder supplier. Never use a propane cylinder • Perform all leak tests outdoors. with a damaged valve connection. • Extinguish all open flames. •... -
Page 8: Operation
Operation DANGER Caution: Do not attempt to operate until you CARBON MONOXIDE HAZARD have read & understand all of the general safety For outdoor use only. Never use inside house, or information in this manual, and that all assembly is other unventilated or enclosed areas. -
Page 9: Replacing The Gas Cylinder
WARNING 1. The whole gas system, hose, regulator, pilot, or burner should be inspected for leaks before use. 2. Check the hose assembly for signs of extreme abrasion, cuts or wear. Suspected areas should be leak tested. If the hose leaks, inspect the visible portion of the hose before each use of the appliance and inspect the entire hose assembly at least annually. -
Page 10: Cleaning And Care
Storage • Always close the valve of the gas cylinder after • Storage of heater indoors is permissible only if the use or in case of a disturbance. cylinder is disconnected and removed from the • Remove the pressure regulator and the hose heater. - Page 11 First Aid For A Burn EYES 2. Young children should be carefully supervised when they are in the area of the heater. • Seek medical attention IMMEDIATELY. Do not put 3. Clothing or other flammable materials should ointments or liquids in eye. not be hung from the heater, or placed on or ELSEWHERE near the heater.
-
Page 12: Troubleshooting
Trouble Shooting PROBLEM PROBABLE CAUSE SOLUTION Burner injector clogged Clean burner injector Burner will not light Low gas supply pressure Call your gas supplier Burner flame goes off Low gas pressure Call your gas supplier immediately after ignition Main burner carry over ports clogged Clean main burner ports Delayed ignition Low gas supply pressure... -
Page 13: Service Record
Service Record It is recommended that this unit is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider: Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. - Page 14 Distributed By: United States Stove Company www.usstove.com 227 Industrial Park Rd (800) 750-2723 South Pittsburg, TN 37380 1 year limited warranty - Customers in the Continental US All components are warranted for a period of 1 year after date of purchase by the original owner against defects in materials and workmanship under normal use.
