TECHNICAL GUIDE
LX SERIES
SPLIT SYSTEM
HEAT PUMPS
16 SEER – R-410A – 1 PHASE
2 THRU 5 NOMINAL TONS
MODELS: CH1624 THRU 60
® ®
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.colemanac.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Standard 5-year limited parts warranty.
Standard 10-year limited compressor warranty.
Extended 10-Years limited parts warranty when product is
registered online within 90 days of purchase for replacement
or closing for new home construction.
*Does not apply to R-22 models, 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed

DESCRIPTION

The CH16 16 SEER Modulating Heat Pumps are the newest
offering in our successful LX Family of split system heat pumps.
These units use a state of the art inverter driven compressor to
precisely meet customers comfort requirements. Using a con-
ventional two-stage heat pump thermostat, the system will auto-
matically modulate capacity and airflow from 50% to 100% of
nominal capacity in 10% increments to meet the comfort
requirements of the consumer, maximizing comfort while mini-
mizing energy bills.
Designed to work with Coleman variable
speed or standard ECM indoor air handling equipment it pro-
vides consumers and dealers system installation options.
Should the unit ever require service the main control and
inverter control both provide system self-diagnostics.

FEATURES

• Improved Temperature Control - The inverter driven com-
pressor and modulating system will automatically adjust
capacity, in heat or cool mode, to precisely match the comfort
demands of the space providing closer temperature and
humidity control.
• Easier Installation - Time is reduced by being factory
charged for a 15-Ft line set and having a factory installed fil-
ter-drier. This means less time spent brazing and charging
the system. The small base dimension and reduced unit
clearances requirements provide more retrofit applications.
• Accessible Information - QR code on unit provides quick
access to technical documents and warranty information at
www.upgnet.com.
• Durable Finish - The automotive grade champagne colored
powder painted and the specially coated wire grill and fasten-
ers add to the corrosion resistant nature of the product allow-
ing it to retain its aesthetics appeal throughout its life.
• Rugged Coil Protection - Coils are protected from mechan-
ical damage by a stamped steel extruded louver coil guard
design.
• Quality Coils - Enhanced aluminum fins are mechanically
bonded to copper tubing.
• Protected Compressor - Compressors are protected by the
system high and low pressure switches. The liquid line filter-
drier is factory installed to protect the system against mois-
ture and contaminates.
• Reliable Operation - Ball bearing fan motors provide supe-
rior performance in extreme temperatures. Factory installed
accumulator protects the compressor while operating across
a wide range of conditions.
• Environmentally Friendly - CFC-free R-410A refrigerant
delivers environmentally friendly performance with zero
ozone depletion.
• Top Discharge - Warm air is blown up, away from the struc-
ture and any landscaping and allows compact location on
multi-unit applications.
• Low Operating Sound Levels - The sturdy cabinet and top
design provides sound performance as low as 76 dBA.
• Better Service Access - Diagonal base valves with open
access for Schrader removal tools and low-loss fittings and
single panel access to the electrical controls. Full corner
access using the swing out electrical box, and removable fan
guard allow easy access for unit service or maintenance.
• Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.
5186825-CTG-D-0717
