UK Quick Programming Guide – K38/39 & K49
This guide should be used alongside the full engineering manual, appropriate to the instrument being

Programming the Instrument

Tecnologic controllers are supplied with default programmable settings that may be suitable for your
application. However we recommend that you go through the programming process, as incorrect
programming could compromise its performance.
Programming level pass numbers:
1381 – Basic menu without 10 second time out
1400 – Advanced menu without 10 second time out
** Minus 1000 to the pass number to add time out function **
Note: To reset instrument to factory default settings, press P for 5 seconds and dial in -481.
Press P to confirm

Key

P button used for entering or moving to the next parameter.
P
Up & down buttons used for increasing or decreasing values.
U button is used for navigation between menus.
U
Holding down for 1 second will take you back one step.
Holding down for 2 seconds will take you out of configuration.
Unit 1 Farnborough Business Centre, Eelmoor Road, Farnborough, GU14 7XA
T: 01252 377600 F: 01252 377601 E: sales@tecnologicuk.co.uk
Tecnologic 'K' Series
used, where more detailed information can be found.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K series and is the answer not in the manual?

Questions and answers

Summary of Contents for Tecnologic K series

  • Page 1 Programming the Instrument Tecnologic controllers are supplied with default programmable settings that may be suitable for your application. However we recommend that you go through the programming process, as incorrect programming could compromise its performance.
  • Page 2 Navigating the basic level programming guide This is a blueprint guide for changing all the parameter settings on the instrument within the 381 menu. 381 Parameter menu Start/ Configure. Display Parameter name/ Manual description ref. Power up unit. tEST will flash SEnS Sensor/ input type Decimal point position...
