LAUNCH
Product Instruction
1 External Structural Drawing
1．Operation Panel
3．Safety Guard
5．Quick Lock Hub Nut
2. Functions
Dynamic Mode
Static Mode
Standard ALU1, ALU2, ALU3, Mode
ALUS Mode
OPT(OPTIMIZATION) mode
Unit Conversion in Different Countries (Areas):
Mechanical sensor arm
Self-calibration
Guard Protection
Self-check Error and Diagnostics
3. Specifications
Rated voltage: 110V /220V / 380V
Protection Class: IP 54
Motor power: 250w
Max Rotating Speed: 220 r /min
Cycle Time: Average 6-9s
Fig1
2．Counterweight Container
4．Mechanical sensor arm
6．Balancer Body
g / oz, mm / inch
1
KWB-511 Wheel Balancer user's manual
