Getting to Know the Sensor

About the Sensor
• The sensor is a small device worn
around your neck.
• Three lead wires gather data from
your heart.
• The sensor can gather and store up
to five hours of data.
• The sensor communicates the data
from your heart constantly to the
monitor.
• It is recommended that you keep
the sensor and monitor in the same
room at all times to eliminate loss of
communication between the devices .
PAGE 6
Sensor Light
Solid Green = Power Up Complete
Flashing Green = Communication
Established
No Light = Communication Ongoing
(majority of prescription)
Flashing Red= Communication Stopped
- Before you Begin
Neck Strap
Battery
Door
Lead Wires
Each wire will snap to
an electrode that will be
attached to your body.
