Wireless Accelerometer Node
1
WHAT YOU NEED
P/N 6305-4002 or P/N 6305-4010
™
®
G-Link2
-LXRS
with internal accelerometers
P/N 6305-5000
P/N 6305-5002 or P/N 6305-5010
™
®
G-Link2
-LXRS
External Accelerometer
with external accelerometer
2a
ASSEMBLE NODE BATTERY/ACCELEROMETER
Remove 4 cover screws
Torx T9
screwdriver
Insert battery in battery
Insure that battery polarity
matches battery holder
2b
ASSEMBLE BASE STATION
P/N 6307-1040
WSDA-BASE-104 & USB Cable
P/N 9021-0034
P/N 9022-0052
3.6 Volt Lithium AA Battery
External Power Cable
holder
Connect external accelerometer
™
®
to G-Link2
-LXRS
connector
3a
INSTALL SOFTWARE AND CONFIGURE NODE
Double-click Node Com-
mander icon on the Desktop
Right-click
Node
Commander
Follow on-screen installa-
tion instructions to install
Node Commander software
Right-click
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lord MicroStrain G-Link2-LXRS
Summary of Contents for Lord MicroStrain G-Link2-LXRS
- Page 1 INSTALL SOFTWARE AND CONFIGURE NODE Follow on-screen installa- tion instructions to install Node Commander software Quick Start ™ ® G-Link2 -LXRS Wireless Accelerometer Node WHAT YOU NEED P/N 6305-4002 or P/N 6305-4010 Double-click Node Com- ™ ® G-Link2 -LXRS mander icon on the Desktop P/N 6307-1040 with internal accelerometers WSDA-BASE-104 &...
