Petsafe Simply Clean Replacement Manual

Petsafe Simply Clean Replacement Manual

Replacing the bowl motor assembly for self-cleaning litter box
Hide thumbs Also See for Simply Clean:

Advertisement

Quick Links

Thank you for choosing PetSafe
want to ensure your pet's happiness and safety by providing you with the tools and techniques to successfully care for
your pet. If you have any questions, please contact the Customer Care Center at 1-800-732-2677 or visit our web site
at www.petsafe.net.
Replacing the Bowl Motor
It is recommended that you perform the procedures in this document on a stable fl at surface that is large enough to
securely and safely hold the Simply Clean Litter Box unit, and that provides suffi cient work area for you to work with
the individual components. We also recommend you remove the litter in the bowl as part of this procedure.
Requirements
To complete the procedures in this document, you will need:
• A #2 Philips screwdriver
• A fl at head screwdriver (optional)
• A replacement bowl motor kit
____________________________________________________________________________________________________________
Removing the Bowl Motor
Cover the work surface with a large sheet, drop cloth, or newspaper, and then:
1. Remove the conveyor cover and set it aside
(see Figure 1 below).
Figure 1: Removing the conveyor cover
Replacing the Bowl
For Simply Clean
®
. Our mission is to be the most trusted brand in the pet ownership experience. We
Motor Assembly
®
Self-Cleaning Litter Box
2. Loosen the two thumbscrews that secure the conveyor
to the base (see Figure 2 below).
Figure 2: Loosening the thumbscrews

Advertisement

loading
Need help?

Need help?

Do you have a question about the Simply Clean and is the answer not in the manual?

Questions and answers

Summary of Contents for Petsafe Simply Clean

  • Page 1 It is recommended that you perform the procedures in this document on a stable fl at surface that is large enough to securely and safely hold the Simply Clean Litter Box unit, and that provides suffi cient work area for you to work with the individual components.
  • Page 2 5. Lower the conveyor to its original position. While holding the conveyor in place, fl ip the Pull up entire base unit over so the bottom side is up. to unlatch Figure 7: Disconnecting the bowl motor wire Figure 5: Turning the base unit upside-down www.petsafe.net...
  • Page 3 4. Lower the conveyor into place (see Figure 11 below). If your bowl is full of litter, you may gently wiggle the conveyor back and forth to bury the rake fi ngers in the litter. Figure 9: Installing the bowl motor assembly Figure 11: Repositioning the conveyor www.petsafe.net...
  • Page 4 Customer Care Center at 1-800-732-2677 Monday – Friday: 8 am - 8 pm EST, or Saturday: 9 am - 5 pm EST. Radio Systems Corporation • 10427 Electric Avenue • Knoxville, TN 37932 • 1-800-732-2677 • www.petsafe.net • ©2008 Radio Systems Corporation • 400-1034...
