Honda 08Z03-SJC-100 Installation Instructions

INSTALLATION
INSTRUCTIONS
PARTS LIST
Meter panel
Left front door switch panel
Right front door switch panel
Right rear door switch panel
Left rear door switch panel
©
2005 American Honda Motor Co., Inc - All Rights Reserved.
Accessory
INTERIOR TRIM
P/N 08Z03-SJC-100
TOOLS REQUIRED
Isopropyl alcohol
Shop towel
Masking tape
INSTALLATION
NOTE:
•
•
Installing the Meter Panel
1.
2.
All 28608 (0502)
Application
2006 RIDGELINE
Be extremely careful not to damage the interior
panel.
The interior trim should be installed only if the
ambient air temperature is above 60°F (15°C).
Using a isopropyl alcohol on a shop towel,
thoroughly clean the area where the meter panel
will attach.
With the meter panel placed upside down, attach
a strip of masking tape one end of each shaded
adhesive backing. Remove 2 in. (5-6 cm) of the
adhesive backings from the ends and fold them
over as shown. Temporarily attach the strips of the
masking tape to the surface of the meter panel.
Remove all remaining adhesive backings from the
meter panel.
SHADED ADHESIVE BACKINGS
Attach a piece of masking tape to
the ends, and remove 2 in. (5-6 cm)
METER
of adhesive backings. Fold the ends
PANEL
back, and attach the masking tape
to the surface of the meter panel.
ADHESIVE
BACKINGS
(Remove.)
Publications No.
All 28608
Issue Date
FEB 2005
1 of 3
08Z03-SJC-1000-91
