aoyue Int857A++ Instruction Manual page 4

SPECIFICATION
Power Input : available in 110V / 220V
Power Consumption: 500W
Temperature Range: 100°C – 480°C
Heating Element: Metal Heating Core
Pump/Motor Type: Turbine Motor
Air Capacity: 20 l /min (max)
Station Dimensions: 132(w) x 121(h) x 192(d) mm
Weight: 2.3Kg
FUNCTION
CPU controlled.
●
Turbine motor generated，
●
Best suited for reworking BGA，PCB plastic connectors
●
as well as large surface shield and covers。
Digital temperature readout for easier manipulation。
●
Compatible with different kinds of air nozzles.
●
●
●
●
●
●
●
4
CARE and SAFETY PRECAUTIONS
CAUTION:
Misuse may cause injury and physical damage.
For your own safety, be sure to comply with the following precaution.
Temperature may reach a high of 480°C when turned on.
­ Do not use near flammable gases, paper and other materials.
­ Do not touch heated parts, can cause severe burns.
­ Warn people around work area.
Thermal Protector
­ If the thermal protector trips, reduce the temperature setting
or increase the air flow to decrease temperature to safe level.
­ Unit is equipped with auto shut­off ability when temperature
gets too high and automatically turns on when temperature
dropped to a safe level.
Handle with Care
­ Never drop or sharply jolt the unit.
­ Contains delicate parts that may break if unit is dropped.
Disconnect plug when not to be used for a long period of time.
­ Turn off power during breaks.
Use only genuine replacement parts.
­ Turn­off power and let unit cool before replacing parts.
Do not modify unit
5
