DESCRIPTION

Demonstration Circuit DC1589A is a Linear Supercap Charger with Current-Limited Ideal Diode and V/I Monitor,
®
featuring the LTC
4425.

PERFORMANCE SUMMARY

SYMBOL
PARAMETER
Vin
Input Voltage Range
Icharge
Supercap Charge current
VOUT
Supercap Stack Output Voltage
V(MID)
Supercap Midpoint Voltage

QUICK START PROCEDURE

Refer to Figure 1 for the proper measurement
equipment setup and jumper settings and follow the
procedure below.
When measuring the input or output voltage ripple, care
NOTE.
must be taken to avoid a long ground lead on the oscilloscope
probe. Measure the input or output voltage ripple by touching the
probe tip directly across the VBUS or VOUT(x) and GND terminals.
See Figure 2 for proper scope probe technique.
1. Set b[2-0] jmpers (JP3, JP4, JP5) to "1". Set
MODE (JP6) to "LDO". Set LD1 to 0A, and PS1
to 5V.
Observe VOUT (VM3) = 3.3V, I(VIN)
(AM1) = 2A, and V(PROG) (VM2) = 1V. Note:
The supercapacitor COUT1 will charge in ap-
proximately 0.5 seconds, so please observe
these signals within a few seconds of setting
PS1 to 5V.
2. Set PS1 to 0V. Observe D1 (PFO) should be lit
due to input 'power failure'
3. Set LD1 to 1A. Observe VOUT. VOUT should
decrease
to
0V,
CONDITIONS
in
about
1
second.
LTC4425EDD: Linear Supercap
Charger With Current-Limited
Ideal Diode And V/I Monitor
Specifications are at T
= 25°C
A
QUICK START GUIDE
FOR DC1589A
MIN
TYP
MAX
UNITS
2.7
5.5
2
1.2
5.4
0.6
2.7
V
A
V
V
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC1589A and is the answer not in the manual?

Questions and answers

Summary of Contents for Linear Technology DC1589A

  • Page 1 FOR DC1589A LTC4425EDD: Linear Supercap Charger With Current-Limited Ideal Diode And V/I Monitor DESCRIPTION Demonstration Circuit DC1589A is a Linear Supercap Charger with Current-Limited Ideal Diode and V/I Monitor, ® featuring the LTC 4425. PERFORMANCE SUMMARY Specifications are at T = 25°C...
