FLoid
Cell Imaging Station
™
QUICK REFERENCE
Catalog No. 4471136
Contents
FLoid
Cell Imaging Station
™
Power cord
Keyboard
Wireless mouse
USB memory device (containing
user manual)
Quick reference card
Printer (Cat. No. 4472351)
1. Install battery in mouse
a. Remove cover from mouse.
b. Insert battery.
c. Turn on power switch.
For Research Use Only. Not for use in diagnostic procedures.
Part. No. ZP-PKGA-0594
2. Connect accessories
3
4
Power cord
1
Outlet
2
USB memory device
3
Pub. No. MAN0005496
1
2
5
6
Keyboard
4
Wireless mouse
5
Printer
6
Rev. A.0
3. Power on device
1
2
3
4
5
6
Light shield
1
Indicator light
2
Objective opening
3
Stage
4
Stage movement knob
5
7
8
9
10
USB port
6
LCD screen
7
USB ports
8
Focus knobs
9
On/off switch
10
Advertisement
Related Manuals for Thermo Scientific Invitrogen FLoid
Summary of Contents for Thermo Scientific Invitrogen FLoid
- Page 1 FLoid Cell Imaging Station ™ QUICK REFERENCE Part. No. ZP-PKGA-0594 Pub. No. MAN0005496 Rev. A.0 Catalog No. 4471136 2. Connect accessories 3. Power on device Contents FLoid Cell Imaging Station ™ Power cord Keyboard Wireless mouse USB memory device (containing user manual) Quick reference card Printer (Cat.
- Page 2 4. Capture image 5. Process image a. Place sample on stage over objective opening. a. Adjust brightness and contrast as needed. b. Turn on light by selecting light bulb icon. b. Save image to USB flash drive and print image. c.
