Connection - Fluigent FLOW-RATE PLATFORM User Manual

5.2 Connection

5.2.1 USB connection
5.2.2 FLOW UNIT connection
SA à Directoire et Conseil de Surveillance au capital de 141 284.95 € - Siret : 487 636 409 00038 – N°TVA UE/EU VAT Number : FR 53 487 636 409
Siège social : Biopark – 1 mail du Professeur Georges Mathé – 94800 Villejuif – France
Tel : +331 77 01 82 68 – Fax : +331 77 01 82 70
Connect the type B plug of the USB cable
provided with the Flow-Rate Platform into
the type B USB port on the front of the
FLOWBOARD.
Connect the other end of the USB cable
(type A standard plug) to the computer
where the corresponding software is
installed (cf. User Manual).
To connect a FLOW UNIT to the FLOWBOARD,
plug the end of the mini-USB plug fixed with
the FLOW UNIT to one of the eight (8) mini-USB
ports on the FLOWBOARD.
FLUIGENT
www.fluigent.com
Page - 15
