The pictures below show ho to o
1. Cut the 1/32'' OD tu i g to the desired length, leaving a square-cut face.
2. Slide the fitting over the tubing.
3. Insert the assembly into the receiving port, and while holding the tubing firmly against the bottom of
the port, tighten the fitting finger tight.
4. To check the tightness of your connection, you may pull gently on the tubing: it must stay fitted in the
ferrule and nut.
5. Do the same thing on the 2
SA à Directoire et Conseil de Surveillance au capital de 141 284.95 € - Siret : 487 636 409 00038 – N°TVA UE/EU VAT Number : FR 53 487 636 409
e t OD / '' tu i g to X", " a d M FLOW UNIT odels.
nd
port.
