Software Features

Vision Application Overview

Vision capture cards are supplied with a powerful software application for configuring the format of the input sources and
displaying the data in various ways.
The Vision application is available when a Vision window is opened:
Start | Programs | Vision | Vision window
The application displays the connected source in a window; it has the following features:
•
Scales the data to fit in the window.
•
Ability to set up sources accurately (settings automatically saved).
•
Save a single frame to a file in one of the following formats:
BMP, JPEG, GIF, TIFF, PNG.
•
Print a single frame.
•
Maintain the aspect ratio of the displayed captured data.
•
Cropping.
•
Display text over the data (on-screen display).
•
Command line interface.
•
Help file documenting all features.

Vision Configure

Vision Configure is a comprehensive EDID management tool which enables the user to program custom EDID parameters for all
capture cards.
To open the Vision configure dialogue:
Start | Programs | Vision | Vision Configure
8
