Quick Links
Parts List
1
Power Commander
1
USB Cable
1
CD-ROM
1
Installation Guide
1
Power Adapter
2
Power Commander Decals
2
Dynojet Decals
2
Velcro
Strip
®
1
Alcohol Swab
1
O2 eliminator
1
Wire tap
The ignition MUST be turned
OFF before installation!
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
i339-411
www.powercommander.com
2 0 0 8 S u z u k i G S X 1 3 0 0 R
I n s ta l l a t i o n I n s t r u c t i o n s
Button Adjustment Display
Faceplate Buttons
Expansion Port
2008 Suzuki Hayabusa - PCIII USB - 1
USB Port
Advertisement
Related Manuals for Dynojet GSX1300R
Summary of Contents for Dynojet GSX1300R
- Page 1 Commander software and latest maps from our web site at: www.powercommander.com PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com i339-411 www.powercommander.com 2008 Suzuki Hayabusa - PCIII USB - 1...
- Page 2 Remove the main seat and the passen- ger seat. Hold the front of the fuel tank up using the prop rod located in the trunk area. Disconnect the main wiring harness from each of the LOWER injectors (Fig. A). Lay the PCIII in the tail section and route the PCIII harness down the left Unplug these connectors hand side of the bike towards the...
- Page 3 The fairing needs to be pulled away from the frame to gain access but does not need to be totally removed. Plug the Dynojet O2 eliminator into the stock wiring harness. The stock O2 sensor will not be connected to anything.
