AMP Research PowerStep Installation Manual page 8

Attach step, sliding the mounting T-nut into
position. Torque to 0 ft lbs (3.5 Nm)
2
8
On each side of the vehicle use tape to mark the led drill location two sections from studs as
shown below. Use tape to indicate. Locations are approximately 22" & 66" from front door edge.
Drive Side Rear Mounted
(In between two rivets just forward of
4
20
mounting location, as shown above)
Mark hole location /2" midpoint of the rocker
with tape and center punch and drill 9/64" hole
into pinch weld. Deburr hole and insert grommet
(#6) for LED Wire.
5
A M P R E S E A R C H P O W E R S T E P
T M
– F O R D F -  5 0
On each side of the vehicle measure from the
rear linkage to end of the board. Measurement
should be approximately " as shown below.
3
9
Drive Side Front Mounted
(Just under left edge of body-
brace, as shown above)
Route LED wires though through grommet,
clean surface, and stick on to rocker panel as
shown below.
16
6
2
