AMP Research PowerStep Installation Manual page 5

Locate mounting points; first and last set of studs on the inner sill.
Motor Linkage mounts toward the front of the truck and Idller mount toward the rear. Driver side
shown below.
Driver Side Rear Stud Location

Mount drive and Idler linkage assemblies. Repeat for passenger side. Make sure linkages sit
square, fully resting on studs before tightening. Torque to 6 ft. lbs (22Nm)
2
Idler Linkage (Rear)
Relocate Brake Cable Guide as shown in following steps.
A. Remove bolt with 3mm box
wrench or socket.
4 3
A M P R E S E A R C H P O W E R S T E P
New Mount
Location
B. Remove and relocate J-Clip
to location shown above. Bend
bracket tab flat to reinstall.
T M
– F O R D F -  5 0
Driver Side Front Stud Location
Drive Linkage (Front)
Bend Tab
C. New location of Brake Cable
Guide installed shown above.
