- Page 1 Instruction Manual Dual-Input J/K/T/E Thermocouple Thermometer (Model 91428-03) Dual-Input Data Logging Thermocouple Thermometer (Model 91428-04) 68X001352 Rev0 0717 1065DGMAN_91428-03,-04...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ........1 2. SAFETY PRECAUTIONS ......2 3. SPECIFICATIONS ........3 4. BATTERY INSTALLATION ...... 6 5. OPTIONAL RUBBER ARMOR ....7 6. OPTIONAL HANDS-FREE KIT....8 7. CONNECTING A THERMOCOUPLE ..9 8. KEY FUNCTIONS ......... 11 9. -
Page 3: Introduction
• Menu driven setup and operation • Data logging for up to 1000 points on model 91428-03, 2000 points on model 91428-04 • USB output (model 91428-04 only) • Differential temperature measurements •... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS WARNING: This instrument is designed to accept low level signals supplied by standard Thermocouples. Under NO circumstances should the input voltage exceed the specified 50V RMS. To prevent ignition of a hazardous atmosphere, batteries must only be changed in an area known to be nonhazardous. -
Page 5: Specifications
SPECIFICATIONS Thermocouple Thermometers Type Temperature range –210°C to 1200°C Type J (–346°F to 2192°F) –250°C to 1372°C Type K (–418°F to 2501°F) –250°C to 400°C Type T (–418°F to 752°F) –250°C to 1000°C Type E (–418°F to1832°) 0°C to 1768°C Type R (model 91428-04 only) (32°F to 3214°F) - Page 6 Types R, S, and B: ±0.1% of reading ±1°C (±0.1% ±2°F) Display: Backlit dot matrix, 50mm x 37.2mm Data logging: Model 91428-03: 1000 points Model 91428-04: 2000 points Logging interval: 1 sec to 60 min Min/Max/Avg function: Auto Off (adjustable time):...
- Page 7 Input protection: 50V rms Storage: –40°C to 65°C (–40°F to 149°F) Humidity: 10% to 90% RH (noncondensing) Battery life: Size: Three AA, 1.5V; alkaline Life: 400 hours continuous, typical, (without backlighting) Dimensions: Without armor: 175mm (L) X 97mm (W) X 42mm (H) With armor: 180mm (L) X 102mm (W) X 52mm (H) Weight with batteries:...
-
Page 8: Battery Installation
BATTERY INSTALLATION The total battery life without backlighting and alarm is about 400 hours. The battery bar annunciator represents the battery strength. An empty battery annunciator indicates low battery strength; a blinking battery annunciator indicates that the batteries should be replaced immediately. -
Page 9: Optional Rubber Armor
RUBBER ARMOR To insert thermometer into the optional rubber armor, slide in from the top of meter before pushing the bottom edges of meter down to set it into position. Lift up the stand at the back of meter for bench top applications if necessary. -
Page 10: Optional Hands-Free Kit
OPTIONAL HANDS-FREE KIT You can use the optional magnets and strap in the Hands-Free Kit accessories for convenient hands-free operations. - 8 -... -
Page 11: Connecting A Thermocouple
CONNECTING A THERMOCOUPLE Use the correct thermocouple type for your instrument setting. Using an incorrect thermocouple type will result in erroneous readings. Thermocouples are colour coded by type using the North American ANSI Color Code as follows: TYPE COLOR Black Yellow Blue Purple... - Page 12 Thermocouple wiring polarity must be correct. If readings decrease as the temperature increases, the thermo- couple wires may be reversed. The red wire is negative for thermocouple wires manufactured in North America. If no probe is connected the display will read “open”. Thermocouples are sensitive at the tip or measuring junction.
-
Page 13: Key Functions
KEY FUNCTIONS Step through Min, Max and Avg readings. Choose probe T1, T2 or T1- Toggle between menu and measure mode hold Freeze display Turns meter on and off (press and hold for 3 on/off seconds to turn off) light Press momentarily to turn on backlight Recalls and steps through... -
Page 14: Display Overview
DISPLAY OVERVIEW The dot matrix display features a large primary display, smaller secondary displays for channel info or Min/Max/ Avg readings, and helpful annunciators for added measurement data. HOLD - Active Data logging is Active Alarm enabled – channel in alarm indicated: T1 or T2 or T1&T2 MAX/MIN/AVG of Secondary channel if MIN/MAX/AVG activated... -
Page 15: Measurement Mode
MEASUREMENT MODE On initial start-up, the meter will display the measured value for input one in the primary display and for input two in the secondary display. Pressing the F2 key will toggle primary display through input one (T1), input two (T2), and the delta (T1 –... -
Page 16: Hold Functon
HOLD FUNCTON Press the hold key to retain the reading on the display. Press the hold key again for normal operation. MIN, MAX, and AVG FUNCTION Press the F1 key to toggle between the minimum, maximum, and average readings. This function is ideal for monitoring unattended operations while continually displaying every temperature change that occurs. -
Page 17: Data Logging
SETUP MODE To access the setup mode from measurement mode, press the F3 key (Menu). Press ▲▼ keys on the meter keypad to scroll through options. To enter a setup screen, press Select F1 key. To return to measurement mode press Meas F3 key. -
Page 18: General Setup Screen
GENERAL SETUP SCREEN The first page of the General Setup screen lets you set probe type, measurement units, time, and date. Press F1 to indicate you want to change the setting of the current parameter or recall▲ or log▼ to move to the next parameter. - Page 19 On the second page, you can set auto-off time, line frequency, and password. This screen below is used to reset/change password. In the event if uses forget his/her password, 5586 can be used to reset to a new value - 17 -...
-
Page 20: Calibration Screen
CALIBRATION SCREEN The thermometer is factory calibrated and does not require calibration before use. The Calibration function allows single- point calibration of the meter at 0°C (32°F) to compensate for thermocouple offset error. It is NOT necessary to perform a field calibration to obtain specified meter accuracy. - Page 21 Select calibration method by pressing F1 and the ▲ or ▼ keys. Then select the channel you with to calibrate the ▲ or ▼ keys . Offset Calibration Use the ▲ or ▼ keys to adjust the value to match known temperature standard. Press F1 to accept.
- Page 22 Slope Calibration Use the ▲ or ▼ keys to adjust the value to match known temperature standard. Press F1 to accept. Then move to second temperature point using the ▲ or ▼ keys and repeat. Match Calibration Use the ▲ or ▼ keys to adjust the value to match T1 readings and T2 readings.
-
Page 23: Alarms Screen
ALARMS SCREEN Disable or enable the alarm for individual probe by pressing recall▲ or log▼ and F1 to accept. Increase or decrease individual limit by pressing recall▲ or log▼. - 21 -... -
Page 24: Data Logging Screen
DATA LOGGING SCREEN Data Transfer from Meter to Computer (Model 91428-04 only) Press recall▲ or log▼ to choose the logging methods as auto or manual. If it is auto logging, using recall▲ or log▼ to set time interval. Its range is from 0 min to 60 min. -
Page 25: Calibration Report Screen
Once the USB connection is established, press the Start button to download data from Meter to PC using HyperTerminal. CALIBRATION REPORT SCREEN The Calibration report will show the time and date along with results of the last user calibration. - 23 -... -
Page 26: Clear / Reset Screen
CLEAR / RESET SCREEN Press F1 to choose which data you want to clear or reset. For calibration, logged data, and reset all, you will have to enter the password to proceed. (Default Password is 9900) - 24 -... -
Page 27: Maintenance
MAINTENANCE Properly used, the thermometer should maintain calibration indefinitely and not require service other than occasional cleaning of the housing and changing of the batteries. CLEANING WARNING: TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE BY ELECTROSTATIC DISCHARGE, CLEAN WITH DAMP CLOTH. Do not clean with abrasives or solvents. -
Page 28: Troubleshooting
TROUBLESHOOTING The following chart lists the most probable faults. There are no internal adjustments or user-replaceable parts. FAULT ACTION Check condition of batteries. Check that batteries are inserted Display properly. Display shows Out-of-range indication. - - - - Display No thermocouple connected in shows the connector. -
Page 29: Accessories
ACCESSORIES Replacement Meters and Meter Accessories Item Number Dual-input J/K/T/E thermocouple 91428-03 thermometer Dual-input data logging thermocouple 91428-04 thermometer 35427-80 Rubber armor with stand Hands-free kit (two magnets and 35427-85 strap) 35427-86 USB cable (model 91428-04 only) 08516-55 General-purpose probe, type K... -
Page 30: Warranty
WARRANTY The Manufacturer warrants this product to be free from significant deviations from published specifications for a period of three years. If repair or adjustment is necessary within the warranty period, the problem will be corrected at no charge if it is not due to misuse or abuse on your part as determined by the Manufacturer. -
Page 31: Innocal Calibration And Repair Services
® INNOCAL CALIBRATION AND REPAIR SERVICES Optimum performance of your temperature-measuring instrument is not a timeless condition. To ensure quality measurements, have your instrument ® calibrated regularly. Trust InnoCal satisfy your calibration and equipment repair needs. With over a decade of service, we've helped thousands of customers meet ISO, FDA, EPA, GLPs/cGMPs and other quality standards. - Page 32 Reliable Support Trust in our free diagnostic support and troubleshooting advice. Our factory- trained metrologists and technicians are armed with years of experience and extensive technical data. Convenient Reminders It’s so easy to keep your instruments functioning properly. Based on your requirements, InnoCal will send you a reminder when it’s time to recertify or service your instrument.
- Page 33 With today's high quality standards such as ISO 9000, certification is becoming increasingly important. Traceability is not a timeless condition. It must be verified and maintained over the life of the calibration to ensure the highest accuracy possible. When you have your calibration done by InnoCal, we will send you an automatic reminder when it is time to recalibrate your instrument.
- Page 34 Products, please contact your nearest distributor or Formatted: Font: 9 pt, Bold Cole-Parmer Toll-Free: 1-800-323-4340 Formatted: Left, Indent: Left: 0.08 Phone: 1-847-549-7600 Exactly 12 pt Fax: 1-847-247-2929 Formatted: Left, Indent: Left: 0.08 ColeParmer.com/Digi-Sense Exactly 12 pt 1065DGMAN_91428-03,-04 - 32 -...
