Brinsea Ova-Easy Advance Series II User Instructions

Hide thumbs Also See for Ova-Easy Advance Series II:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Using
Contents
Section
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Read the instructions before use!
Damaged appliances shall not be used.
The appliance and its supply cord must be placed in an indoor area not subject to splashes of
water or wet conditions and protected from or out of reach of animals.
Repairs shall be carried out only by a suitably qualified person.
This appliance shall not be used, cleaned or maintained by children or persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge without supervision.
Children shall not play with the appliance.
Ensure that nothing can restrict the movement of the trays or setting shelves. This may damage
the turning mechanism and invalidate the guarantee. Load the setting shelves evenly to help
prevent imbalanced operation. Ensure trays are pushed to the back of each shelf.
Disconnect the incubator from the mains power supply during cleaning. Ensure that all electrical
parts are kept dry.
Record your appliance serial number here: __________________
OVA-EASY 100
User Instructions
Subject
1
MJ1023 GB Issue 01
Page
2
3
3
4
6
9
9
10
12
13
13
14
15
15
17
19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ova-Easy Advance Series II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brinsea Ova-Easy Advance Series II

Summary of Contents for Brinsea Ova-Easy Advance Series II

  • Page 1: Table Of Contents

    MJ1023 GB Issue 01 OVA-EASY 100 ADVANCE User Instructions Contents Section Subject Page Introduction Unpacking Location and Installation Quick Reference Digital Control System Storage of eggs Temperature Humidity and Ventilation Egg Turning Egg Setting Periodic Incubation Cooling Hatching Cleaning up Troubleshooting Servicing and Calibration Specifications...

  • Page 2: Advance

    MJ1023 GB Issue 01 1 Introduction These instructions detail the operation of your new Ova-Easy Advance Series II Digital Cabinet Egg Incubator with programmable automatic egg turning system. Please read these instructions carefully before setting up your machine to achieve best results and keep these instructions safe for future reference. This...

  • Page 3: Unpacking

    Open the door and place the water evaporation pan in the front of the incubator and fill with 1:200 mix of water and Brinsea disinfectant solution. The water level should be no higher than the first ridge of the tray. Place the Evaporation Block upright across the front of the pan (in the slot). Place the flat lid on the pan and slide the pan back into the cabinet so that the evaporation block is at the front of the cabinet.

  • Page 4: Quick Reference

    MJ1023 GB Issue 01 4 Quick Reference (please read relevant section for detail) This quick reference is intended to allow users to quickly set up the incubator and learn the key features of the control system. Please read the rest of the instructions to obtain a full understanding of each feature. PRESS BOTH BUTTONS TO UNLOCK THE MAIN MENU SELECT THE OPTION / RETURN TO THE MENU.
  • Page 5 MJ1023 GB Issue 01 MAIN MENU – QUICK REFERENCE 37.5C INCUBATION TEMPERATURE. TEMP RANGE 20.0 – 40.0°C (68.0- 104.0°F).   DEFAULT 37.5°C (99.5°F). RELATIVE HUMIDITY. RANGE 20% – 80%. RH 20% DEFAULT 20%.   ONLY FOR EX VERSION WITH EX ONLY ADVANCE HUMIDITY PUMP –...

  • Page 6: Digital Control System

    (see section 11) the asterisk will be replaced by an arrow: “↓”. The asterisk "*" adjacent to the relative humidity display is only on when the pump control output is on (see section 8) and is only applicable when using the optional Brinsea Advance Humidity Management Module.
  • Page 7 MJ1023 GB Issue 01 HIGH TEMPERATURE ALARM DISPLAY – If the measured temperature goes up by more than the figure in the ALARM HI screen, the alarm will sound immediately and “+T” will be displayed. Press OK to silence the alarm for 30 minutes. If the high temperature problem rectifies itself the “+T”...
  • Page 8 MJ1023 GB Issue 01 AUTOMATIC SHELF LEVELLING TO PREVENT THE RISK OF POSSIBLE INJURY OR DAMAGE TO THE MECHANISM NEVER INITIATE A TURN WITH THE DOOR OPEN. THE MOTOR WILL BE SWITCHED OFF IF THE DOOR IS NOT FULLY CLOSED AND A FAULT MESSAGE MAY BE SET. AN ALARM SOUNDS AT THE START OF EACH TURN TO WARN THE OPERATOR.

  • Page 9: Storage Of Eggs

    MJ1023 GB Issue 01 6 Storage of eggs Store eggs in cool, damp conditions. Most species may be safely stored for up to 14 days before serious reductions in hatch rates are likely. Daily turning of stored eggs also helps maintain hatchability.

  • Page 10: Humidity And Ventilation

    MJ1023 GB Issue 01 8 Humidity and Ventilation Short term variations in humidity are not important. The average humidity over the incubation period needs to be near optimum to achieve the ideal weight loss. High humidity for the day or two of hatching is also important.
  • Page 11 Resist the temptation to open the door frequently – leave for at least 6 hours between inspections. The Brinsea Advance Humidity Pump is available as an option on the Ova-Easy Advance incubators. The incubator digital control system not only reads the humidity in the incubator but it provides a control signal to operate the water pump and accurately maintain the humidity level at the desired level.

  • Page 12: Egg Turning

    MJ1023 GB Issue 01 9 Egg Turning SWITCHING AUTOMATIC TURNING ON AND OFF Press the - and + buttons simultaneously to unlock the Main Menu. Scroll to the TURN 0 / 1 option and press OK to select the Turn on/off screen. Press the + button to switch turning on (1) or the –...

  • Page 13: Egg Setting

    Cooling is an entirely natural process as most birds will get off the nest at least once a day and leave the eggs unheated for a significant time. From Brinsea’s 35 year experience, the best hatch rates are always achieved when the incubator can best mimic the natural nest conditions.

  • Page 14: Hatching

    MJ1023 GB Issue 01 The periodic cooling feature turns the incubator’s heater and low temperature alarm off for a selectable period but keeps the fans running. After the cooling period is complete the incubator reverts to normal temperature and the alarm is automatically reset. 11.1 SETTING THE COOLING PERIOD.

  • Page 15: Cleaning Up

    14.1 Poor hatching results are frustrating and can be caused by a large number of factors. The most common are given below. Brinsea Products will not be held responsible for loss of eggs or chicks under any circumstances. A wealth of advice and information is available on our website:- www.brinsea.co.uk...
  • Page 16 Strong electrical interference perhaps from a faulty appliance or lights. Restart the incubator and try a different power socket or a “surge protector” type socket adaptor. If the error message occurs again please contact Brinsea Products at the address at the end of these instructions.

  • Page 17: Servicing And Calibration

    OK button. Check temperature calibration after resetting to defaults. 15.3 If the problem persists contact your distributor or Brinsea Products Service Dept. 15.4 The digital temperature and humidity display is individually calibrated during manufacture but may be re-calibrated if required.
  • Page 18 PLACE HYGROMETER IN CENTRE WITH NO WATER IN THE EVAPORATING TRAY.   CAL! HUMIDITY PUMP CYCLE TIME. RH CYCLE RHC 7S ONLY APPLICABLE WHEN USED WITH THE BRINSEA ADVANCE HUMIDITY   PUMP. AMBIENT TEMPERATURE COMPENSATION. T 20.0C AMBIENT AMBIENT TEMPERATURE USED IN HEATER CONTROL ALGORITHM.

  • Page 19: Specifications

    Brinsea Products Ltd, 32-33 Buckingham Road, Weston Industrial Estate, Weston-super-Mare, N. Somerset, BS24 9BG Tel: +44 (0) 845 226 0120 Fax: +44 (0) 1934 708177 e-mail: sales@brinsea.co.uk, website:...
  • Page 20 MJ1023 GB Issue 01 Declaration of Conformity BRINSEA PRODUCTS LTD. 32-33 Buckingham Road Weston Industrial Estate Weston-super-Mare North Somerset BS24 9BG Declare under our sole responsibility the products: Egg Incubators: Ova-Easy 100 Advance Series 2 (Serial numbers MJ1023x/xxxxxxxxx) Ova-Easy 100 Advance Series 2 EX (Serial numbers MJ1033x/xxxxxxxxx)
