Magic Chef MCSRE24S User Manual page 21

OvEN DOOR ExTERIOR
• Use a glass cleaner and a soft cloth or sponge.
• Apply glass cleaner to soft cloth or sponge, not directly on panel.
REMOvING AND ClEANING OvEN DOOR
For normal range use, it is not suggested to remove the oven door. However, if removal is necessary, make sure the
oven is off and cool. The oven door is heavy. Follow these instructions.
1. Open the door fully. (Refer to Figure 17.)
2. lift up and push the small levers located on the two hinges all the way back. (Refer to Figure 18.)
3. While holding the door on each side, shut the door until it touches the levers.
4. Then continue closing the door until it is about 4" (100 mm) from being fully closed.
5. Pull the door towards you, pulling it out of its seat. Door will gently come away from the oven. (Refer to
Figure 19.)
6. To replace the door, perform the reverse of the above procedure.
NOTE: If door does not come away from oven easily, DO NOT force it.
CHANGING THE INTERIOR OvEN lIGHT bUlb
WARNING: To reduce the risk of electric shock, ensure that the
appliance is switched off before replacing the lamp.
1. Remove the glass cover by turning it counter-clockwise. (Refer
to Figure 20.)
2. Replace light with a high temperature bulb that meets the
following criteria:
• 240 V
Figure 17
• 25 W • Type: E-14
Figure 18
21
Figure 19
Figure 20
