Hardware and Power Specifications

It is important to ensure each node in the system will have the proper power and cooling available and will
meet your solution needs. You'll find the hardware specifications, power and heat requirements, and racking
process for each Scale Computing product line in this chapter.

HC1100 Series Nodes

These are the entry level HC3 systems. This Series includes the HC1100, HC1150, HC1150D, and
HC1150DF.

Hardware and Upgrade Options

Current base model designs of each node in the HC1100 Series as well as their upgrade options.
HC1100
NODE
CPU
RAM
Networking
Storage
Rack
Power
Certifications
04/2018
Base Model Description
Intel E5-2603v4
6 Cores
6 Threads
1.7GHz
64GB (DDR4)
4 x 1GbE NICs
2 Public NICs bonded active/passive
2 Private NICs bonded active/passive
NL-SAS (7200 RPM)
4TB (4 x 1TB) RAW Capacity
1U Height
1.7" (43mm) H x 17.2" (437mm) W x
19.85" (503mm) D
2 x 400W Power Supply Units
UL/CB
CE
FCC
Power, heat, and hardware details
Upgrade Options
Intel E5-2620v4
8 Cores
16 Threads
2.1GHz / 3GHz
128GB (DDR4)
4 x 10GbE NICs
2 Public NICs bonded active/passive
2 Private NICs bonded active/passive
NL-SAS (7200 RPM)
8TB (4 x 2TB) RAW Capacity
16TB (4 x 4TB) RAW Capacity
32TB (4 x 8TB) RAW Capacity
N/A
N/A
N/A
