INSTRUCTION MANUAL
MODEL# CBT806
Outdoor Portable Charcoal Grill
For Outdoor Use Only!
Warning! Be careful of sharp edges during assembly.
Made In China
Save these instructions for future reference. If you are assembling this unit for someone
else, give this manual to them to read and save for future use.
Contact 1-800-694-0013 for assistance. Do not return to place of purchase.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CBT806 and is the answer not in the manual?

Questions and answers

Summary of Contents for RevoAce CBT806

  • Page 1 INSTRUCTION MANUAL MODEL# CBT806 Outdoor Portable Charcoal Grill For Outdoor Use Only! Warning! Be careful of sharp edges during assembly. Made In China Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to them to read and save for future use.
  • Page 2: Parts List

    Parts & Hardware List Parts List Expanded View Lid Handle C0806-020 C0806-020 Air Vent B0105-A01 Top Hinge (2) B0120-C01 Bottom Hinge (2) B0120-C02 Bottom Bowl C0806-030 Air Damper (2) C0806-040 Leg Assembly (4) C0806-050 Charcoal Grid C0806-060 Cooking Grid C0806-070 Warming Rack C0806-080 Lock*...
  • Page 3 Assembly Instructions Tools Required: Knife or scissors and Phillips head screwdriver . To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or openings. . Clear an area large enough to layout all components and hardware. .
  • Page 4 Step 3 Attach leg assembly to bottom bowl (B Screw 4Pcs / D Wing nut 4Pcs). Step 4 Attach top hinge to bottom hinge (G Pin 2Pcs / H Cotter pin 2Pcs) Note: If top hinge does not fit into bottom hinge, gently squeeze top hinge tabs together.
  • Page 5 Step 5 Slide warming rack into holes in lid and bottom bowl. Note: Look for corresponding holes on side of lid, insert short wire ends into lid hole one side at a time. Position warming rack legs into slots on bottom bowl sides. Step 6 Insert charcoal grid and cooking grid into bottom bowl.
  • Page 6 Appendix This grill can be folded for your easily take. Please refer to steps below: Lock lid (Note: Lid must be locked before transporting) To unlock: lift up on lock handle, remove lock bracket from rise on lid, push lock handle down. Fold grill (Note: Always lock lid before fold grill).
