RevoAce P1409MIA Manual

Outdoor portable charcoal grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Outdoor Portable Charcoal Grill
Model No. P1409MIA
For Outdoor Use Only!
Warning! Be careful of sharp edges during assembly.
Made In China
Save these instructions for future reference. If assembling this unit for someone else, give
them this manual to read and save for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P1409MIA and is the answer not in the manual?

Questions and answers

Related Manuals for RevoAce P1409MIA

Summary of Contents for RevoAce P1409MIA

  • Page 1 Outdoor Portable Charcoal Grill Model No. P1409MIA For Outdoor Use Only! Warning! Be careful of sharp edges during assembly. Made In China Save these instructions for future reference. If assembling this unit for someone else, give them this manual to read and save for future use.
  • Page 2 Parts & Hardware List Expanded View Parts List 1. Air vent 2. Lid handle 3. Lid 4. Cooking grid 5. Charcoal grid 6. Bottom bowl 7. Wire handle 8. Ash receiver 9. Leg (2) Hardware List (Included) A: Screw M4x5 Nickel Plated Single Phillips Truss Head 3Pcs / B: Screw M4x10 430SS Truss Head 1Pc / C: Screw M5x12 Nickel Plated Phillips Truss Head 6Pcs / D: Round nut M4 Nickel Plated 3Pcs /...

  • Page 3: Assembly Instructions

    Assembly Instructions For easiest assembly: 1. Choose an area with a smooth surface, free of cracks and openings that will protect components during the assembly process. 2. Spread out all parts. 3. Tighten all hardware connections by hand first. Then, before completing each step, go back and fully tighten all hardware. Be careful not to over-tighten.
  • Page 4 Step 3 Attach leg to bottom bowl (C Screw 4Pcs / G Washer 4Pcs / J Lock washer 4Pcs / F Wing nut 4Pcs). Step 4 Attach ash receiver to bottom bowl.
  • Page 5 Step 5 Attach wire handle to bottom bowl (H Washer 2Pcs). Step 6 Insert charcoal grid into bottom bowl. Insert cooking grid into bottom bowl. Cover lid onto bottom bowl.
  • Page 6 Step 7 Congratulations, your assembly is now complete. Read operating instructions before proceeding.

  • Page 7: Helpful Hints

    SAFETY HINTS 1. Stand your grill on a safe, level surface away from flammable items such as wooden fences, house siding, overhead lines or over hanging tree branches. NEVER USE your grill indoors. 2. DO NOT use petrol, paraffin, methylated spirit or lighter fuel to light your charcoal. 3.
