Summary of Contents for Compulite Luna

  • Page 1: Luna And Nova Yokes

    Luna and Nova Yokes...
  • Page 2 No part of this product or document may be reproduced in any form by any means without the prior express written authorization of Compulite Systems (2000) Ltd. and its licensors (if any). Information contained herein is subject to change without notice.

  • Page 3: Table Of Contents

    Contents User Guide:......................1 Luna and Nova Yokes)..................1 Introduction ..................4 Attaching Yoke to Luminaire............. 4 Interface....................... 5 Connectors..................5 Control Panel ................... 6 Operation..................... 7 Programming the Yoke..............7 Modes ........................Test Mode....................8 Technical Specifications ................9 Doc.

  • Page 4: Introduction

    Luna and Nova yokes have a self-locking system, last position memorization, programmable pan and tilt limits, and an internal power supply. They are quiet and extremely accurate. Luna’s maximum load is 15 kg. Nova’s maximum load 30kg. Luna and Nova use servo controlled 24 VDC motors with mechanical overload protection (torque limiter and friction clutch) for both the X and Y axes.

  • Page 5: Interface

    L u n a a n d N o va Y o k e s Interface Connectors AC In Fixture power cable DMX Thru DMX In Figure 1 Top panel Scroller (option) Focus (option) Fixture AC cable Figure 2 Connectors on Yoke arms Doc. Version 1.01 Compulite Systems (2000)

  • Page 6: Control Panel

    Control Panel Figure 3 Display, LEDs, and Control Keys Display Luna and Nova are equipped with LED Smart displays. The display can be inverted for orientation according to the yoke’s physical rigging, whether hanging or standing. There are two display modes: bright and dim. During programming the display is bright.

  • Page 7: Operation

    5. Press STORE again Note Pressing any key at any time stops yoke travel and disrupts DMX communication for 15 seconds. At the end of the 15 second period, DMX communication is resumed. The display dims. Doc. Version 1.01 Compulite Systems (2000)

  • Page 8: Modes

    The test lasts for 10 minutes or until any button is pressed. Keypresses Results/Comments 1. Press MODE until COM is displayed 2. Press any key except The Yoke goes to Test mode. MODE. 3. Press any key to exit Test. Doc. Version 1.01 Compulite Systems (2000)

  • Page 9: Technical Specifications

    Position resolution +- 2 cm. @ 10 m. Repeatability Signal input DMX 512 DMX Assignment 8 bits 16 bits Channel high Channel tilt Channel focus/iris tilt high Channel dimmer tilt Channel focus/iris Channel dimmer Doc. Version 1.01 Compulite Systems (2000)
  • Page 10 Pin 3 – DMX (+) Pin 4 - +48v Features: Switch off the power of the motor when it hits some obstacles. Shut down when it arrives end position. Options Focus or Iris Color changer connector Doc. Version 1.01 Compulite Systems (2000)
