IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS
C2204/FMTPJ01NDCH
FRONT TIEDOWNS
Minor movement (or settling) can occur in some incidental harsh driving conditions
(on or off road).
A rubber bed mat is not a requirement to maintain the lifetime warranty on a Torklift sys-
tem, but a strong recommendation, simply as a safety precaution to protect the truck bed,
the bottom of the camper and to give the camper additional support.
Warning!!
TORKLIFT DOES NOT RECOMMEND: Installing your truck camper in your truck on top of
a drop in plastic bed liner!!! THIS WILL VOID YOUR WARRANTY!
The drop in plastic bed liners can slide on top of the truck bed surface, and the camper can
slide on top of the slick surface of the bed liner. The liner can also act as a spring causing a
trampoline effect increasing vertical truck camper movement, independent of the vehicle,
possibly resulting in truck bed damage and/or camper damage!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Torklift C2204
Summary of Contents for Torklift C2204
- Page 1 Minor movement (or settling) can occur in some incidental harsh driving conditions (on or off road). A rubber bed mat is not a requirement to maintain the lifetime warranty on a Torklift sys- tem, but a strong recommendation, simply as a safety precaution to protect the truck bed, the bottom of the camper and to give the camper additional support.
- Page 2 TIE DOWN DIAGRAM UPPER SUPPORT STRAP TRUCK FRAME CLAMP STRAP WELDED BOLTS FRAME MOUNTED TIEDOWN RECIEVER PLATE...
-
Page 3: Installation
There is enough room to install the C2204 Tie Down between the frame and the gas tank, but if the tank is closer than normal, you may choose to loosen the straps for the tank and move it away from the frame while completing the installation. - Page 4 3. Next attach the upper support strap to the tie down receiver pocket unit using the supplied 1/2” x1-1/2” Hex Bolt with one 1/2” flat washer one 1/2” lock wash- er, and one 1/2” Hex nut (See Photo 8). NOTE: THE LONG TAPERED END OF THE CLAMP STRAP POINTS DOWN AND GOES TOWARD THE FRONT OF THE TRUCK! * ‘07 New Body Style E-brake cable addendum (see page 9).
-
Page 5: Illustrated Diagrams
ILLUSTRATED DIAGRAMS PHOTO 1 PHOTO 2... - Page 6 PHOTO 3 PHOTO 4...
- Page 7 PHOTO 5 PHOTO 6...
- Page 8 PHOTO 7 PHOTO 8...
- Page 9 Photo F Photo G The e-brake cable has been relocated to above the tiedown receiver on the ‘07 new body style truck (Photo F). The e-brake cable is specially coated, and was designed specifically for direct metal contact, as shown above (Photo G) where the e-brake can be seen contacting the factory installed cable guides.
- Page 10 INSTRUCTIONS FOR MAINTENANCE OF POLISHED STAINLESS STEEL PRODUCTS Torklift utilizes quality grade 304 stainless steel in this product. 304 stainless steel is well known for its anti cor- rosive properties, however in some environments such as coastal regions or when in contact with some road chemicals, corrosion may occur.
- Page 11 TorkLift TRUE frame mounted tie downs are far superior to all tie down systems available. The TorkLift system is unique in its design and is patented. Four independent tie down points (with no belly or crossbar) working much like your...
- Page 12 TORKLIFT’S BOLT FISHING GUIDE Your guide to understanding the installation of our frame mounted tie downs. Note: The hardware may vary as to what is being fished along with -Coiled End of Bolt Fisher- the bolt. In this instance a 1” X 2”...
- Page 13 INSTRUCTIONS On one end of each of your tiedown inserts is a triangular plate referred to by Torklift as a bullet plate. Your tiedown inserts should be installed with the shorter side of the bullet plate facing away from each other, i.e..
- Page 14 TURNBUCKLE SPRINGLOAD OPTIONS CONTACT YOUR LOCAL DEALER FOR MORE DETAILS Torklift requires all 4 tiedown points to be spring loaded in order to qualify for our manufacturer’s Industry Exclusive “Camper Anchor” and “Truck Frame” Warranty BASIC SPRINGLOAD KIT - S9000 Includes 2 External Springload Cylinder Units, 2 Heavy Duty Forged Turnbuckles and 24”...
- Page 15 Minor movement (or settling) can occur in some incidental harsh driving conditions (on or off road). A rubber bed mat is not a requirement to maintain the lifetime warranty on a Torklift system, but a strong reccommendation simply as a safety precaution to protect the truck bed, the bottom of the camper and to give the camper additional support.
