Summary of Contents for Torklift C2204
- Page 1 IMPORTANT OWNER-OPERATOR INSTALLATION INSTRUCTIONS C2204 REVISED ver7 BY: JL 08/5/15 TECH SUPPORT (800) 246-8132 AFTER INSTALL, PLEASE GIVE THIS BOOKLET TO YOUR CUSTOMER...
- Page 2 Warnings Truck Bed and Camper Protection Torklift does not recommend installing your camper on top of a plastic bed liner (or other compressible material such as foam). These materials can act as a spring, causing increased vertical truck camper movement independent of the vehicle. Plastic bed liners can slide on the truck bed surface, and the truck camper can slide on top of the bed liner.
- Page 3 TIE DOWN DIAGRAM UPPER SUPPORT STRAP TRUCK FRAME CLAMP STRAP WELDED BOLTS FRAME MOUNTED TIEDOWN RECIEVER PLATE...
-
Page 4: Installation
There is enough room to install the C2204 Tie Down between the frame and the gas tank, but if the tank is closer than normal, you may choose to loosen the straps for completing the installation. - Page 5 3. Next attach the upper support strap to the tie down receiver pocket unit using the supplied 1/2” x1-1/2” Hex Bolt with one 1/2” flat washer one 1/2” lock washer, and one 1/2” Hex nut (See Photo 8). NOTE: THE LONG TAPERED END OF THE CLAMP STRAP POINTS DOWN AND GOES TOWARD THE FRONT OF THE TRUCK! * ‘07 New Body Style E-brake cable addendum (see page 9).
-
Page 6: Illustrated Diagrams
ILLUSTRATED DIAGRAMS PHOTO 1 PHOTO 2... - Page 7 PHOTO 3 PHOTO 4...
- Page 8 PHOTO 5 PHOTO 6...
- Page 9 PHOTO 7 PHOTO 8...
- Page 10 Photo F Photo G The e-brake cable has been relocated to above the tie down receiver on the ‘07 new body style truck (Photo F). The e-brake cable is specially coated, and was designed specifically for direct metal contact, as shown above (Photo G) where the e-brake can be seen contacting the factory installed cable guides.
- Page 11 On one end of each of your tie down inserts is a triangular plate referred to by Torklift as a bullet plate. Your tie down inserts should be installed with the shorter side of the bullet plate facing away from each other, i.e.. The shorter side of the front insert should point to the front of the truck and the shorter side of the rear insert should point towards the rear of the truck.
- Page 12 Due to the extreme, harsh, undercar environment that your Torklift products live in, (consistently sprayed with corrosive road chemicals such as salt, and road debris), Torklift does not warranty the power coated finish. To minimize corrosion from these factors on powder coated steel products,...
- Page 13 Warranty Information 322 Railroad Ave North, Kent, WA 98032 Torklift will require proof of purchase to register, with pictures of any defective product before issuing a replacement. Torklift will not register any product without proof of purchase, which can be faxed, scanned, emailed, or mailed to the information provided below.
- Page 14 Thank you for making TorkLift your choice for truck, camper packages and accessories for your vehicle. By choosing TorkLift products, you have chosen a company that has been serving the RV industry for nearly 40 years and whose name has become synonymous with strength, quality and advanced design and installation.
- Page 15 They are designed for each make and model to fit tight to the frame so as not to compromise ground clearance. TorkLift tie downs are not universal ‘one size fits all’ therefore all the problems with correct fit for each particular application have been eliminated.
- Page 16 OFFICIAL WARRANTY REGISTRATION CARD PLEASE FILL OUT THIS FORM COMPLETELY AND RETURN TO TORKLIFT WITHIN 30 DAYS OF PURCHASE ACCOMPANIED BY A COPY OF YOUR ORIGINAL RECEIPT TODAY’S DATE: _________________________ 1. PART(S) PURCHASED PART#: ___________________ PART#: _______________________ PART#: ___________________ PART#: _______________________ 2.
