DFI GM341-GHF Installation Manual

Hide thumbs Also See for GM341-GHF:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
GM341-GHF Installation Guide
• One GM341-GHF system unit
• Demonstration kit:
- I/O board
- Five I/O cables (red, blue, green, yellow, and orange)
- A USB cable (type-A connector to type B-connector)
- Gaming software package
Note:
The software package that came with the system contains application and code samples
to implement gaming software for the system.
DFI reserves the right to change the specifications at any time prior to the product's release. For the
latest revision and details of the installation process, please refer to the user's manual.
Package Contents
www.dfi.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the GM341-GHF and is the answer not in the manual?

Questions and answers

Related Manuals for DFI GM341-GHF

Summary of Contents for DFI GM341-GHF

  • Page 1 The software package that came with the system contains application and code samples to implement gaming software for the system. DFI reserves the right to change the specifications at any time prior to the product's release. For the latest revision and details of the installation process, please refer to the user's manual.

  • Page 2: Ports And Connectors

    Ports and Connectors DP 0 DP 1 4-pin DC-in DP 2 LAN 1 LAN 2 DP 3 COM 4/5 RS232 (Tx/Rx/12V/-12V/GND) COM 3 RS232 (Tx/Rx/GND) or ccTalk COM 2 (RS232) COM 1 (RS232/RS422/RS485) Speaker 5.1 ch audio Door 1~6 Digital inputs/outputs iButton (from top to down): Door 7...
  • Page 3 Connecting the I/O Board The system supports 32 digital inputs and outputs. The I/O board that came with the package can be connected to the system to test the digital input and output function. Please observe the following guidelines and follow the procedure to con- nect the I/O board.
  • Page 4 To connect the display, use a DisplayPort cable to connect one of the DP ports to a display device. 4-pin DC-in Power LED HDD LED Power Button Reset Button DP 0 DP 1 DP 2 DP 3 www.dfi.com...

  • Page 5: Board Layout And Jumper Settings

    Board Layout and Jumper Settings System Fan Power LED DC_in HDD LED LAN 1 LAN 2 Power Button Reset Button DP 0 SATA 3.0 COM 2 DP 1 COM 3 COM 4/5 SATA 2 DP 2 Ryzen V1000Series/ USB 2.0_4 R1000Series DC_out DP 3...

  • Page 6: Connector Pin Assignment

    Connector Pin Assignment COM 1: RS232/RS422/RS485 COM 2: RS232 1 2 3 4 5 6 7 8 9 Pins RS232 RS232 RS485 DATA- DATA+...
  • Page 7 COM 3: RS232 COM 4/5: RS232 (Tx/Rx/GND/ccTalk) (Tx/Rx/͟ + 12V/GND) Pins Pin Assignment Pins Pin Assignment COM4 RS232-TX COM3 RS232-TX COM4 RS232-RX COM3 RS232-RX +12V power out -12V power out +12V power out ccTalk COM5 RS232-TX COM5 RS232-RX DC-out +12V power out Pins Pin Assignment -12V power out...
  • Page 8 Intrusion Door 1~6 Pins Pin Assignment Pins Pin Assignment Door 1 Door 5 Door 2 Door 6 Door 3 Door 4 Digital Input 1~16/17~32 Pins Pin Assignment Pins Pin Assignment DI 1 / DI 17 DI 11 / DI 27 DI 2 / DI 18 DI 12 / DI 28 DI 3 / DI 19...
