Summary of Contents for DFI AL053-BC-E3930
- Page 1 AL053 Embedded SBC 2.5” User’s Manual A-494-M2003...
-
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules. -
Page 3: Table Of Contents
Table of Contents I/O Connectors ..............18 Digital I/O Connector..............18 Front Audio Connector ..............18 Copyright ........... 2 COM (Serial) Port ................19 SMBus Connector ................20 Trademarks ..........2 Front Panel Connector ..............20 LVDS LCD Panel Connector ............. 21 FCC and DOC Statement on Class B ... -
Page 4: Warranty
Warranty Static Electricity Precautions 1. Warranty does not cover damages or failures that arised from misuse of the product, in- It is quite easy to inadvertently damage your PC, system board, components or devices even ability to use the product, unauthorized replacement or alteration of components and prod- before installing them in your system unit. -
Page 5: About The Package
About the Package The package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. • One AL053 board • One Heat spreader (Height: 11mm) Optional Items • USB port cable (Length: 200mm) •... -
Page 6: Chapter 1 - Introduction
1 x LVDS LCD Panel Connector 1 x LCD/Inverter Power Audio 1 x Audio (Line-out/Mic-in) 1 x 8-bit DIO SMBus 1 x SMBus WATCHDOG Output & System Reset, Programmable via Software from 1 to 255 Seconds TIMER Interval SECURITY fTPM2.0 Chapter 1 Introduction www.dfi.com... -
Page 7: Features
USB 2.0. It is a marked im- provement in device transfer speeds between your computer and a wide range of simultane- ously accessible external Plug and Play peripherals. Chapter 1 Introduction www.dfi.com... -
Page 8: Chapter 2 - Hardware Installation
Chapter 2 Chapter 2 - Hardware Installation Board Layout DC-in USB 0-1 USB 3.1 Gen1 Flash BIOS Buzzer Mini PCIe Intel I210AT or I210IT (opt.) LCD/Inverter & SATA Power LAN 1 Panel Power Select (JP2) Battery Intel USB 2.0 Atom® LVDS PTN3460 Processor... -
Page 9: Block Diagram
Chapter 2 Block Diagram Mechanical Drawing Mini DP++ DDR3L 1866MHz Channel A SODIMM PCIe x1 GLAN 1 I210AT PTN3460 LVDS I210IT (opt.) SATA 3.0 M.2 1x USB 3.1 Gen1 PCIe x1 (B-key 2242) USB 3.1 Gen1/2.0 2x USB 2.0 USB 2.0 Intel Atom ®... -
Page 10: System Memory
Chapter 2 Installing the SODIMM Module Important: Electrostatic discharge (ESD) can damage your board, processor, disk drives, add-in Note: boards, and other components. Perform installation procedures at an ESD workstation The system board used in the following illustrations may not resemble the actual only. -
Page 11: Jumper Settings
Chapter 2 5. Grasping the module by its edges, align the module into the socket at an approximately 30 Jumper Settings degrees angle. Apply firm even pressure to each end of the module until it slips down into the socket. The contact fingers on the edge of the module will almost completely disappear Panel Power Select inside the socket. -
Page 12: M.2 Signal Select
Chapter 2 M.2 Signal Select 1-2 On: SATA (default) 2-3 On: PCIe JP5 is used to select the M.2 signal: SATA (default) or PCIe. Chapter 2 Hardware Installation www.dfi .com... -
Page 13: Heat Spreader Assembly
H e a r f a c I n t e S i d e C P U s i s h a s T o C L e g Chapter 2 Hardware Installation www.dfi.com e r * r e a d... - Page 14 H e a f * 4 f * 4 Chapter 2 Hardware Installation r f a c r f a c www.dfi.com d - o f d - o f I n t e I n t e S t a n...
- Page 15 Configure the onboard LAN in the “ACPI Configuration” submenu of the Advanced menu in the Install the graphics driver. Refer to Chapter 4 for more information. BIOS. Refer to Chapter 3 for more information. Driver Installation Install the LAN drivers. Refer to Chapter 4 for more information. Chapter 2 Hardware Installation www.dfi.com...
-
Page 16: Rear Panel I/O Ports
USB 3.1 Gen1 LAN 1 The rear panel I/O consists of the following ports: • 1 9~36V DC-in 2-pin terminal block • 2 USB 3.1 Gen1 ports • 1 GbE (RJ-45) • 1 Mini DP++ port Chapter 2 Hardware Installation www.dfi.com... -
Page 17: Usb Ports
Chapter 3 for more information. Wake-On-USB Keyboard/Mouse The Wake-On-USB Keyboard/Mouse function allows you to use a USB keyboard or USB mouse to wake up a system from the S3 (STR - Suspend To RAM) state. Chapter 2 Hardware Installation www.dfi.com... -
Page 18: I/O Connectors
The front audio connector allows you to connect to line-out and mic-in jacks that are at the DIO7 front panel of your system. DIO6 Driver Installation DIO5 Install the audio driver. Refer to Chapter 4 for more information. DIO4 DIO3 DIO2 DIO1 DIO0 Chapter 2 Hardware Installation www.dfi.com... -
Page 19: Com (Serial) Port
BIOS Setting Configure the serial port in the “SIO FINTEK81803” submenu of the Advanced menu in the BIOS. Refer to Chapter 3 for more information. Chapter 2 Hardware Installation www.dfi.com... -
Page 20: Smbus Connector
This switch is used to power on or off the system. RESET - Reset Switch This switch allows you to reboot without having to power off the system. Pin Pin Name Pin Pin Name LED Power Signal PWR-SW PWR-LED Signal RESET HD-LED RST signal Signal Chapter 2 Hardware Installation www.dfi.com... -
Page 21: Lvds Lcd Panel Connector
BIOS. Refer to Chapter 3 for more information. Panel Power Panel Power Note: 1. DFI board's LVDS LCD panel connector: 2. DFI board's LCD/Inverter & SATA power connector: Manufacturer: V-STAR Manufacturer: E-call Part No.: W100V40TP2 Part No.: 0110-3221050 Description: 2*20pin, 1.0mm, BOX header... -
Page 22: Battery
SMBus. It can expand the system’s internal I/O connectivity. Please refer to the following table • Replace only with the same or equivalent type recommended by the manufacturer. for pin assignment. • Dispose of used batteries according to local ordinance Chapter 2 Hardware Installation www.dfi.com... - Page 23 USB_SSTX0+ USB_SSTX0- 5VSB 5VSB SATA0_RX+ 5VSB 5VSB SATA0_RX- PCIE_WAKE# Note: SATA0_TX+ DFI board's E I/O connector: SATA0_TX- Manufacturer: Samtec Part No.: QSE-040-01-L-D-A-K-TR SMB_STB_CK Description: Board-to-board connector, 2*40 pin, 0.8mm (pitch), 3.25mm (height), SMD type, 180 degree DDI0_CTRLCLK_AUX+ SMB_STB_DAT DDI0_CTRLCLK_AUX- CLK33M...
-
Page 24: Chapter 3 - Bios Setup
“Press DEL to run setup” will appear on the screen. If the message disappears before you respond, restart the system or press the “Reset” button. You may also restart the system by pressing the <Ctrl> <Alt> and <Del> keys simultaneously. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com... -
Page 25: Insyde Bios Setup Utility
The date format is <month>, <date>, <year>. Month displays the month, from 01 to 12. Date displays the date, from 01 to 31. Year displays the year, from 2000 to 2099. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com... - Page 26 This field is to specify what state the system should be in when power is re-applied after a power failure (G3, the mechanical-off, state). Always On The system working state. Always Off Off, except for trickle current to devices such as the power button. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
- Page 27 Select the LCD panel color depth: 18 Bit, 24 Bit, 36 Bit or 48 Bit. Backlight Type Set the backlight type: Normal+PWM Mode, Normal+DC Mode, Invert+PWM Mode or Invert+DC Mode. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
- Page 28 Select Serial ATA controller(s) speed from Gen1 (1.5 Gbit/s), Gen2 (3.0 Gbit/s) or Gen 3 (6.0 Gbit/s). Serial ATA Port 0/1 and Hot Plug These fields are used to enable or disable the serial ATA ports and their hot plug func- tion. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
- Page 29 Select the speed of the PCI Express Root Port: Auto, Gen1 or Gen2. Help ↑/↓ Select Item F5/F6 Change Values Setup Defaults Exit ←/→ Select Item Enter Select SubMenu Save and Exit Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
- Page 30 Select data bits: 7 Bits or 8 Bits. Parity Select parity bits: None, Even or Odd. Stop Bits Select stop bits: 1 Bit or 2 Bits. Flow Control Select flow control type: None, RTS/CTS or XON/XOFF. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
- Page 31 COM port will be the same as those in Console Redirection section. When disabled the global setting, setting of the COM port can be configured indepen- dently in this section. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
- Page 32 Choose RS232/RS422/RS485 (Peer-to-Peer) for COM type. Enable or disable the watchdog function. A counter will appear if you select to enable WDT. Input any value between 1 to 255 seconds. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com...
-
Page 33: Security
Disabled Suppoort Network Stack Set the supervisor’s password and the length of the password must be greater than UEFI IPv4/IPv6 one character. USB Boot Enable or disable booting to USB boot devices. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com... -
Page 34: Exit
Select this option to save BIOS configuration settings to a USB flash device. Restore Setting from file This field will appear only when a USB flash device is detected. Select this field to restore setting from the USB flash device. Chapter 3 BIOS Setup Chapter 3 BIOS Setup www.dfi.com www.dfi.com... -
Page 35: Updating The Bios
For updating Insyde BIOS in UEFI mode, Due to the safety concerns, the BIOS (SPI ROM) chip cannot be removed from this system you may refer to the how-to-video at https://www.dfi.com/Knowledge/Video/31 . board and used on another system board of the same model. -
Page 36: Chapter 4 - Supported Software
Please download drivers, utilities and software applications required to enhance the perfor- tion tips then click “Install”. mance of AL053 at https://www.dfi.com/product/index/374#download. Intel Chipset Software Installation Utility The Intel Chipset Software Installation Utility is used for updating Windows INF files so that ®... - Page 37 We recommend that you skip this process by disabling this function then click “Next”. 2. Read the license agreement then click “Yes”. 5. Click “Yes, I want to restart this computer now” then click “Finish”. Restarting the system will allow the new software installation to take effect. Chapter 4 Supported Software www.dfi.com...
- Page 38 “Finish”. then click “Next”. Restarting the system will allow the new software installation to take effect. 3. Select the program features you want installed then click “Next”. Chapter 4 Supported Software www.dfi.com...
- Page 39 “Next.” 5. The step displays the installing status in the prog- ress. 2. The step shows the components which will be installed. Then, Click Next. 6. After completing installa- tion, click “Finish”. Chapter 4 Supported Software www.dfi.com...
- Page 40 1. Setup is ready to install the driver. Click “Next”. 4. Click “Finish“ when the installation is complete. 2. Read the license agreement care- fully. Tick “I accept the terms in the Li- cense Agreement” then click “Next”. Chapter 4 Supported Software www.dfi.com...
- Page 41 4. Setup is ready to install the driver. 6. Click “Yes, I want to restart Click “Next”. this computer now” then click “Finish”. Restarting the system will allow the new software installation to take effect. Chapter 4 Supported Software www.dfi.com...
-
Page 42: Appendix A - List Of Connectors
COM 1 V-STAR JCL20161228017: 2*5pin, 1.27mm, PIN PLUG, H= 5mm +5V/1A Digital I/O SMBus V-STAR SHY-JCL 180806P: 2*3pin, 1.27mm, PIN PLUG, H= 5mm +3.3VSB/0.5A V-STAR SHY-JCL 180806P: 2*3pin, 1.27mm, PIN PLUG, H= 5mm Front Panel Appendix A Troubleshooting Checklist www.dfi.com...
