- Page 1 Network Video Recorder Installation Manual IR-300 Powered by...
- Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP™ Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Important Safeguards 1. Read Instructions B. If liquid is spilled, or objects have fallen into the equipment. All the safety and operating instructions should be read before the appliance C. If the equipment has been exposed to rain or water. is operated.
- Page 4 Before reading this manual In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
- Page 5 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.
-
Page 6: Table Of Contents
Table of Contents Part 1 – Introduction ......... 7 Product Features . -
Page 7: Part 1 - Introduction
Part 1 – Introduction Product Features This is a video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: ● UHD resolution support ● H.265 support codec ●... - Page 8 Part 1 – Introduction VGA Monitor DP Monitor HDMI Monitor Audio Out Gigabit PoE Network Switch Camera USB HDD Flash Memory Network Video Recorder Keyboard Microphone Mouse Network Connection...
-
Page 9: Accessories
Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Network Video Recorder Power Cable Installation Manual Optical USB Mouse Keyboard Please download IDIS Center software and product manual from this link: https://www.idisglobal.com/support/csdownload - IDIS Website (www.idisglobal.com) > Support > Technical Resources... -
Page 10: Overview
Part 1 – Introduction Overview Front Panel SATA LED Status LEDs Power Button USB Ports Power LED Front Door Lock Rack Mount Ears • Some buttons have more than one function. • Remote control sensor is located on the left side of the front panel. Ensure that the sensor remains unobstructed at all times. - Page 11 Part 1 – Introduction 4 USB Ports 5 Power LED ● Storage Device Connection Lights up while the main unit is in operation. Connect an external USB hard drive or a USB flash memory device to one of the USB ports for use with the Clip Copy feature.
- Page 12 Part 1 – Introduction Connections on the Front Panel Flash Memory Keyboard Mouse USB HDD...
-
Page 13: Dimensions
Part 1 – Introduction Dimensions Unit : mm... -
Page 14: Rear Panel
Part 1 – Introduction Rear Panel R-300 Power In Port Network Ports USB 2.0 Ports USB 3.0 Ports HDMI eSATA Port RS-232 Port VGA (D-Sub) Audio Connection The LED and Buzzer Control Rules of Redundant Power Condition Power Module #1 Power Module #2 Buzzer AC Cord Included /... -
Page 15: Rear Panel Connections
Do 0506 is compatible. not run the power cable underneath a rug or carpet. IDS1004 IDIS • Only the hard disk from the below list is compatible for the • The power cable is grounded. Do not modify the best performance. - Page 16 Part 1 – Introduction USB Port Monitor Connection Connect to the VGA OUT, HDMI or DP port. Support Super-speed USB 3.0 (5Gbps), High-Speed USB 3.0 (480Mbos) and Full Speed USB 2.0 (12Mbps) for transfer. • Use a certified cable marked with an HDMI logo when using HDMI.
- Page 17 Part 1 – Introduction Connections on the Rear Panel Power Network eSATA Storage Device Monitor Monitor Keyboard Speaker Microphone HDMI Monitor Network Gigabit PoE Camera Switch...
-
Page 18: Part 2 - Raid Configuration
Part 2 - RAID Configuration Introduction This chapter explains how to use JMB39X HW RAID Manager to configure RAID and monitor the status of the disks connected on JMB39X hardware RAID controller. Once JMB39X HW RAID Manager is started, the JMB39X HW RAID Manager GUI window will be opened and the application icon could also be found in the notification tray located at the bottom right hand corner of the... - Page 19 Part 2 - RAID Configuration If the user selects a controller item from the tree view, it Disk Information will display the model name and capacity of the RAID and disks connected on the specified controller at the right top table and also display all connected disk charts at the right bottom area.
-
Page 20: Event Log Viewer
Part 2 - RAID Configuration Event Log Viewer Basic RAID Configuration JMicron HW RAID Manager will monitor the status of JMicron HW RAID Manager provides users to do the basic all connected disks and RAID and make records of the RAID configuration to the connected disk. - Page 21 If the user deletes the RAID, the disk charts will be drawn in green color. After the RAID configuration, restart the service from the IDIS Solution Suite Service Manager to properly apply the changed storage. After the user confirms to apply the configuration, it will pop up another progress window to show the configuration status.
-
Page 22: Part 3 - Appendix
Part 3 - Appendix Troubleshooting Problem Solution ● Check the power cable connection status. ● Check the power outlet. The main unit won't turn on. ● Check the ATX power if the red LED is on or the buzzer rings. If the red LED is on or the buzzer rings, change the ATX power. -
Page 23: Specifications
Secondary Storage eSATA HDD (Extension) OS Storage * SSD is suggested as a storage for OS and IDIS Solution Suite installation, not for recording storage or Clip Copy bulk storage. GENERAL Unit Dimensions 482.6mm x 88mm x 523.3mm (19"x3.5"x20.6") (W x H x D) Unit Weight 12.6kg (27.8lb) - Page 24 Part 3 - Appendix Some hard disks may not function properly when mounted on to this product. Refer to the compatibility chart below before mounting any additional hard disk on to the product. Hard disk compatibility chart is subject to change without notice. Contact your retailer for the latest compatibility chart.
- Page 25 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
