  • Page 3: Table Of Contents

    TABLE OF CONTENTS Cautions 1. Introduction ........................1 1-1. Features ........................1 1-2. Clinical applications ....................2 1-3. Probe selection ......................3 1-4. Contents in package ....................3 2. Appearance ........................4 2-1. View .......................... 4 3. Quick start ........................8 3-1.
  • Page 4 m. OTHERS - CALibration ..................28 n. OTHERS - CAL PRINT (Printing Calibration) ............28 o. OTHERS - BACKLIGHT ..................28 p. OTHERS - AUTO-OFF (Automatic shut-off) ............29 q. OTHERS - DISCHARGE ..................29 4-3. Shortcut keys ......................30 4-4.
  • Page 5 Cautions Please read the following important points carefully before you operate the unit. 1. Only skilled persons should operate the unit. 2. Use the unit for measuring blood flow. 3. Do not apply any modification to the unit. 4. Device placement Follow the requirements for storage and operating environments.
  • Page 6 (8) Do not use the components for other devices. (9) Use the unit under the operating environments specified on the specifications. (10) Use the unit as specified in the operation manual. (11) Do not use the unit in a strong electromagnetic field or it may cause incorrect measurements.
  • Page 7 purchased the unit. (2) Only authorized persons should perform the repair services. 15. Do not disassemble the unit. 16. Destruction (1) In case of destruction of the unit, follow the instructions for disposal of the destruction appointed by each country or local government. (2) Do not place battery in a fire or it may cause an explosion and injury.

  • Page 8: Introduction

    1. Introduction Thank you very much for choosing the Smartdop 30EX. The Hadeco Smartdop 30EX is a uniquely designed bi-directional Doppler with backlit LCD display and Doppler blood pressure monitor capability. It detects arterial and venous blood flows in extremities as well as blood pressures of brachial, ankle and toe, calculates ABI and TBI and fetal heart sounds.

  • Page 9: Clinical Applications

    CONTRAINDICATIONS Do not use the Smartdop 30EX for ophthalmic or periordical studies as the acoustic intensity is higher than the level recommended by authorities for use on and around the eye.

  • Page 10: Probe Selection

    1-3. Probe selection The frequency of diagnostic ultrasound is inversely proportional to depth of penetration. The Smartdop has 5 interchangeable probes with different frequencies. Use those probes depending on your applications. BT2M20S8C (2MHz): Fetal heart rate BT4M05S8C (4 MHz): Deep peripheral blood velocity and flow BT5M05S8C (5 MHz): Deep peripheral blood velocity and flow BT8M05S8C (8 MHz):...

  • Page 11: Appearance

    2. Appearance 2-1. View Front Right View 1. Printer: To print velocity wave forms, systolic pressures, ABI / TBIs and velocity / pressure documentations and PPG / PV waveforms. 2. Speaker: Outputs Doppler sounds. 3. Volume control: To adjust sound volume. 4.
  • Page 12 Operating Panel 10. Mode LEDs: Indicate the mode selected. (Mode 1, Mode 2, ARM/LEG, TOE) Illuminate sequentially while charging battery. 11. MODE button: To select the mode of either the arterial Mode 1, venous Mode 2, ARM/LEG pressure or TOE pressure mode. See “§...
  • Page 13 15. INF/DUMP button: To freeze / unfreeze the waveform. Freeze Right Measuring pressure To inflate / dump the blood pressure cuff. To move cursor (systolic pressure point) to the right. Menu mode To move the cursor right. To change the mode or setting. 16.
  • Page 14 Back Right View and Probe 18. Roll shaft: To set paper roll. 19. Communication port: To connect computer. (USB) 20. Probe connector #2: To connect probe #2. 21. AC adaptor connector: To connect the designated AC adaptor. 22. Power switch: To turn on/off the unit.

  • Page 15: Quick Start

    3. Quick start For the first time of use and in case the unit has not been used for a while, fully charge the internal battery. 3-1. Turning the unit ON (1) Connect the probe to the probe connector so that the arrow mark will be placed under the Probe connector mark...

  • Page 16: Charging / Discharging Battery

    3-2. Charging / Discharging battery Charging battery: (1) Turn the unit off and plug the AC adaptor to the unit to charge battery. The Mode LEDs will illuminate sequentially (one after another) while charging is in progress. Note1: Use the designated AC adaptor. Model name: GMPU18UI-3 AC adaptor connector Note2: Charging battery with AC adaptor while in use may...

  • Page 17: Setting Printer Paper

    3-4. Setting printer paper (1) Remove the roll shaft and set it into the paper roll. Insert and hold the paper edge into the paper entry under the printer and press the PRINT button. (2) Press the button again when sufficient paper comes out.

  • Page 18: Measuring Blood Velocity

    3-5. Measuring Blood Velocity This section explains typical operation of measuring blood velocity. Refer to “§ 5-1. Arterial and venous blood velocity modes” and “§ 4-2. Menu Mode” for mode settings of various uses. (1) Connect the probe to the probe connector. See the step# (1) in the “§.3-1.

  • Page 19: Ankle Brachial Pressure Index (Abi)

    (6) Headset can be used to listen to Doppler sounds. It will cut off the speaker. If you wish to save the waveform and numerical data on the memory, see “§ 4-2-7-a. MEMORY - STORE”. Headset connector If you retry the measurement, press INF/DUMP button or probe button to get out of the freeze mode.
  • Page 20 Note1: Once you locate the point, please keep the probe there until blood pressure is taken. Note2: In case INF/DUMP LED doesn't blink due to low flow or arrhythmia, press INF/DUMP button longer than 2 sec to activate cuff inflator manually in the next step #6. (6) Press INF/DUMP or probe button to inflate the cuff.
  • Page 21 (9) Wrap the cuff above the ankle and apply the probe to the posterior tibial artery at an angle of approximately 45 to 60 degrees. Taking Ankle pressure: (10) Take the ankle pressure the same way for the brachial. (Steps #5 to #6 of this section) Press the LEG/TOE button to store it as the ankle pressure and the ABI will be displayed as shown in the right.

  • Page 22: Toe Brachial Pressure Index (Tbi)

    3-7. Toe brachial pressure index (TBI) Optional PPG probe (PG-21) is required for this testing. (1) Take the brachial pressure in the same way as ABI. Follow steps #1 to 7 of "§ 3-6 Ankle brachial pressure index (ABI)". (2) Remove arm cuff from tubing and replace with toe cuff, DVC-1.9 or DPC-2.5 for toe pressures.

  • Page 23: Pv - Arterial Studies

    3-8. PV – Arterial studies (1) Wrap VC-12 cuff around patient's leg, thigh at groin, above knee, below knee, or ankle. (2) Connect the cuff to the tubing and other end of tubing to the inflation inlet as shown in the right. Inflation inlet (3) Turn the unit on and press Probe Selection button a few times until both #1 and #2 LEDs on the...

  • Page 24: Measuring Fetal Heart Rate

    3-9. Measuring Fetal Heart Rate Evaluation of fetal heart rate and sounds throughout pregnancy except where fetal heart is not developed sufficiently during the first trimester. 3-9-1. Functions * Connect 2 MHz probe to the unit to go to fetal heart rate mode. * The unit display heart rate calculated every 2 sec.

  • Page 25: Operation

    3-9-3. OPERATION (1) Connect the probe to the probe connector. See the step# (1) in the “§.3-1. Turning the unit ON” for the details. (2) Put ultrasonic gel on the probe top or patient skin. (3) Turn the unit on and sake sure the probe selection LED illuminating corresponds to the connector you connected probe.

  • Page 26: Mode Settings

    4. Mode settings Note: For the mode and menu for PPG probe and PV probe, see “§ 7-3-4. Menu for PPG” and “§ 7- 4-3. Menu for PV”. 4-1-1. Basic Modes Smartdop has following six Basic Modes: 1. Arterial Blood Velocity: Mode 1 2.

  • Page 27: Menu Mode

    4-2. Menu mode Various mode settings are changeable in Menu mode. Some menus have sub menus. Refer to following Menus and Menu operation first. 4-2-1. Menus Menu: Submenu: Blood Velocity measurement mode Blood Velocity freeze mode ARM/LEG/TOE measurement mode ARM/LEG/TOE freeze mode PV AC measurement...

  • Page 28: Menu Operation

    4-2-2. Menu Operation (1) Press MENU button to go to Menu mode. The unit will display the menu depending on Basic Mode. (2) Select the menu by pressing Up (PRINT) or Down (LEG/TOE) buttons and selected mode will be highlighted. Press Right (INF/DUMP) button to change the setting.

  • Page 29: Menu For Blood Velocity Measurement Mode

    4-2-3. Menu for Blood Velocity Measurement Mode Note: *1 DISCHARGE is available when AC adaptor is connected to the main unit. 4-2-4. Menu for Blood Velocity Freeze Mode Note: *1 DISCHARGE is available when AC adaptor is connected to the main unit.

  • Page 30: Menu For Pressure Mode

    4-2-5. Menu for Pressure Mode Note: *1 GUIDANCE is available only on Measurement mode. *2 WAVEFORM, CURSOR and P.DISP are available only on Freeze mode. *3 STORE is available only when on Freeze mode and pressure(s) has been assigned to ARM or LEG/TOE.

  • Page 31: Menu Mode Details

    4-2-7. Menu Mode Details See “§ 4-2-2. Menu Operation” how to show each menu item. Do the mode setting once and subsequent Smartdop use will revert to this mode. a. MEMORY - STORE (1) STORE sub menu is available when on freeze mode only.

  • Page 32: Memory - Clear

    c. MEMORY - CLEAR (1) Select the memory number, in which you wish to clear the data. The memory number with "*" indicates memory area where data have been already stored. (2) Press Enter and then the confirmation screen with waveform stored will be displayed as shown in the picture right.

  • Page 33: Waveform (Freeze Mode Only)

    f. WAVEFORM (Freeze mode only)  Blood velocity and PV Arterial modes (Changing viewing area of waveform); Page 1 Press Right to change viewing area of waveform. Page 1: First half of waveform Page 2: Second half of waveform Note: The pages can be also switched by pressing a shortcut Page 2 key of MODE when on freeze mode of velocity and PV arterial.

  • Page 34: P.clear (Clearing Blood Pressure Data)

    h. P.CLEAR (Clearing blood Pressure data) (1) Press Enter and a confirmation of “CLEAR?” will be shown. (2) Press Enter again to clear the pressure data in RAM and “COMPLETED” will be shown for 5 sec. Note: This function can be also done by turning unit off and on OR pressing a shortcut key of ARM or LEG/TOE longer than 2 sec.

  • Page 35: Others - Prb-Key (Probe Button Function)

    l. OTHERS - PRB-KEY (Probe button function) Press Enter or Right to change the probe button function. FREEZE: Freezes/unfreezes waveform PRINT: Activates/deactivates printer FRZ&PRINT: Freeze and Print Note: When on ARM/LEG and TOE modes, probe button works the same way as INF/DUMP button no matter what is selected on the PRB-KEY mode.

  • Page 36: Others - Auto-Off (Automatic Shut-Off)

    p. OTHERS - AUTO-OFF (Automatic shut-off) Press Enter or Right to change the mode. Enables Automatic shut-off. OFF: Disables Automatic shut-off. See “§ 3-1. Turning the Unit On” for the details. q. OTHERS - DISCHARGE DISCHARGE is available when AC adaptor is connected to Smartdop. (1) Press Enter and confirmation “START?”...

  • Page 37: Shortcut Keys

    4-3. Shortcut keys Shortcut keys Functions Modes Reference in § 4-2-7 MODE + MENU Backlight On / Off All modes o. Others - Backlight MODE + RIGHT Right Cursor Pressure i. Cursor MODE + LEFT Left Cursor Pressure i. Cursor MODE + DOWN Zoom In / Out Pressure...

  • Page 38: Symbol List

    4-5. Symbol list Symbol Description Symbol Description Type BF applied part Freeze Headset Mode button USB connector Print button AC adaptor connector Menu button Probe connector Arm button Caution* Refer to the Operating Leg / Toe button manual Power ON Probe selection button Power OFF Probe button...

  • Page 39: Display And Printing

    5. Display and Printing 5-1. Arterial and venous blood velocity modes Arterial and venous blood velocity can be measured on these modes by Doppler technique. Smartdop displays and prints waveform as follows: Mode 1: Displays approx. 2.56 sec of waveform per screen of LCD Prints waveform in time scale of approx.

  • Page 40: Parameters

    5-1-2. Parameters Mode 1: Abbrs. Systolic velocity [cm/s] Mean velocity [cm/s] Heart rate [BPM] Mode 2: Abbrs. Systolic velocity [cm/s] Mean velocity [cm/s] Note: All computations are based on as follows: Mode1: Latest 3 beat average on measurement mode First 3 beat average on freeze mode Mode2: Latest 10 sec average on measurement mode First 10 sec average on freeze mode If the heart rate can't be calculated because of an over +/-25% irregularity due to an...

  • Page 41: Print Samples

    5-1-4. Print Samples Mode 1 (Artery): *Time scale 0.2 sec/div. (approx. 25 mm/sec) 0.2 sec 5 sec max. Mode 2 (Vein): *Time scale 1 sec/div. (approx. 5 mm/sec) 1 sec 25 sec max.

  • Page 42: Arm / Leg And Toe Pressure Modes

    5-2. ARM / LEG and TOE pressure modes Systolic blood pressures of Arm, Leg and Toe can be measured automatically on these modes and displayed them with velocity/pressure documentation. Also, Smartdop calculates ABI / TBI and prints them. For typical operation for Pressure modes, see “§ 3-6. Ankle brachial pressure index (ABI)” and “§...

  • Page 43: Error Messages

    5-2-3. Error Messages When error occurs while measuring blood pressure, the following error messages will be displayed on the LCD: E1: (Reserved) E2: Waveform error. E3: Pressure exceed 300 mmHg. E4: Systolic pressure not found. E5: Time out. E6: Cuff pressure don’t go up. E7: Cuff pressure don’t go down E9: Cuff pressure go up very fast Press any button other than probe selection button to delete the error message and...

  • Page 44: Pv Arterial Mode (Pv-Ac)

    5-3. PV arterial mode (PV-AC) PV Arterial Studies (PV-AC mode) can be performed on this mode without any optional probes. (PV-DC needs optional PV probe.) Smartdop displays and prints waveform as follows: Displays approx. 2.56 sec of waveform per screen of LCD Prints waveform in time scale of approx.

  • Page 45: Maintenance

    6. Maintenance 6-1. Performance check by user Please perform the maintenance in case the unit is not in use for a while. Preparation (1) Make sure if there is no damage and / or crack on the main unit and probe. (2) Check if wall voltage is good for rating input voltage of AC adaptor.

  • Page 46: Warranty

    6-3. Warranty The guarantee period is two years for this equipment and one year for probe after the date of purchase when used under normal conditions. In the event of a problem during the warranty period, please contact your dealer. In case the warranty period is over, please consult your dealer for a charged service.

  • Page 47: Others

    7-2. Others:  Sphygmomanometer  3-way stopcock  Smart-V-Link software with communication cable  Cuffs: DVC-1.9, DPC-2.5, VC-10, VC-12  PPG probe clip 7-3. Photoplethysmograph With the PG-21, Smartdop senses the reflection of light from the hemoglobin of the red blood cells in surface vessels by utilizing infrared light.

  • Page 48: Ppg - Venous Reflux Study

    Preparation (1) Connect the PPG probe assembly to the probe connector #1 or #2. (2) Make sure Mode 1 LED (AC mode) illuminates. If not, press MODE button to select Mode 1 for AC mode. (3) Check that the face of the PPG sensor is free of stains.
  • Page 49 Preparation (1) Connect the PPG probe assembly to the probe connector #1 or #2. (2) Make ure Mode 2 LED (DC mode) illuminates. If not, press MODE button to select Mode 2 for DC mode. (3) To change the counting number for patient dorsiflexes, go to the menu and select COUNT and then press Enter (or Right) until the number becomes the one desired.
  • Page 50 (6) The test is complete when the waveform on the LCD returns to the baseline amplitude. Smartdop will automatically freeze the waveform and calculate recovery times. Note: "1/2" is the half recovery time for returning to 50% of refilling amplitude where middle vertical dotted line is shown.

  • Page 51: Menu For Ppg

    7-3-4. Menu for PPG Menu Sub Menu Selections Reference in §4-2-7 STORE 1 to 30, FREEZE a. Memory - Store MEMORY READ 1 to 30, FREEZE b, Memory - Read CLEAR 1 to 30, ALLE c, Memory - Clear WAVEFORM PAGE 1, PAGE 2 f.

  • Page 52: Pneumoplethysmograph

    7-4. Pneumoplethysmograph With the PV-21, Smartdop senses volume changes in a limb or digit by measuring the pressure changes in a recording cuff. “How to use pneumoplethysmograph” is described in this section. Built-in cuff inflator works when INFLATOR in menu mode is ON to inflate cuff. See “§...
  • Page 53 Examination Procedure (1) Place the patient in supine position with the leg and hip rotated outward. Use pillows to support the leg and hip. It is important that the patient is comfortable and relaxed. (2) Wrap a wide occluding cuff at mid-thigh and a sensing cuff at mid-calf. (3) Connect a 3-way stopcock to the inlet of PV probe.

  • Page 54: Menu For Pv

    (11) Smartdop will automatically stop the measurement process, and then freeze the waveform. Press PRINT button to print the waveform, if necessary. (12) If you wish to save the data on the memory, see “§ 4-2-7-a. MEMORY - STORE”. (13) Press the INF/DUMP button to get out of the freeze mode.

  • Page 55: Technical Information

    8. Technical Information 8-1. Principles Model Smartdop 30EX is designed to obtain various blood flow velocity through the ultrasound which is transmitted from probe to patient body and is reflected by the blood (hemocyte, etc.). The unit amplifies the high frequency oscillation output and then supplies it to the transmitter transducer.

  • Page 56: Block Diagram

    8-2. Block diagram...

  • Page 57: Specifications

    8-3. Specifications Probes: Model Freq. Ispta* (in situ) [mW/cm²] BT2M20S8C 2 MHz 80 mW/cm² or less BT4M05S8C 4 MHz 390 mW/cm² or less BT5M05S8C 5 MHz 390 mW/cm² or less BT8M05S8C 8 MHz 390 mW/cm² or less BT10M5S8C 10 MHz 390 mW/cm²...
  • Page 58 Deflation rate: 2 - 5 mmHg/sec External outputs: Headset, USB port Electrical safety: Conform to IEC60601-1 Internally powered equipment Type BF applied part. Operating environment: 10 to 37 degrees Centigrade 85% humidity or less with no condensation Storage and transport environment: 0 to 50 degrees Centigrade 85% humidity or less with no condensation Dimensions:...

  • Page 59: Safety Standards

    Guidance and manufacturer’s declaration – electromagnetic emissions The Smartdop 30EX is intended for use in the electromagnetic environment specified below. The customer or the user of the Smartdop 30EX should assume that it is used in such an environment. Emissions test...
  • Page 60 Guidance and manufacturer’s declaration – electromagnetic immunity The Smartdop 30EX is intended for use in the electromagnetic environment specified below. The customer or the user of the Smartdop 30EX should assure that it is used in such an environment. Immunity test...
  • Page 61 If the measured field strength in the location in which the Smartdop 30EX is used exceeds the applicable RF compliance level above, the Smartdop 30EX should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Smartdop 30EX.
  • Page 64 Manufactured by Hadeco, Inc. September, 2017 2-7-11 Arima, Miyamae-ku, Kawasaki, Printed in Japan Kanagawa, 216-0003 Japan 080-00114-2.6...
