X2 Data Logger – Wi-Fi Setup
All X2 Data Loggers are equipped with Wi-Fi communications.
For applications using dedicated Wi-Fi telemetry, proceed through this document for network
and web setup instructions.

Advertisement

loading
Need help?

Need help?

Do you have a question about the X2 and is the answer not in the manual?

Questions and answers

Related Manuals for NexSens X2

Summary of Contents for NexSens X2

  • Page 1 X2 Data Logger – Wi-Fi Setup All X2 Data Loggers are equipped with Wi-Fi communications. For applications using dedicated Wi-Fi telemetry, proceed through this document for network and web setup instructions.
  • Page 2 X2 Data Logger – Wi-Fi Setup Connect all sensors to the ports specified on the back of the claim code card for each X2 logger.
  • Page 3 X2 Data Logger – Wi-Fi Setup Connect 12V power to the X2 through the center 6-pin port using one of the following: UW6-PW AC Power Adapter SP6- Solar power pack...
  • Page 4 Select the X2 Logger from the list of available Wireless Networks on a PC or Mobile Device and connect to it. If the X2’s network is not visible or if a disconnection occurs, insert the magnetic base of the included screwdriver to reset the Wi-Fi module.
  • Page 5 X2 Data Logger – Wi-Fi Setup On the logger network, navigate to X2.NexSens.com with any web browser to connect to the embedded web. Access the Main Menu. Toggle to hide/show menu Go to Settings|Network and toggle the Wi-Fi mode to ‘Network’...
  • Page 6 X2 Data Logger – Wi-Fi Setup Enter the local Network SSID, Security Settings, and Password at the X2 Deployment location and click Save Settings. The SSID is case sensitive and must be entered exactly as it is displayed.
  • Page 7 X2 Data Logger – Wi-Fi Setup Once the network information has been committed successfully, a prompt will appear to reset the X2 Wi-Fi via a magnet swipe. The accepted Network connection will be displayed above and the SSID and password fields will become greyed out.
  • Page 8 X2 Data Logger – Wi-Fi Setup When the Advanced Settings fields are left at their defaults (see below), the X2 will automatically acquire network settings via DHCP. Only change these settings if the network does not have a DHCP server available. Contact your network administrator for this information as...
  • Page 9 X2 Data Logger – Wi-Fi Setup Disconnect from the X2’s Wi-Fi network and reset its Wi-Fi with the magnet and reconnect to the primary network (the same one the X2 was just configured for). If the X2 has not yet been claimed into a WQData LIVE project, follow the steps outlined here.
  • Page 10 X2 Data Logger – Wi-Fi Setup Once the X2 is transmitting data to WQData LIVE, reference the Remote Device Configuration menu to customize system settings as desired.
